Summary of Contents for Kramer MODULAR TBUS-1Axl

  • Page 1 PDF provided by Conference Room AV Kramer TBUS-1Axl(B) Table Well Modular AV Box with Tilt Up Lid - Black...
  • Page 2 K R A ME R E LE CT R O N IC S L T D . USER MANUAL MODEL: MODULAR TBUS-1Axl Table Connection Bus P/N: 2900-300055 Rev 3...
  • Page 4: Table Of Contents

    F igure 1: TBUS-1Axl inside a Table F igure 2: TBUS-1Axl Enclosure Top View F igure 3: TBUS-1Axl Inner Frame (P/N: 80-000299) F igure 4: Installing a Kramer TOOL F igure 5: Installing the T-TBLANK TOOL Blank F igure 6: T-RC8IR (P/N: 80-000599)
  • Page 5: Introduction

    GROUP 9: Room Connectivity, GROUP 10: Accessories and Rack Adapters and GROUP 11: Sierra Products. Thank you for purchasing the Kramer TBUS-1Axl enclosure, which is ideal for boardrooms, conference and training rooms! Note that the inner frame, power socket assembly, power cord and other inserts for the TBUS-1Axl enclosure are purchased separately.
  • Page 6: Getting Started

    Use Kramer high-performance high-resolution cables Go to http://www.kramerelectronics.com to check for up-to-date user manuals, a complete list of Kramer wall plates and module connectors, application programs, and to check if firmware upgrades are available (where appropriate). Achieving the Best Performance To achieve the best performance: •...
  • Page 7: Overview

    France, Italy, Australia, Israel, South Africa or “Universal” for use anywhere (see compatibility restrictions in Section 7 Order the power sockets separately from Kramer Electronics Figure 1: TBUS-1Axl inside a Table Do not place heavy objects on top of the TBUS-1Axl.
  • Page 8: Your Tbus-1Axl Enclosure

    Remove it before installing the unit Enclosure Inserted into the table cut out TOOL Height Adjustment Used for installing Kramer TOOLs Screw Holes Tie Holes Insert the self-locking tie through the holes to fix the pass- through cables to the inside walls of the unit...
  • Page 9: Tbus-1Axl Optional Inner Frames

    2 openings for 4 power sockets 2 cable pass-through inserts 2 blank inserts T1AF-14L (P/N: 80-000699) 1 opening for 1 power socket 1 opening for Kramer SI-1VGA / RC-3TB 2 cable pass-through inserts 2 blank inserts TBUS-1Axl - Your TBUS-1Axl Enclosure...
  • Page 10: Tbus-1Axl Accessories

    You can install any wall plate devices as well as any of the single or dual inserts—see our Web site for details. T-RC8IR (P/N: 80-000599) 1 special panel to fit the Kramer RC-8IR Control Panel into the appropriate frame (P/N 80-000399 or P/N 80-000499 instead of two power...
  • Page 11: Power Socket Options

    Power Socket Options A choice of one or more power sockets per inner frame is available in several versions, including power sockets for the USA, Germany (the Europlug), Belgium- France, Italy, South Africa, Israel and Australia. A “Universal” socket for general use is also available (see the compatibility restrictions in the table below).
  • Page 12 Dual power sockets are used for TBUS-1Axl with two or four power sockets: Dual Power Socket Assemblies: Power Specs Universal: TS-2U (80-001899) 100-240V AC, 50/60Hz, 5A Maximum 5A/2.5A per power outlet USA: TS-2US (80-001999) 100-240V AC, 50/60Hz, 5A Maximum 5A/2.5A per power outlet Germany and EU: TS-2DE (80-002199) 100-240V AC, 50/60Hz, 5A...
  • Page 13: Power Cord Options

    Power Cord Options You can order any of the following power cords to use with a modular TBUS: Power Cord Type Description 6ft/110V (North America) C-AC/US (110V) 91-000099 6ft/125V (Japan) C-AC/JP (125V) 91-000699 6ft/220V (Europe) C-AC/EU (220V) 91-000199 6ft/220V (Israel) C-AC/IL (220V) 91-000999 6ft/250V (UK)
  • Page 14: Installing The Tbus-1Axl

    1. Unscrew the two screws that fasten the blank plate to the inner frame and remove the blank plate. 2. Place the required Kramer insert over the opening, insert the two screws to fix the Kramer insert in place, and tighten them.
  • Page 15: F Igure 3: Tbus-1Axl Inner Frame (P/N: 80-000299)

    (supplied). Power socket kits come with assembly instructions. 5.1.3 Mounting a Kramer TOOL To mount a TOOL (for example, to the T1AF-14T), as shown in Figure 1. Screw the spacers to their designated places (one on each side).
  • Page 16: F Igure 4: Installing A Kramer Tool

    3. Screw the screws (one on each side) through the frame holes and spacers. Figure 4: Installing a Kramer TOOL 5.1.4 Installing the TOOL Blank To install the T-TBLANK, as shown in Figure 1. Insert the T-TBLANK from beneath, through the TOOL opening.
  • Page 17: F Igure 6: T-Rc8Ir (P/N: 80-000599)

    5.1.5 Mounting the Special Panel for RC-8IR The Kramer T-RC8IR for the TBUS-1Axl Table Connection bus is used to fit the Kramer RC-8IR Control Panel into the appropriate frame (P/N 80-000399 or P/N 80-000499 instead of two power sockets). Inner Frame Attachment hole...
  • Page 18: Installation Instructions

    2. Place the T-RC8IR over the RC-8IR enclosure so that both face plate holes are aligned with the face plate holes on the RC-8IR enclosure and the IR IN receiver fits into the IR IN opening. 3. Insert the faceplate screws through the T-RC8IR and RC-8IR enclosure faceplate holes, and tighten.
  • Page 19: Cutting An Opening In The Table

    4. Unscrew and remove the template from the surface of the table and clean the table surface. Take care not to damage the table. If needed, you can download a full-scale template from our Web site. Kramer Electronics is not responsible for any damage caused to the table. TBUS-1Axl - Installing the TBUS-1Axl...
  • Page 20: Inserting The Tbus-1Axl Through The Cut Out Opening

    Inserting the TBUS-1Axl through the Cut Out Opening To install TBUS-1Axl in the opening: 1. Remove the protective rubber guard from around the outer rim of the TBUS-1Axl housing. Beware of the sharp edge! 2. Carefully insert the unit into the prepared opening (see Figure 3.
  • Page 21: Inserting The Pass-Through Cables

    2. Secure the cables to the tie holes on the TBUS-1Axl. Do not secure the cables too tightly or too loosely. Leave a small amount of slack. Inserting the Pass-through Cables To insert the pass through cables (for example, to connect a laptop) do the following: 1.
  • Page 22: Adjusting The Height Of The Inner Frame

    Adjusting the Height of the Inner Frame If needed, you can adjust the inner frame height to accommodate large or bulky cables. To adjust, perform the following: 1. Remove the height adjustment screws, while supporting the surface from underneath with your fingers. 2.
  • Page 23: Using The Tbus-1Axl

    Using the TBUS-1Axl Once the TBUS-1Axl is installed, you can easily customize it to suit your own requirements by plugging in the required A/V equipment, as illustrated in the example in Figure Figure 11: TBUS-1Axl Boardroom Installation TBUS-1Axl - Using the TBUS-1Axl...
  • Page 24: Technical Specifications Of The Assembled Tbus-1Axl

    Technical Specifications of the Assembled TBUS-1Axl POWER SOURCE Single Socket Assemblies: (AC power limits): 100-240V AC, 50/60Hz, 5A Universal Maximum 5A per power outlet Fully compatible with power plugs in the UK, India, Italy and Denmark, as well as with the 2-prong Europlug. Partially compatible (if the polarity is reversed) with plugs in China, Switzerland, Israel and the USA.
  • Page 25 TBUS-1Axl...
  • Page 27 For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. We welcome your questions, comments, and feedback. Web site: www.kramerelectronics.com E-mail: info@kramerel.com SAFETY WARNING...
