X-BAR Registers
7.3.1.4.11 OUTPUT6MUX0TO15CFG Register (Offset = 14h) [reset = 0h]
OUTPUT6MUX0TO15CFG is shown in
Return to Summary
Output X-BAR Mux Configuration for Output 6
31 30 29 28
MUX15 MUX14
R/W-0h R/W-0h
15 14 13 12
MUX7 MUX6
R/W-0h R/W-0h
Bit Field
31-30 MUX15
29-28 MUX14
27-26 MUX13
25-24 MUX12
23-22 MUX11
21-20 MUX10
1036
Crossbar (X-BAR)
Figure 7-66
Table.
Figure 7-66. OUTPUT6MUX0TO15CFG Register
27 26 25
MUX13 MUX12
R/W-0h R/W-0h
11 10 9
MUX5 MUX4
R/W-0h R/W-0h
Table 7-74. OUTPUT6MUX0TO15CFG Register Field Descriptions
Type Reset
R/W 0h
R/W 0h
R/W 0h
R/W 0h
R/W 0h
R/W 0h
Copyright © 2015–2017, Texas Instruments Incorporated
and described in Table
24 23 22 21
MUX11 MUX10
R/W-0h R/W-0h
8 7 6 5
MUX3 MUX2
R/W-0h R/W-0h
Description
Select Bits for OUTPUT6 Mux15:
00 : Select .0 input for Mux15
01 : Select .1 input for Mux15
10 : Select .2 input for Mux15
11 : Select .3 input for Mux15
Refer to the Output X-BAR section of this chapter for more details.
Select Bits for OUTPUT6 Mux14:
00 : Select .0 input for Mux14
01 : Select .1 input for Mux14
10 : Select .2 input for Mux14
11 : Select .3 input for Mux14
Refer to the Output X-BAR section of this chapter for more details.
Select Bits for OUTPUT6 Mux13:
00 : Select .0 input for Mux13
01 : Select .1 input for Mux13
10 : Select .2 input for Mux13
11 : Select .3 input for Mux13
Refer to the Output X-BAR section of this chapter for more details.
Select Bits for OUTPUT6 Mux12:
00 : Select .0 input for Mux12
01 : Select .1 input for Mux12
10 : Select .2 input for Mux12
11 : Select .3 input for Mux12
Refer to the Output X-BAR section of this chapter for more details.
Select Bits for OUTPUT6 Mux11:
00 : Select .0 input for Mux11
01 : Select .1 input for Mux11
10 : Select .2 input for Mux11
11 : Select .3 input for Mux11
Refer to the Output X-BAR section of this chapter for more details.
Select Bits for OUTPUT6 Mux10:
00 : Select .0 input for Mux10
01 : Select .1 input for Mux10
10 : Select .2 input for Mux10
11 : Select .3 input for Mux10
Refer to the Output X-BAR section of this chapter for more details.
SPRUI33 – November 4 2015 – Revised January 2017
www.ti.com
7-74.
20 19 18 17
MUX9 MUX8
R/W-0h R/W-0h
4 3 2 1
MUX1 MUX0
R/W-0h R/W-0h
