Texas Instruments TMS320F28004x Technical Reference Manual page 1010

X-BAR Registers
Table 7-65. OUTPUT1MUX16TO31CFG Register Field Descriptions (continued)
Bit Field
19-18 MUX25
17-16 MUX24
15-14 MUX23
13-12 MUX22
11-10 MUX21
9-8 MUX20
7-6 MUX19
5-4 MUX18
1010
Crossbar (X-BAR)
Type Reset Description
R/W 0h
Select Bits for OUTPUT1 Mux25:
00 : Select .0 input for Mux25
01 : Select .1 input for Mux25
10 : Select .2 input for Mux25
11 : Select .3 input for Mux25
Refer to the Output X-BAR section of this chapter for more details.
R/W 0h
Select Bits for OUTPUT1 Mux24:
00 : Select .0 input for Mux24
01 : Select .1 input for Mux24
10 : Select .2 input for Mux24
11 : Select .3 input for Mux24
Refer to the Output X-BAR section of this chapter for more details.
R/W 0h
Select Bits for OUTPUT1 Mux23:
00 : Select .0 input for Mux23
01 : Select .1 input for Mux23
10 : Select .2 input for Mux23
11 : Select .3 input for Mux23
Refer to the Output X-BAR section of this chapter for more details.
R/W 0h
Select Bits for OUTPUT1 Mux22:
00 : Select .0 input for Mux22
01 : Select .1 input for Mux22
10 : Select .2 input for Mux22
11 : Select .3 input for Mux22
Refer to the Output X-BAR section of this chapter for more details.
R/W 0h
Select Bits for OUTPUT1 Mux21:
00 : Select .0 input for Mux21
01 : Select .1 input for Mux21
10 : Select .2 input for Mux21
11 : Select .3 input for Mux21
Refer to the Output X-BAR section of this chapter for more details.
R/W 0h
Select Bits for OUTPUT1 Mux20:
00 : Select .0 input for Mux20
01 : Select .1 input for Mux20
10 : Select .2 input for Mux20
11 : Select .3 input for Mux20
Refer to the Output X-BAR section of this chapter for more details.
R/W 0h
Select Bits for OUTPUT1 Mux19:
00 : Select .0 input for Mux19
01 : Select .1 input for Mux19
10 : Select .2 input for Mux19
11 : Select .3 input for Mux19
Refer to the Output X-BAR section of this chapter for more details.
R/W 0h
Select Bits for OUTPUT1 Mux18:
00 : Select .0 input for Mux18
01 : Select .1 input for Mux18
10 : Select .2 input for Mux18
11 : Select .3 input for Mux18
Refer to the Output X-BAR section of this chapter for more details.
