Levelflex FMP56, FMP57 HART
4-wire, 4-20mA HART, active
"Power supply; Output"
K: 4-wire 90-253VAC; 4-20mA HART
L: 4-wire 10,4-48VDC; 4-20mA HART
1) Feature 020 of the product structure
7.1.4 Overvoltage protection
If the measuring device is used for level measurement in flammable liquids which requires the
use of overvoltage protection according to DIN EN 60079-14, standard for test procedures
60060-1 (10 kA, pulse 8/20 μs), overvoltage protection has to be ensured by an integrated or
external overvoltage protection module.
Integrated overvoltage protection
An integrated overvoltage protection module is available for 2-wire HART as well as
PROFIBUS PA and FOUNDATION Fieldbus devices.
Product structure: Feature 610 "Accessory mounted", option NA "Overvoltage protection".
Resistance per channel
Threshold DC voltage
Threshold impulse voltage
Capacitance at 1 MHz
Nominal arrest impulse voltage (8/20 μs)
External overvoltage protection
HAW562 or HAW569 from Endress+Hauser are suited as external overvoltage protection.
For detailed information please refer to the following documents:
• HAW562: TI01012K
• HAW569: TI01013K
7.2

Connecting the device

WARNING
L
Explosion hazard!
‣
Comply with the relevant national standards.
‣
Observe the specifications in the Safety Instructions (XA).
‣
Only use the specified cable glands.
‣
Check whether the supply voltage matches the specifications on the nameplate.
‣
Before connecting the device: Switch the supply voltage off.
‣
Before switching on the supply voltage: Connect the potential bonding line to the exterior
ground terminal.
Endress+Hauser
1)
Terminal voltage
90 to 253 V
10.4 to 48 V
(50 to 60 Hz), overvoltage category II
AC
DC
Technical data
Electrical connection
Maximum load R
500 Ω
2 * 0.5 Ω max
400 to 700 V
< 800 V
< 1.5 pF
10 kA
max
39
