Racelogic RLVBDSP02 Instruction Manual page 7

LED Display
Press the button to cycle through SP0-SP7. When the desired parameter number is
selected, stop pressing the button. After a short delay of approximately 3 seconds the
display will return to operational mode.
Example. To select lateral acceleration press the button in short succession until
the display shows SP 4. After approximately 3 seconds the display will start showing
lateral acceleration (Before Longacc will work, you must have set the GPSLongacc
channel in Extra serial Data under VBOX Setup)
LED Display
RLVBDSP02_Manual.doc
Display knots
Display km/h
Display mph
Longitudinal Acceleration
Ensure you have enabled
GPSLongacc in "VBOX Setup" ->" Serial
data" settings
Lateral Acceleration
GPSLatacc in "VBOX Setup" ->" Serial
data" settings
Display number of satellites in view
Display height (Ref WGS84)
Display Vertical Velocity m/s
Revision 1 30/04/2008
Description
Page 7 of 9
