LED Display

Introduction

The RLVBDSP02 is a LED Display module for use with the Racelogic VBOX. It provides an
easy to read display of vehicle speed. In addition to speed the LED display can also show
lateral acceleration, current satellite count and height and vertical velocity. Connection to the
VBOX is via the 5 pin Lemo connector on the VBOX.
The speed figure shown on the display is heavily smoothed when compared with the actual
GPS speed, to allow the user to easily see the vehicle speed when it is changing quickly.
Therefore when you come to a stop suddenly, the display will lag behind the real speed being
measured.

Parts supplied with RLVBDSP02

1 x RLVBDSP02 LED Display
1 x RLVBCAB05 Connection cable to Readout
1 x RLVBACS014 Suction mount for LED Display

Specification

Size - Single
Size - Dual
Mounting
Weight
Display
Speed
Height
Vertical Velocity
Power
Cable supplied
RLVBDSP02_Manual.doc
110mm x 50mm x 25mm (4 ¼" x 2" x 1")
110mm x 50mm x 30mm (4 ¼" x 2" x 1 ¼")
Velcro mounting suction cups
Approx 100g / 14.1oz
4 x 7 segment LED. Daylight readable
Knots or Km/h or Mph
Metres (Ref WGS84) Max 999.9m
M/S
Approx 200mA
RLVBCAB05
Revision 1 30/04/2008 Page 4 of 9
