Multi-Function Display User Manual
•
01 - MFD Introduction
•
02 - MFD Test screens
•
03 - MFD Data Display Options
•
04 - MFD Menu Options
•
05 - MFD Setup (VBOX Tools)
•
06 - MFD Display Parameter Tables
•
07 - MFD Thermal Printer
•
08 - MFD Firmware Upgrade
•
09 - MFD CAN Output
•
10 - MFD PIN OUTS
•
11 - MFD Technical Specifications
•
12 - MFD Standard Inventory and Accessories
•
Home
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Racelogic RLVBDSP03-24
Summary of Contents for Racelogic RLVBDSP03-24
- Page 1 Multi-Function Display User Manual • 01 - MFD Introduction • 02 - MFD Test screens • 03 - MFD Data Display Options • 04 - MFD Menu Options • 05 - MFD Setup (VBOX Tools) • 06 - MFD Display Parameter Tables •...
- Page 2 Also in the serial connectors is a digital output, which will either send a pulse or toggle its state when a split line is crossed. https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/...
-
Page 3: Basic Operation
Three buttons are used to configure the display. The left and right arrow keys are used for selecting a menu item or cycling through the display screens. When power is applied, the display will revert to the data display mode. https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/... -
Page 4: How To Select A Parameter
Make sure the hole on the rear of the display that is used for the buzzer is not obstructed. Note: Exposing the windscreen mount to large changes in temperature over a prolonged period of time may cause loss of suction. We would recommend that the suction mount is removed when the days testing is complete. https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/... -
Page 5: Pre-Set Test Screens
Press OK to clear the results from all of the Pre-set tests. Press OK to print all of the results from all of the Pre-set tests on a Thermal Printer connected to the serial port of the MFD. Press OK to enter the general Pre-set test setup screens. https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/... - Page 6 Press OK to edit the Start speed for the test. Press OK to edit the End speed for the test. Press OK to edit the distance over which the test should be timed. Press OK to return to the main menu https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/...
- Page 7 13 screen layouts. Some screens will display a title page, which will timeout after approximately one second if no buttons are pressed. The title pages are to inform the user as to which page is displayed, as shown in the examples below. https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/...
-
Page 8: Mode Screens
If only two parameters are displayed, then the complete description of the channel will be displayed alongside the value, as shown above. The setting to change between parameter configurations can be found in CONFIG DISPLAY > NUM OF PARAMS. https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/... - Page 9 The parameters are split into 4 groups: General, Brake, Accel and CAN. General parameters are taken from standard Racelogic CAN output from the VBOX. Brake parameters are commonly used in brake testing, the majority of which require the use of a brake trigger switch with the VBOX. Accel parameters are used in acceleration tests, and CAN parameters are from external modules connected to a CAN bus, such as analogue, thermocouple or vehicle CAN data.
- Page 10 Settings such as Contrast, Backlight brightness and units of measurement. View the display firmware version and serial number. View the current compact flash file name, memory % used and logging status. Press OK to return to the data display mode. https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/...
-
Page 11: Set Parameters Menu
OK to set. Change the contrast of the LCD. Adjust the contrast using the arrow keys and press OK to set. Select measurement units. When units are flashing, the arrow keys switch between Kmh & Mph. https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/... - Page 12 OK will reset Average Velocity and the Distance Travelled. Note, Average Velocity is calculated from VBOX turn on and not from first movement. Define a velocity at which the MFD will momentarily beep. Enable/disable on screen Brake Trigger message when the Brake Trigger is pressed. https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/...
-
Page 13: Version Menu
Define up to four distances for drive by noise testing. When these are crossed the display will beep. Version Menu Hardware Version Firmware version. Unit serial number. Press OK to return to the main menu. https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/... -
Page 14: Target Set-Up Menu
When the start / finish line is crossed, a new lap is stored. Lap times are saved when the MFD is turned off. Power up resets the lap counter to lap 1, so any previously stored times will be overwritten when new laps are completed. https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/... - Page 15 Change whether split time is time from start / finish line (ON) or time from previous split point (OFF). Change whether digital output pulses or toggles when crossing a start / finish split line. Press OK to reset average lap time and lap count. https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/...
- Page 16 From within this window all of the functions and display parameters of the MFD can be set. To change any of the displays parameters, click on a title and a new window appears allowing the selection to be changed. https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/...
- Page 17 The image on the right shows the setup screen for Lap Timing functions of the MFD. Note that from the Lap Timing setup page Lap and Split positions can be downloaded from or uploaded to the VBOX. https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/...
-
Page 18: Accel/Decel Test Setup
Accel/decel test setup From within this page the start and end criteria for the Accel and Decel tests can be set. These Accel and Decel tests run concurrently when either of the Main Screens are displayed. https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/... -
Page 19: General Parameters
Lateral Acceleration Max. Lateral Acceleration Longitudinal Acceleration Average Velocity km/h or mph Distance Travelled m or ft Vertical Velocity 2 m/s or ft/s Current Filename VBOXIII & VB3i File Status VBOXIII & VB3i IMU-INS Status Kalman Filter Status table https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/... -
Page 20: Brake Parameters
**To set up the start and end speed for the acceleration / deceleration tests enter the CONFIG DISPLAY MENU from screens 1, 2 or 3, scroll across until the screen displays ACCEL/DECEL SETUP press OK to enter the test set-up menu. https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/... -
Page 21: Accel Parameters
VBOX Tools or a logged file will be a result of adding together the numbers of the active statuses shown below. Kalman Filter Status Decimal kf_Clear 0x0000 kf_NEWIMUVersion 0x0001 kf_TestMode 0x0002 kf_Use 0x0004 kf_Initialised 0x0008 kf_IMUDataFound 0x0010 https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/... -
Page 22: Lap Timing Parameters
Average Lap Time Velocity km/h or mph Lap Time Velocity at start / finish line km/h or mph Split 1 time Velocity at split 1 km/h or mph Split 2 time Velocity at split 2 km/h or mph Split 3 time https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/... -
Page 23: Pass-By-Noise Parameters
*Velocity at start line km/h or mph *Velocity at finish line km/h or mph *Acceleration between mid-point m/s² and finish line *Acceleration across Drive-By-Noise m/s² test area *A laser light barrier kit must be present in order to use these parameters. https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/... - Page 24 Note: When doing lap timing, set the end speed for the acceleration test and start speed of deceleration test to a value you will not attain (i.e. 900) otherwise every time you have a valid test, the results will be printed out along with the lap timing results which can be confusing. https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/...
-
Page 25: Loading Paper
Pattern Battery Paper Buffer Green Charging Normal Green Orange Green Orange Charging Normal Orange Charging Spooling Green Green Running Normal Green Orange Running Normal Orange Orange Running Spooling Normal Orange Spooling No light Flat, or in sleep mode https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/... - Page 26 • When the display is connected and setup, double click on the firmware file to start the upgrade. • Racelogic Upgrader software should be launched, simply select the correct COM port the MFD is connected to (this can be checked in device manager) and click upgrade to begin.
-
Page 27: Standard Channels
2. Velocity units indication, single bit, 0 = MPH; 1 = KPH. 3. Velocity when brake trigger activated, 0.01 km/h/ mph per bit. 4. Distance travelled from activation of brake trigger, 0.01 m/ft per bit. 5. Time from brake trigger being activated until rest, 0.01 seconds per bit. https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/... -
Page 28: Pre-Set Test Channels
• Test 1 ID: 0x509 • Test 2 ID: 0x50A • Test 3 ID: 0x50B • Test 4 ID: 0x50C • Test 5 ID: 0x50D • Test 6 ID: 0x50E • Test 7 ID: 0x50F • Test 8 ID: 0x50G https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/... -
Page 29: End Conditions
(1) Units (2) End_Speed (3) Distance Unused test no. 1. Velocity units indication, single bit, 0 = MPH; 1 = KPH. 2. End speed for test, 0.1 km/h/ mph per bit. 3. Distance travelled during test, 0.01 m/ft per bit. https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/... - Page 30 10 - MFD PIN OUTS CAN Connectors - Top Left and Top Right (Lemo 5 PIN) Function RxD, Serial Data Transmit – COM2 CAN High CAN Low +12 V Power Chassis Ground https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/...
-
Page 31: Rs232 Connectors - Bottom Left And Bottom Right (Lemo 5 Pin)
RS232 Connectors - Bottom Left and Bottom Right (Lemo 5 PIN) Function TxD, Serial Data Transmit – COM1 - Firmware Upgrade RxD, Serial Data Receive – COM1 - Firmware Upgrade Digital Output 1 - Lap pulse/toggle Digital Output 2 - Unused +12 V Power Chassis Ground https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/... -
Page 32: Mfd Technical Specifications
Power Input Voltage Range 12/ 24 V DC (±10 %) Either Velcro mounting suction cups or 1/4 - 20 screw Mounting mounting Weight (approximate) 400 g / 14.1 oz 20 x 2 Line LCD with contrast control and adjustable Display backlight https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/... - Page 33 Data Operating Temp 0 - 60 °C Storage Temp -40 to +85 °C https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/...
-
Page 34: Standard Inventory
12 - MFD Standard Inventory and Accessories Standard Inventory Description Product Code MFD unit RLVBDSP03-24 VBOX Connection cable RLCAB005 Suction Mount RLVBACS041 Optional Accessories Description Product Code Serial cable for firmware upgrade RLCAB001 Unterminated 5W Lemo cable RLCAB015 MF Display Thermal Printer RLVBACS026 https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/... - Page 35 Home OutOfRangeError: index value is out of range (click for details) Callstack: at (Template:Custom/Views/PDFPageFooter), /content/body/pre, line 11, column 13 at template() at () • VBOX Automotive • https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/...
- Page 36 VBOX Motorsport • LabSat GNSS Simulators • VBOX Mining https://racelogic.support/01VBOX_Automotive/06Displays/Multi-Function_Display_(MFD)/...
