Installation

Mounting components and dimensions

Personal injury hazard. Only qualified personnel should conduct the tasks described in this section of the manual.
The controller can be installed on a surface, panel or pipe (horizontal or vertical). For mounting
options and instructions, refer to
on page 10 and Figure 6
For horizontal pipe mounts, the mounting feet
a vertical position.
For both horizontal and vertical pipe mounts, attach the mounting bracket to the controller as shown
in Figure 5 on page 10.
Figure 2 Mounting components
1 Mounting foot (2x)
2 Sealing gasket for panel mount, Neoprene
3 Bracket for wall and pipe mounting
4 Vibration isolation gasket for pipe mount
5 Vibration isolation washer for pipe mount (4x)
Note: A bracket for panel mounting is available as an optional accessory.
C A U T I O N
Figure 2, Figure 3
on page 11.
(Figure
on page 8, Figure 4 on page 9,
2) must be attached to the mounting bracket in
6 Flat washer, ¼-inch ID (4x)
7 Lock washer, ¼-inch ID (4x)
8 M5 x 0.8 Keps hexnut (4x)
9 Pan head screws, M5 x 0.8 x 100mm (4x) (Used for
variable diameter pipe mount installations)
10 Pan head screws, M5 x 0.8 x 15 mm (4x)
Figure 5
