DMA Transfer count:
No limitation for chaining mode (scatter/gather) DMA
Max. Transfer rate:
DO: 80M Bytes/sec: 32-bit output @ 20 MHz
DI: 80M Bytes/sec: 32-bit input @ 20 MHz
Programmable Counter:
Device: 82C54-10
Digital Input Pacer: 20MHz, 10MHz, or clock output of Timer
#0
Digital Output Pacer: 20MHz, 10MHz, or clock output of
Timer #1
General Specifications
Connector: one 100-pin male SCSI-II style cable connector
Operating Temperature: 0? C ~ 60?C
Storage Temperature: -20? C ~ 80?C
Humidity: 5 ~ 95%, non-condensing
Dimension: Compact size only 179mm(L) X 102mm(H)
Power Consumption:
+5 V @ 830 mA max. with on-board terminator off, or
+5 V @ 1.0A max. with on-board terminator on
4 Introduction
