Submenu level 2 → TB GAS TEMP MENU
Display indication
Designation according to PA profile
3.0
TB TEMP STATE
PRIMARY_VALUE
TEMPERATURE UNIT
PRIMARY_VALUE_UNIT
GAS S1 STATE
SECONDARY_VALUE_1
HEATER S2 STATE
SECONDARY_VALUE_2
SENSOR MEASURING TYPE
SENSOR_MEAS_TYPE
ZERO OFFSET COMP GAS
BIAS_1
ZERO OFFSET COMP HEATER
BIAS_2
END TB GAS TEMP
42/14-39 EN
Sensyflow iG, Version 1.00
Operation, configuration and communication
Explanation
D
Display of status message for the gas temperature in hexadecimal
notation
Display 0x80 ... 0x83 → OK
(see section 7.1.2.2
SP
Select from °C, F, K
D
Display of status message for the gas temperature in hexadecimal
notation
Display 0x80 ... 0x83 → OK
(see also section 7.1.2.2 and 7.1.2.3)
D
Display of status message for the heater temperature in hexadecimal
notation
Display 0x80 ... 0x83 → OK
(see section 7.1.2.2
SE
Select from
PV = SV1,
PV = SV2,
PV = SV2 - SV1
(SV1 = gas temperature, SV2 = heater temperature)
SP
Input of a zero offset compensation value for the gas temperature in the
selected unit (e. g. -3 °C)
Caution: This function shifts the entire characteristics!
Default = 0
SE
Input of a zero offset compensation value for the heater temperature in
the selected unit (e. g. 5 °C)
Caution: This function shifts the entire characteristics!
Default = 0
and
see section 7.1.2.3
)
and
see section 7.1.2.3
)
