The context-sensitive button functions are shown in the display. This allows easy operation and configu-
ration of the Sensyflow iG.
The display modes show symbols in the lower right corner of the display, indicating device status infor-
mation.
36 Sensyflow iG, Version 1.00
In the low-voltage versions you can use also the push-buttons for parameterizati-
on, after removing the front cover and the display cover frame.
!
Caution!
Take ESD precautions before touching the assemblies!
ENTER button (also shown inverted in the display)
– Access to submenus
– Input confirmation
– Browsing through several functions
– Going back up one menu level
ARROW buttons, up/down (also shown inverted in the display)
– Navigating within a menu level (main menu, submenu level 1, submenu level 2)
ARROW buttons, left/right
– Navigating within an input field
<
>
+ button
– Incrementing numerical values
+
– Changing characters and special characters
-||-
Connect – a proper cyclic PROFIBUS connection is established.
-| |-
Disconnect – cyclic PROFIBUS connection interrupted.
Overflow – measuring value cannot be displayed (if possible, change display unit),
O
output values are not effected.
*
Pulsating asterisk – indicates normal operating condition (measuring operation).
Simulation – simulated values and status signal are output instead of measuring
S
values.
Error – device indicates status signal with error. Status signals can be called up in
E
the SERVICE MENU.
