7.1.2
Sensyflow iG provides cyclic data communication for the following modules, which are described in the
vendor-specific GSD file.
Module
No.
1
2
3
4
5
6
7
Four modules must be selected for cyclic data communication. Observe the following slot assignment for
configuring the modules.
• Slot 1: Empty_Module, Mass flow
• Slot 2: Empty_Module, Gas temp.
• Slot 3: Empty_Module, Total, SET_Total, SET/MODE_Total, Characteristics Input
• Slot 4: Empty_Module, Characteristics Input
22 Sensyflow iG, Version 1.00

Module configuration for cyclic data communication (DP)

Module Byte
Input
Empty_Module -
Mass flow 5 Byte
(Float +
Status]
Gas temp. 5 Byte
(Float +
Status]
Total 5 Byte
(Float +
Status]
SET_Total 5 Byte
(Float +
Status]
SET/MODE_Total 5 Byte
(Float +
Status]
Characteristics Input -
Operation, configuration and communication
Data type Byte
Input Output
0 -
Byte 0..3 Float -
Byte 4 Status
Byte 0..3 Float -
Byte 4 Status
Byte 0..3 Float -
Byte 4 Status
Byte 0..3 Float 1 Byte
Byte 4 Status
Byte 0..3 Float 2 Byte
Byte 4 Status
0 7 Byte,
(2 Byte,
Float +
Status)
Data type
Output
0
0
0
0
Byte 0
0=Totalize
1=Reset 2=PRESET
Byte 0
0=Totalize
1=Reset 2=PRESET
Byte 1
0-2=Totalize
3= HOLD
Byte 0
Bit 0..3
0x0 = characteristic 1
0x1 = characteristic 2
0x2 = characteristic 3
0x3 = characteristic 4
Bit 4..6 reserved
Bit 7
0x0 = change characteristic
0x1 = characteristic active
Byte 1
Bit 0..3
0x0 = Start
0x1 = Halt
0x3 = Preset
0x4 = Reset
Byte 2 (reserved)
Byte 3..6
Float Integrator value
42/14-39 EN
