7.7.2
Submenu level 2 → TB FLOW MENU
Display indication
Designation according to PA
profile 3.0
42/14-39 EN Sensyflow iG, Version 1.00

Submenu level 2

CALIBRATION FACTOR
CALIBR_FACTOR
LOW FLOW CUT-OFF
LOW_FLOW_CUTOFF
ZERO POINT COORECT
ZERO_POINT
ZERO POINT ON/OFF
ZERO_POINT_ADJUST
MASS FLOW STATE
MASS FLOW STATE
MASS FLOW UNIT
MASS_FLOW_UNIT
MIN MASS FLOW
MASS_FLOW_LO_LIM
MAX MASS FLOW
MASS_FLOW_HI_LIM
END TB FLOW MENU
Operation, configuration and communication
Explanation
SE Input of calibration factor that acts as multiplier on measu-
ring value.
Caution:
This functions changes the gradient of the characteristic
curve!
Default = 1
SP Input of the threshold amount in the selected mass flow unit
(e. g. 5 kg/h). For measurement values below the selected
threshold the device outputs a zero signal.
Default = 0
SE Input of the zero offset compensation value in the selected
mass flow unit (e. g. 1 kg/h).
Caution:
This function shifts the entire characteristics curve!
Default = 0
SE Activation of the set zero offset compensation
Default = OFF
D Display of status message for mass flow in hexadecimal no-
tation
Display 0x80 ... 0x83 → OK
(see section 7.1.2.2
SP Select from
t/d, t/h, t/m, t/s
kg/d, kg/h, kg/m, kg/s
g/h, g/m, g/s
lb/d, lb/h, lb/m, lb/s
3 3 3
Nm /d, Nm /h, Nm
Nl/d, Nl/h, Nl/m, Nl/s
SCFD, SCFH, SCFM, SCFS
SE Lower range value.
Default = 0
SE Upper range value of selected characteristics
and see section 7.1.2.3 )
3
/m, Nm /s
45
