Max Jax Parts List - Dannmar maxjax User Manual

ITEM NO PART NUMBER
1 17150002
2 17154001
3 17200028
4 17201010
5 17206016
6 17206017
7 17156001
8 17156002
9 17300003
10 17207037
11 17108041
12 17207015
13 17200005
14 17207011
15 17200017
16 17202012
17 17207033
18 17107006
ITEM NO PART NUMBER
1 17151001
2 17157001
3 17152001
4 17157002
5 17158009
6 17102009
7 17153001
8 17250017
9 17200029
10 17200021
11 17201010
12 17201017
13 17207038
14 17158010
15 17200022
16 17206015
17 17206019
18 17206018
19 17206020
20 17157003

MAX JAX PARTS LIST

MAX JAX ASSEMBLY
MAX JAX POWER UNIT STAND ASSEMBLY
MJ-MAORB 90~ LONG 6801-LL-06-06-NWO
MALE 90° ELBOW, EXTRA LONG 2501-LL-06-06
MAX JAX HYD. HOSE ASSEMBLY Ø10 x 4520mm
MAX JAX HYDRAULIC HOSE ASSEMBLY Ø10 x 295mm
MAX JAX POST ASSEMBLY
SERRATED HEX FLANGE SCREW M8 x 12
3/8-18 NPT MALE QUICK DISCONNECT COUPLING
FOR TECHNICAL QUESTIONS, CALL (877)432-6627
DESCRIPTION
MAX JAX POST ASSEMBLY
M8 x 20 HEX HEAD BOLT
M8 NYLON LOCK NUT
110 VOLT, 1HP POWER UNIT
HYDRAULIC FLOW DIVIDER
SHORT LIFT PAD EXTENSION
POWER UNIT VIBRATION DAMPENER
M8 x 25 HEX HEAD BOLT
7/8 x 3-13/16 DROP IN SLEEVE ANCHOR
5/8-11 HEX HEAD BOLT
5/8 FLAT WASHER
SHIM
SLIP ON LIFT PAD ASSEMBLY
DESCRIPTION
MAX JAX POST WELDMENT
MAX JAX SAFETY PIN ASSEMBLY
MAX JAX LIFT HEAD WELDMENT
MAX JAX LIFT HEAD PIN WELDMENT
MAX JAX SLIDE BLOCK
ARM LOCK ASSEMBLY
MAX JAX ARM WELDMENT
CYLINDER ASSEMBLY Ø2.0 x 42
HEX HEAD BOLT M8 x 55mm
M10 x 45 HEX HEAD BOLT
M8 NYLON LOCK NUT
M10 NYLON LOCK NUT
C RING Ø38mm OD 5103-150
MAX JAX WHEEL
45° STREET ELBOW 5503-06-06
HEX NIPPLE 5404-06-06
STRAIGHT EXPANDER 5405-04-06
MAX JAX POST STRAP WELDMENT
QTY
2
1
4
8
1
1
2
1
1
1
4
1
4
10
10
10
20
4
QTY
1
1
1
2
4
2
2
1
2
2
2
2
2
2
8
1
1
1
1
1
9
