Rotary Hammer Drill Or Similar (If Anchoring)

‡

5/8" Masonry Bit

‡

7/8" Masonry Bit

‡

Hammer

‡

4 Foot Level

‡

Open End Wrench Set: Metric

‡

Socket And Ratchet Set: Metric

These instructions must be followed to ensure proper installation and operation of your lift. Failure to

comply with these instructions can result in serious bodily harm and void product warranty. Manufacturer

will assume no liability for loss or damage of any kind, expressed or implied resulting from improper

installation or use of this product.

BEFORE INSTALLING YOUR NEW LIFT, CHECK THE FOLLOWING:

1. LIFT LOCATION: Always use architects plans when available. Check layout dimension against floor

plan requirements making sure that adequate space is available.

2. OVERHEAD OBSTRUCTIONS: The area where the lift will be located should be free of overhead

obstructions such as heaters, building supports, electrical lines etc.

3. DEFECTIVE FLOOR: Visually inspect the site where the lift is to be installed and check for cracked or

defective concrete.

4. OPERATING TEMPERATURE. Operate lift only between temperatures of 41° -104° F.

5. Lift is designed for INDOOR INSTALLATION ONLY.

The floor on which the lift is to be installed must be 4-inch minimum thickness concrete, with a

minimum compressive strength of 3000 psi. (Reinforced steel bar optional). This lift must be installed

on a solid level concrete floor with no more than 3 degrees of slope. Failure to do so could cause

personal injury or death.

DO NOT install this lift on any asphalt surface or any surface other than concrete.

DO NOT install this lift on expansion seams or on cracked or defective concrete.

DO NOT install this lift on a second / elevated floor without first consulting building architect.

DO NOT install this lift outdoors.
