( INSTALLATION OF MOTORCYCLE ADAPTERS* )

1. Lower the lift all the way to the ground.
2. Swivel both arms towards the center line of the lift until they are parallel.
3. Fully extend both arms. (See figure 25)
4. Align the motorcycle adapters and lower onto the lift arms. Ensure it rests firmly on top of the lift arms.
Place the adapter buttons thru the motorcycle adapter into the lift arm holes. (See figure 26)
5. Disconnect the cylinder hose from the flow control valve opposite the side you are using for the
motorcycle adapter.
*Motorcycle Adapter is an optional accessory.
Fig. 26
FOR TECHNICAL QUESTIONS, CALL (877)432-6627
STEP 15
Arms Parallel
Arms Extend
Adapter Button
Fig. 25
