Parts Inventory - Dannmar maxjax User Manual

When removing the lift from shipping angles pay close attention as the posts can slide and can cause
injury. Prior to removing the bolts make sure the posts are held securely by a fork lift or some other heavy
lifting devise.
Be sure to take a complete inventory of parts prior to beginning installation.
PART # QTY
17200017 10
17202012 10
17207011 10
N/A 1
17206015 2
17206014 2
17156002 1
17156001 2
17206020 2
17206018 2
17206019 2
17206017 1
17206016 1
17200029 4
17200005 4
17200029 4
17201010 12
17207033 12
17207038 4
17207040 4
17200021 4
17201017 4
17207015 1
17158007 2
17207012 2
17158010 4
17157003 2
17207037 1
17107006 4
17108041 4
17157002 4
17157001 2
17157007 1
8

PARTS INVENTORY

PARTS BAG
5/8" x 2" Hex Bolt For Anchors
5/8" x 11 Power Drop Recess Anchors
5/8-11 X 4" Anchor Set Bolt
Male Quick-Disconnect Fitting
Female Quick-Disconnect Fitting
Max Jax Hydraulic Hose Assembly Ø10 X 280mm
Max Jax Hydraulic Hose Assembly Ø10 X 4520mm
Pipe Reducer (3/8" Npt Female - 1/4" Npt Male)
45-Degree Pipe Fitting (3/8" Npt Female - 3/8" Npt Male)
Long 3/8" NPT - 3/8" JIC 90-Degree Fitting
Long 90-Degree 3/8" x 3/8" O-Ring Fitting
M8 X 1.25mm Hex Bolt ( Power Unit Bolts )
M8 X 25mm Hex Bolts (For Flow Divider)
Hex Head Bolt M8 X 55mm (For Column Wheels)
25mm C-Washers / Floor Mounting Shims
M10 X 45 Hex Head Bolt (For Column Top Straps)
M10 Nylon Lock Nut (For Column Top Straps)
Rubber Power Unit Dampener Pad
127mm Wheels For Power Unit Cart
Retainers for Power Unit Cart Wheels
75mm Wheels For Columns
PARTS BOX
OPTIONAL MOTORCYCLE ADAPTER KIT
VISIT US ON THE WEB AT WWW.DANNMAR.COM
DANGER
DESCRIPTION
5/8" Flat Washers
3/8" x 3/8" Pipe Nipple
M8 Nylon Hex Nuts
"C" Retainer Clips for Arms
Pull Rings for Arm Pins
Column Top Straps
Flow Divider
Contact Lift Pads
Stackable Pad Adapters
Arm Pins
Lock Bars
Adapter Frame Assembly
