Transport Data Logger | TDL 110

3.5 Accuracies

Attribute
Temperature:
Humidity:
Acceleration/Shock:

Table 4: Accuracies

4 Mounting the TDL

The TDL comes with an integrated mounting plate at the bottom side. The mounting plate
provides four mounting holes for screw fastening purposes.
3

Figure 2: Mounting the TDL using screws

1 Screwdriver
2 Screw
3 Mounting holes
In general, the TDL can be mounted in any position as required. The fastening, depending on
the specific requirements, can be carried out with screws or with double-sided adhesive tape.
In case shock shall be measured a direct and non-absorbing connection between the TDL
and the monitored good is required. For achieving this we recommend using either screws
or a fiber-reinforced adhesive tape. Recommended screws are either M5 countersunk head
or M4 carriage bolt.
Value
± 0.5 °C (0 °C ... +60 °C)
± 1 °C (-25 °C ... +80 °C)
± 5 % rH typical
± 10 % rH maximum
(20 % rH ... 80% rH at 25 °C)
± 10 %
1
2
3
8 | 21
