Transport Data Logger | TDL 110
8. Enter your desired PIN and confirm.
Notice
You cannot configure the TDL without a valid PIN. It is impossible to
reset the PIN; even at the factory.
▶ Always make a note of the PIN and store it in a safe place.
9. To start logging immediately, tap "Start logging" and confirm that
logging will start only when the TDL device is disconnected. The device
confirms logging start by flashing three times the green LED. To start
logging later, tap "Disconnect" in the app. The device confirms the
disconnection by flashing three times the red LED.
Then press t he button on the TDL for 2 to 5 seconds when you want
to start logging. The TDL blinks green three times to confirm that
logging has started.
INFO
The measurement starts immediately after you tap on "Start logging".
The TDL uses its current position as a reference for the tilt measure-
ment.
If you configure the TDL in a different position to its final mounting posi-
tion we suggest to tap "Disconnect" in the app and activate the TDL later
in its final mounting position with a button press of 2 to 5 seconds.

Figure 6: Enter the PIN

No TDL Access!

Figure 7: Start logging

Figure 8: Delayed logging start

11 | 21
