Transport Data Logger | TDL 110

5.4 Reading and Transferring Data

5.4.1 Reading the Data

1. Connect your smartphone to a configured TDL.
Overview Screen
This screen provides an overview of the four parameters, showing you at a glance
if any violations have occurred during the logging period. Green check marks indi-
cate that no violation has occurred, whereas an exclamation mark indicates that
the limit values have been exceeded at least once during the logging period. If an
icon is shown grayed out, no limit value has been defined for this parameter.
2. Tap "Download Details".
3. Confirm "Stop logging & download".
4. Enter your PIN.
Notice
An interrupted connection can cause damage to data.
▶ Do not lock your phone while downloading data.
5. Tap "Show Details". The summary screen appears.
6. Tap the desired measurement parameter to view those mea-
surements.
7. Tap an entry date for more detailed information.
Risk of Data Loss
