Transport Data Logger | TDL 110

1 Introduction and Intended Use

By being attached to the shipment and measuring and recording relevant parameters like
temperature, humidity, tilt and shock, the TDL makes the delivery process of goods visible
and traceable. These measurements are then documented and visualized through a mobile
application. Since the limits of each parameter can be individually configured, any violation
of these limits is traceable and clearly assignable to the stations throughout the entire trans-
port process.
The Transport Data Logger is designed according to the information provided in the data
sheet. Any use or operation which requires specific requirements and standards which aren't
explicitly mentioned in the data sheet must be validated and tested on customer's own re-
sponsibility.
6
5

Figure 1: Overview TDL

1 Surface: place your shipment code here
2 Button (see chapter
3 LED (green/red) (see chapter
4 Mounting holes (4x) (see chapter
5 Battery (see chapter 6.1 Changing the
6 Mounting plate (see
For further assistance please refer to:
support@bosch-connectivity.com
5 Operation)
5.5 Blinking
4 Mounting the
Battery)
chapter 4 Mounting the
http://www.bosch-connectivity.com/TDL110
Pattern)
TDL)
TDL)
5 | 21
1
2
3
4
or e-mail to:
