UG287: EFM32 Giant Gecko GG11 Starter Kit User's Guide

Advanced Energy Monitor

7.4 Accuracy and Performance

The Advanced Energy Monitor is capable of measuring currents in the range of 0.1 µA to 95 mA. For currents above 250 µA, the AEM

is accurate within 0.1 mA. When measuring currents below 250 µA, the accuracy increases to 1 µA. Even though the absolute accuracy

is 1 µA in the sub 250 µA range, the AEM is able to detect changes in the current consumption as small as 100 nA. The AEM produces

6250 current samples per second.

silabs.com | Building a more connected world.

Rev. 1.10 | 25
