Si106
D
X
EVELOPMENT
1. Kits Overview
This user's guide describes the development kits of the Si106x Wireless MCU family. The latest version of this user
guide is available online at http://www.silabs.com/products/wireless/wirelessmcu/Pages/default.aspx. Each kit
contains two RF nodes based on the Wireless Motherboard to support evaluation and development of sub-GHz RF
links with the different Wireless MCUs. WMCU pico board content of the different kits is listed in Table 1, and
content common to all the kits is listed in Table 2.
Table 1. WMCU Pico Boards of the Si106x Development Kits
Qty
Si1060 490 MHz Wireless MCU Development Kit
2
Si1060 915 MHz Wireless MCU Development Kit
2
Si1062 868 MHz Wireless MCU Development Kit
2
Si1064 434 MHz Wireless MCU Development Kit
2
Si1064 868 MHz Wireless MCU Development Kit
2
Si1064 915 MHz Wireless MCU Development Kit
2
Qty
2
2
2
4
1
Rev. 0.2 11/13
K
I TS
Description
Si1060 490 MHz PICO Board
Si1060 915 MHz PICO Board
Si1062 868 MHz PICO Board
Si1064 434 MHz PICO Board
Si1064 868 MHz PICO Board
Si1064 915 MHz PICO Board
Table 2. Common Kit Content
Description
Wireless Motherboard
USB cable (USBA-USB mini)
Antenna with SMA connection
AA Battery
Si106x Development Kit User's Guide
Copyright © 2013 by Silicon Laboratories
S i 1 0 6 x - D K
U
'
G
SER
S
UIDE
Part Number
1060-490-DK
1060-PCE20C490
1060-915-DK
1060-PCE20C915
1062-868-DK
1062-PCE13D868
1064-434-DK
1064-PCE10D434
1064-868-DK
1064-PCE10D868
1064-915-DK
1064-PCE10D915
Part Number
MSC-WMB912
MSC-AT50-XXX
Si106x-DK
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Silicon Laboratories Si106 Series
Summary of Contents for Silicon Laboratories Si106 Series
- Page 1 Si1064 915 MHz PICO Board 1064-PCE10D915 Table 2. Common Kit Content Description Part Number Wireless Motherboard MSC-WMB912 USB cable (USBA-USB mini) Antenna with SMA connection MSC-AT50-XXX AA Battery Si106x Development Kit User’s Guide Rev. 0.2 11/13 Copyright © 2013 by Silicon Laboratories Si106x-DK...
-
Page 2: Software Setup
Si106x-DK 2. Software Setup There are two software tools provided by Silicon Labs to aid in wireless MCU software development: the Wireless Development Suite (WDS) and the Silicon Labs Integrated Development Environment (IDE). To download and install the Silicon Labs IDE and unlimited Keil PK51 Professional Developer’s Kit, follow this link: http://pages.silabs.com/lp-keil-pk51.html. -
Page 3: Hardware Setup
Si106x-DK 3. Hardware Setup After checking the kit contents against Tables 1 and 2, the kit can be put into operation by performing the steps listed below. Figure 1. Wireless Motherboard Top Markings 1. Insert a WMCU Pico Board in connectors J5, J6, J7, J8 on the Wireless Motherboard (WMB). Align the triangle symbol on the WMCU Pico board with the triangle symbol on the WMB. - Page 4 Si106x-DK Repeat steps 1 to 9 for the other node of the kit. The two nodes are now ready for evaluation. For more details about the board's operation, see "6. The Wireless Motherboard Hardware Platform" on page 7 and "7. Board Schematics"...
- Page 5 AN692: Si4355/Si4455 Programming Guide and Sample Codes EZRadio API Documentation Available Tools: Silicon Laboratories IDE installer WDS3 installer For hardware design guidance see the following application notes: AN791: Layout Design Guide for the Si106x/8x Wireless MCUs Si1060 and Si1062: ...
- Page 6 Si106x-DK Si1064: AN686: Antennas for the Si4455/4355 RF ICs AN693: Si4455 Low-Power PA Matching For detailed information on lab measurements and data sheet parameter verification, refer to the following documents: Si1060 and Si1062: ® AN632: WDS User Guide for EZRadioPRO Devices Si1064: ...
- Page 7 Si106x-DK 6. The Wireless Motherboard Hardware Platform The wireless motherboard platform is a demo, evaluation, and development platform for EZRadio and EZRadioPRO radio ICs. It consists of a wireless motherboard and interchangeable MCU and RF pico boards. Figure 2. 8-Bit Wireless Motherboard Platform Rev.
- Page 8 Si106x-DK 6.1. The Wireless Motherboard MCU Pico Board RF Pico Board Communication Current and Debug Measurement Interface Pins External Power Supply Radio Connection Test Sensor Pins Module Connector Power Supply Switch Radio GPIO MCU DC/DC Connectors Converter Switch MCU Test Pins Potentiometer Push Buttons...
- Page 9 Si106x-DK 6.2. Power Scheme The power source of the platform can be selected with the “SUPPLY SELECT” power supply selector switch on the WMB board. If this switch is in the “USB” position, supply voltage is provided by the PC that is connected to the “J16”...
- Page 10 Si106x-DK Table 4 lists the functions and connections of the WMCU GPIOs. Primary functions are factory-connected on the WMB. Secondary functions can be connected by desoldering a 0 resistor that connects the primary function and soldering in to the proper position to connect the secondary function. Because of the limited number of MCU GPIOs of the WMCU, LEDs and pushbutton switches are connected to the EBID MCU of the WMB912 and can be accessed via the SMBUS on P1.4 and P1.5 of the WMCU.
-
Page 11: Board Schematics
Si106x-DK 7. Board Schematics The complete design pack of all WMCU Pico boards and all WMBs can be found at www.silabs.com. Rev. 0.2... - Page 12 Si106x-DK Rev. 0.2...
- Page 13 Si106x-DK Rev. 0.2...
- Page 14 Si106x-DK Rev. 0.2...
- Page 15 Si106x-DK Rev. 0.2...
- Page 16 The products must not be used within any Life Support System without the specific written consent of Silicon Laboratories. A "Life Support System" is any product or system intended to support or sustain life and/or health, which, if it fails, can be reasonably expected to result in significant personal injury or death.
