Precise Instrument DAT 400 Technical Manual page 47

Addr. of Modbus register
41001-41002
41003
41004
41005-41006
41007-41008
41101
41102
41103-41104
41105
41106
41201
41202-41203
41204
41205
41206
41207-41208
41209
41210
41401-41402
41403
41404
TABLE F - WEIGHT SETPOINT OPERATION CODING
bit
0...1 0 = Net weight, 1 = Gross weight, 2 = Peak
2
3 0 = Positive values 1 = Negative values
4 0 = Always controlled 1 = Only with stable weight
EXAMPLE: CALIBRATION FUNCTION VIA MODBUS
To perform the calibration of full scale (that require the weight value in the sample set in the data register),
the value in the data register must be present when the command register is programmed. For example:
Calibrate the full scale using a sample weight of 2000 kg.
Write 2000 in the data register.
Write 0x0011 in the command register.
Use the multiple registers write function and write the registers of data register and command register
in a single command.
Data stored in memory with the 0x0020 command
Cells capacity
Cells sensitivity
Weight division value
Tare of the system
System capacity
Weight filter
Weight stability
Auto-zero setpoint
Zero tracking
Zero band in divisions
Operation mode Set 1
Hysteresis Set 1
Timer Set 1
Delay Set 1
Operation mode Set 2
Hysteresis Set 2
Timer Set 2
Delay Set 2
Analog full scale
Analog mode
Analog range
Setpoint operation mode
0 = N.O. 1 = N:C.
Page 45
