GENERAL DATA
All functions of the DAT 400 are activated and modified by accessing a simple setup menu, shown on
page 21. All settings selected or activated remain stored even after switching off the transmitter.
The DAT 400 is preconfigured with a default setting. The following pages show the values of "Default"
for each parameter.
With the first on-site installation, it's necessary to change some parameters in order to obtain a correct
indication of the displayed weight (Theoretical adjustment).
The settings of the setup menu can be changed using the front keys or via the utility "INOVATION 2"
software supplied.
CHANGING AND ENTERING THE PARAMETERS:
The setup parameters are grouped into a number of main menus.
To access the setup menu press the PRG key and then the SET key and hold down simultaneously for
3 seconds.
The display shows the message Conf1G that is the first of the main menus.
Use the arrow keys to select the menu you want to change.
Press the PRG key to access the selected menu.
KEY FUNCTION DURING THE MAIN MENU PROGRAMMING
SET
It selects the next menu.
FUN
It selects the previous menu.
0
It exits the programming menu or returns to the upper level.
It accesses the corresponding sub-menu or programming or confirms the selected
PRG
parameter.
KEY FUNCTION WHEN SETTING THE NUMERICAL VALUES
SET
It increases the value of the flashing digit.
FUN
It decreases the value of the flashing digit.
0
It goes to the next digit.
PRG
It confirms and store the displayed value.
