The instrument is programmed and controlled through the keyboard which has 4 keys, with double
functions. The selection of one of the key functions is established automatically by the instrument accor-
ding to the operation in progress. In general, the management of the programming menus is done by
using the SET and FUN keys to scroll through the items; the PRG key is used to enter its sub-menu or
programmable parameter, while the 0 button allows you exiting the menu or returning to the top level.
KEY FUNCTIONS DURING THE WEIGHT DISPLAY
SET
Access to the menu for the programming of the setpoints
Select the display view (gross weight, net weight).
FUN
(Long press) Selection of the weight/peak display
Resetting the displayed value (gross weight, net weight or peak).
0
(Press and hold for 5 sec.) Calibration of zero, to be executed only if its function
is enabled in the PARAM menu (see item "0 ALL").
Sending the weight string on the serial line.
PRG
(Long press) Access to the quick set-up menu.
PRG SET
(Press for 3 sec) Access to the setup menu.
+
(Press for3 sec) It accesses the keypad lock/unlock menu and auto-off function of
PRG 0
the display.
+
KEY FUNCTION DURING THE MAIN MENU DISPLAY
SET
It selects the next parameter.
FUN
It selects the previous parameter.
0
It exits the programming menu or returns to the upper level.
It accesses the corresponding sub-menu or programming or confirms the selected
PRG
parameter.
KEY FUNCTION WHEN SETTING THE NUMERICAL VALUES
SET
It increases the value of the flashing digit.
FUN
It decreases the value of the flashing digit.
0
It goes to the next digit.
PRG
It confirms the displayed value.

USING THE KEYBOARD

Page 11
