Vertex Standard VXR-9000EV Service Manual page 68

REG Unit
Parts Layout
Parts List
REF DESCRIPTION
PCB with Components
Printed Circuit Board
C 3901 CHIP TA.CAP.
C 3902 CHIP CAP.
C 3903 CHIP TA.CAP.
C 3904 CHIP CAP.
C 3905 CHIP CAP.
C 3906 CHIP TA.CAP.
C 3907 CHIP CAP.
C 3908 CHIP TA.CAP.
P 3901 WIRE ASSY
Q 3901 IC
Q 3902 IC
L-2
Side A
Side B
VALUE V/W TOL.
4.7uF 16V
0.001uF 50V B
4.7uF 16V
0.001uF 50V B
0.001uF 50V B
4.7uF 16V
0.001uF 50V B
4.7uF 16V
KIA7809API
(Q3901, 3902)
MFR'S DESIG VXSTD P/N
CB2566001
FR0108700
TEMSVA1C475M-8R K78120031
GRM39B102K50PT K22174821
TEMSVA1C475M-8R K78120031
GRM39B102K50PT K22174821
GRM39B102K50PT K22174821
TEMSVA1C475M-8R K78120031
GRM39B102K50PT K22174821
TEMSVA1C475M-8R K78120031
AC044N/U T9207048
KIA7809API G1093165
KIA7805API G1093163
VERS. LOT SIDE LAY ADR
1-
1- A
1- A
1- A
1- A
1- A
1- A
1- A
1- A
1-
1- B
1- B
