Vertex Standard VXR-9000EV Service Manual page 33

REF DESCRIPTION
R 1225 CHIP RES.
R 1226 CHIP RES.
R 1227 CHIP RES.
R 1228 CHIP RES.
R 1229 CHIP RES.
R 1230 CHIP RES.
R 1231 CHIP RES.
R 1232 CHIP RES.
R 1233 CHIP RES.
R 1234 CHIP RES.
R 1235 CHIP RES.
R 1236 CHIP RES.
R 1237 CHIP RES.
R 1238 CHIP RES.
R 1239 CHIP RES.
R 1240 CHIP RES.
R 1241 CHIP RES.
R 1242 CHIP RES.
R 1243 CHIP RES.
R 1244 CHIP RES.
R 1245 CHIP RES.
R 1246 CHIP RES.
R 1247 CHIP RES.
R 1248 CHIP RES.
R 1249 CHIP RES.
R 1250 CHIP RES.
R 1251 CHIP RES.
R 1252 CHIP RES.
R 1253 CHIP RES.
R 1254 CHIP RES.
R 1255 CHIP RES.
R 1256 CHIP RES.
R 1257 CHIP RES.
R 1258 CHIP RES.
R 1259 CHIP RES.
R 1260 CHIP RES.
R 1261 CHIP RES.
R 1262 CHIP RES.
R 1263 CHIP RES.
R 1265 CHIP RES.
R 1266 CHIP RES.
R 1267 CHIP RES.
R 1268 CHIP RES.
R 1269 CHIP RES.
R 1270 CHIP RES.
R 1271 CHIP RES.
R 1272 CHIP RES.
R 1273 CHIP RES.
R 1274 CHIP RES.
R 1276 CHIP RES.
R 1277 CHIP RES.
R 1278 CHIP RES.
R 1279 CHIP RES.
R 1280 CHIP RES.
R 1281 CHIP RES.
R 1282 CHIP RES.
R 1283 CHIP RES.
R 1284 CHIP RES.
R 1285 CHIP RES.
R 1286 CHIP RES.
R 1287 CHIP RES.
R 1290 CHIP RES.
R 1292 CHIP RES.
R 1293 CHIP RES.
R 1294 CHIP RES.
R 1295 CHIP RES.
R 1296 CHIP RES.
R 1298 CHIP RES.
R 1299 CHIP RES.
R 1300 CHIP RES.
R 1301 CHIP RES.
R 1302 CHIP RES.
R 1303 CHIP RES.
VALUE V/W TOL.
47k 1/16W 5%
560 1/16W 5%
180 1/16W 5%
18 1/16W 5%
0 1/16W 5%
100 1/16W 5%
100 1/16W 5%
0 1/16W 5%
10k 1/16W 5%
220k 1/16W 1%
220k 1/16W 1%
1.8k 1/16W 5%
47k 1/16W 5%
47k 1/16W 5%
47k 1/16W 5%
47k 1/16W 5%
4.7k 1/16W 5%
4.7k 1/16W 5%
6.8k 1/16W 5%
15k 1/16W 5%
0 1/16W 5%
4.7k 1/16W 5%
10k 1/16W 5%
10k 1/16W 5%
2.7k 1/16W 5%
10k 1/16W 5%
220 1/16W 5%
22 1/16W 5%
18k 1/16W 5%
12k 1/16W 5%
220 1/16W 5%
4.7k 1/16W 5%
47k 1/16W 5%
33k 1/16W 5%
56 1/16W 5%
100k 1/16W 5%
2.2k 1/16W 5%
10 1/16W 5%
10k 1/16W 5%
220 1/16W 5%
2.2k 1/16W 1%
100k 1/16W 5%
1.8k 1/16W 1%
100k 1/16W 5%
0 1/16W 5%
180 1/16W 5%
18 1/16W 5%
100 1/16W 5%
33k 1/16W 5%
10k 1/16W 5%
1k 1/16W 5%
100k 1/16W 5%
10k 1/16W 5%
0 1/16W 5%
15k 1/16W 5%
0 1/16W 5%
0 1/16W 5%
0 1/16W 5%
0 1/16W 5%
0 1/16W 5%
47 1/16W 5%
1k 1/16W 5%
10k 1/16W 5%
0 1/16W 5%
2.7 1/10W 5%
100 1/16W 5%
10k 1/16W 5%
4.7 1W 5%
4.7 1W 5%
100k 1/16W 5%
1k 1/16W 5%
1k 1/16W 5%
1k 1/16W 5%
MFR'S DESIG VXSTD P/N
RMC1/16 473JATP J24185473
RMC1/16 561JATP J24185561
RMC1/16 181JATP J24185181
RMC1/16 180JATP J24185180
RMC1/16 000JATP J24185000
RMC1/16 101JATP J24185101
RMC1/16 101JATP J24185101
RMC1/16 000JATP J24185000
RMC1/16 103JATP J24185103
RMC1/16 224FTP J24183224
RMC1/16 224FTP J24183224
RMC1/16 182JATP J24185182
RMC1/16 473JATP J24185473
RMC1/16 473JATP J24185473
RMC1/16 473JATP J24185473
RMC1/16 473JATP J24185473
RMC1/16 472JATP J24185472
RMC1/16 472JATP J24185472
RMC1/16 682JATP J24185682
RMC1/16 153JATP J24185153
RMC1/16 000JATP J24185000
RMC1/16 472JATP J24185472
RMC1/16 103JATP J24185103
RMC1/16 103JATP J24185103
RMC1/16 272JATP J24185272
RMC1/16 103JATP J24185103
RMC1/16 221JATP J24185221
RMC1/16 220JATP J24185220
RMC1/16 183JATP J24185183
RMC1/16 123JATP J24185123
RMC1/16 221JATP J24185221
RMC1/16 472JATP J24185472
RMC1/16 473JATP J24185473
RMC1/16 333JATP J24185333
RMC1/16 560JATP J24185560
RMC1/16 104JATP J24185104
RMC1/16 222JATP J24185222
RMC1/16 100JATP J24185100
RMC1/16 103JATP J24185103
RMC1/16 221JATP J24185221
RMC1/16 222FTP J24183222
RMC1/16 104JATP J24185104
RMC1/16 182FTP J24183182
RMC1/16 104JATP J24185104
RMC1/16 000JATP J24185000
RMC1/16 181JATP J24185181
RMC1/16 180JATP J24185180
RMC1/16 101JATP J24185101
RMC1/16 333JATP J24185333
RMC1/16 103JATP J24185103
RMC1/16 102JATP J24185102
RMC1/16 104JATP J24185104
RMC1/16 103JATP J24185103
RMC1/16 000JATP J24185000
RMC1/16 153JATP J24185153
RMC1/16 000JATP J24185000
RMC1/16 000JATP J24185000
RMC1/16 000JATP J24185000
RMC1/16 000JATP J24185000
RMC1/16 000JATP J24185000
RMC1/16 470JATP J24185470
RMC1/16 102JATP J24185102
RMC1/16 103JATP J24185103
RMC1/16 000JATP J24185000
RMC1/10T 2R7J J24205279
RMC1/16 101JATP J24185101
RMC1/16 103JATP J24185103
RMC1 4R7JTE J24305479
RMC1 4R7JTE J24305479
RMC1/16 104JATP J24185104
RMC1/16 102JATP J24185102
RMC1/16 102JATP J24185102
RMC1/16 102JATP J24185102
MAIN Unit
Parts List
VERS. LOT SIDE LAY ADR
1- B f4
1- A F2
1- A F4
1- A F4
1- B b2
1- B b2
1- B b2
1- B a2
1- B g4
1- A G1
1- A G1
1- A F2
1- B g5
1- B g4
1- B g4
1- B g4
1- B b2
1- B a2
1- A F2
1- A A1
1- B b2
1- B g4
1- B b2
1- B a2
1- B g4
1- A G1
1- A A1
1- A A1
1- A G2
1- A G1
1- A A1
1- A F2
1- A A4
1- A A4
1- A G2
1- A A3
1- A E2
1- A E2
1- A F2
1- A G2
1- A B4
1- A F2
1- A A3
1- A A4
1- A G3
1- A F3
1- A F3
1- B a3
1- A F2
1- A C1
1- A C2
1- A F5
1- B d5
1- A G2
1- B f3
1- B f3
1- A G2
1- A A3
1- B f3
1- B f3
1- B a2
1- B b2
1- B b2
1- B b2
1- B g3
1- A F4
1- B f2
1- B g4
1- B g4
1- B a2
1- A G2
1- A G2
1- A G2
H-15
