Vertex Standard VXR-9000EV Service Manual page 30

MAIN Unit
Parts List
REF DESCRIPTION
Q 1040 IC
Q 1041 TRANSISTOR
Q 1042 TRANSISTOR
Q 1043 TRANSISTOR
Q 1044 TRANSISTOR
Q 1045 TRANSISTOR
Q 1046 TRANSISTOR
Q 1047 TRANSISTOR
Q 1048 FET
Q 1049 TRANSISTOR
Q 1050 IC
Q 1051 TRANSISTOR
Q 1052 IC
Q 1053 FET
Q 1054 TRANSISTOR
Q 1055 IC
Q 1056 IC
Q 1057 IC
Q 1058 TRANSISTOR
Q 1059 TRANSISTOR
Q 1060 TRANSISTOR
Q 1061 TRANSISTOR
Q 1062 IC
Q 1063 TRANSISTOR
Q 1064 IC
Q 1501 TRANSISTOR
Q 1502 TRANSISTOR
Q 1503 TRANSISTOR
Q 1504 TRANSISTOR
R 1001 CHIP RES.
R 1002 CHIP RES.
R 1003 CHIP RES.
R 1004 CHIP RES.
R 1005 CHIP RES.
R 1007 CHIP RES.
R 1009 CHIP RES.
R 1010 CHIP RES.
R 1011 CHIP RES.
R 1013 CHIP RES.
R 1014 CHIP RES.
R 1016 CHIP RES.
R 1017 CHIP RES.
R 1019 CHIP RES.
R 1020 CHIP RES.
R 1022 CHIP RES.
R 1023 CHIP RES.
R 1024 CHIP RES.
R 1025 CHIP RES.
R 1027 CHIP RES.
R 1029 CHIP RES.
R 1030 CHIP RES.
R 1031 CHIP RES.
R 1032 CHIP RES.
R 1033 CHIP RES.
R 1034 CHIP RES.
R 1036 CHIP RES.
R 1037 CHIP RES.
R 1040 CHIP RES.
R 1041 CHIP RES.
R 1042 CHIP RES.
R 1045 CHIP RES.
R 1046 CHIP RES.
R 1047 CHIP RES.
R 1049 CHIP RES.
R 1050 CHIP RES.
R 1052 CHIP RES.
R 1053 CHIP RES.
R 1055 CHIP RES.
R 1056 CHIP RES.
R 1057 CHIP RES.
R 1061 CHIP RES.
R 1062 CHIP RES.
R 1063 CHIP RES.
H-12
VALUE V/W TOL.
10k 1/16W 5%
100 1/16W 5%
150 1W 5%
100k 1/16W 5%
39k 1/16W 5%
150 1W 5%
27k 1/16W 5%
10k 1/16W 1%
10k 1/16W 1%
100k 1/16W 5%
3.3k 1/16W 5%
8.2k 1/16W 5%
100k 1/16W 5%
1k 1/16W 5%
680 1/16W 5%
8.2k 1/16W 5%
0 1/16W 5%
100k 1/16W 5%
10k 1/16W 5%
120k 1/16W 1%
47k 1/16W 5%
47 1/16W 5%
100k 1/16W 5%
120k 1/16W 1%
18k 1/16W 5%
12k 1/16W 5%
33k 1/16W 5%
6.8k 1/16W 5%
220 1/16W 5%
56 1/16W 5%
0 1/16W 5%
0 1/16W 5%
10k 1/16W 5%
33k 1/16W 5%
10k 1/16W 5%
150k 1/16W 5%
1k 1/16W 5%
1k 1/16W 5%
47k 1/16W 5%
39k 1/16W 5%
1k 1/16W 5%
33k 1/16W 5%
100k 1/16W 5%
0 1/16W 5%
MFR'S DESIG VXSTD P/N
BU4066BCFV-E2 G1093537
2SA1162GR TE85R G3111627G
2SC2712GR TE85R G3327127G
DTC144EK T146 G3070033
FMG2 T148 G3070015
2SC4116GR TE85R G3341167G
2SC4116GR TE85R G3341167G
UN5215-(TX) G3070193
2SK520-T2B K41 G3805207A
RT1N241M-T11-1 G3070249
NJM2904V-TE1 G1091677
2SA1586Y TE85R G3115867Y
MB15A02PFV1-G-BND-EF G1092541
2SK520-T2B K41 G3805207A
RT1N241M-T11-1 G3070249
M62364FP 600D G1093033
M51132FP 600C G1091930
TDA2003 G1090769
2SC4116GR TE85R G3341167G
2SC5226-4/5-TL G3352268Z
DTC144EE TL G3070075
2SC4116GR TE85R G3341167G
L78M05T-TL G1091731
2SC3356-T2B R25 G3333567E
TA75S01F TE85R G1091593
XN1213-(TX) G3070194
2SC5226-4/5-TL G3352268Z
XN1213-(TX) G3070194
2SC4116GR TE85R G3341167G
RMC1/16 103JATP J24185103
RMC1/16 101JATP J24185101
RMC1 151JTE J24305151
RMC1/16 104JATP J24185104
RMC1/16 393JATP J24185393
RMC1 151JTE J24305151
RMC1/16 273JATP J24185273
RMC1/16 103FTP J24183103
RMC1/16 103FTP J24183103
RMC1/16 104JATP J24185104
RMC1/16 332JATP J24185332
RMC1/16 822JATP J24185822
RMC1/16 104JATP J24185104
RMC1/16 102JATP J24185102
RMC1/16 681JATP J24185681
RMC1/16 822JATP J24185822
RMC1/16 000JATP J24185000
RMC1/16 104JATP J24185104
RMC1/16 103JATP J24185103
RMC1/16 124FTP J24183124
RMC1/16 473JATP J24185473
RMC1/16 470JATP J24185470
RMC1/16 104JATP J24185104
RMC1/16 124FTP J24183124
RMC1/16 183JATP J24185183
RMC1/16 123JATP J24185123
RMC1/16 333JATP J24185333
RMC1/16 682JATP J24185682
RMC1/16 221JATP J24185221
RMC1/16 560JATP J24185560
RMC1/16 000JATP J24185000
RMC1/16 000JATP J24185000
RMC1/16 103JATP J24185103
RMC1/16 333JATP J24185333
RMC1/16 103JATP J24185103
RMC1/16 154JATP J24185154
RMC1/16 102JATP J24185102
RMC1/16 102JATP J24185102
RMC1/16 473JATP J24185473
RMC1/16 393JATP J24185393
RMC1/16 102JATP J24185102
RMC1/16 333JATP J24185333
RMC1/16 104JATP J24185104
RMC1/16 000JATP J24185000
VERS. LOT SIDE LAY ADR
1- B g4
1- B b2
1- B b2
1- B g4
1- B g5
1- A G2
1- A F2
1- A F2
1- A G4
1- B a4
1- A A4
1- A F2
1- A G2
1- A G3
1- B a3
1- B f3
1- A B4
1- A A3
1- B b2
1- A F4
1- B b2
1- A E2
1- B d4
1- A F5
1- B c5
1- B c2
1- B c2
1- A E2
1- B c2
1- B a5
1- B a5
1- B e3
1- A D4
1- B e3
1- B e3
1- B e3
1- A C4
1- A C3
1- A D3
1- B e4
1- A D4
1- B e3
1- B d5
1- B d5
1- B d3
1- A C5
1- A D4
1- A C3
1- A D5
1- A D4
1- A C3
1- A D3
1- A D5
1- A C3
1- A C3
1- A C4
1- B d4
1- A C3
1- A C3
1- A C3
1- A C3
1- B d4
1- A C4
1- A D5
1- A C5
1- A C2
1- A C2
1- A D5
1- B e5
1- A C3
1- B e3
1- B e3
1- B f2
