Vertex Standard VXR-9000EV Service Manual page 54

PANEL Unit
Parts Layout (Side B)
a
1
2
3
4
BU4094BCFV BU4066BCFV
(Q4003, 4011, 4014) (Q4008)
NJM2902V
(Q4001)
J-4
b c
DTC144EE (26) DTC323TK (H02) XN1213 (9L)
(Q4004, 4012) (Q4002) (Q4005, 4007, 4009,
4010, 4013, 4015,
4016, 4017, 4018,
4019, 4020, 4021,
4022)
d e f
MC2850 (A7)
(D4006, 4011, 4013,
4015, 4016, 4019)
