Vertex Standard VXR-9000EV Service Manual page 39

A B
1
2
3
4
2SB1201S LA8630M
(Q3004, 3055) (Q3034)
C D
BU4066BCFV NJM12903R NJM2904V
(Q3032, 3033) (Q3043) (Q3035, 3041)
NJM2902V TC4W53FU
(Q3001, 3021, 3044) (Q3058)
E F
2SC4116GR (LG) DTA144EE (16) DTC144EE (26)
(Q3025) (Q3026) (Q3028, 3029, 3037,
3040, 3050, 3056,
2SC4154 (LE)
3057, 3060)
(Q3042)
TC4S66F (C9) TC4S81F (C2)
(Q3064) (Q3061)
CNTL Unit
Parts Layout (Side A)
G H I
DTC323TK (H02) FMG2 (G2) TA75S01F (SA)
(Q3015) (Q3024, 3062, 3063) (Q3016, 3036, 3059)
02CZ3.6Z (36Z) DA204K (K) MC2848 (A6)
(D3021) (D3022) (D3020, 3029)
MC2850 (A7)
(D3018, 3019)
I-3
