Pa Unit - Vertex Standard VXR-9000EV Service Manual

REF DESCRIPTION
R 7037 CHIP RES.
R 7038 CHIP RES.
R 7039 CHIP RES.
R 7040 CHIP RES.
R 7041 CEMENT RES.
R 7043 CHIP RES.
R 7044 CHIP RES.
R 7045 CHIP RES.
R 7046 CHIP RES.
R 7047 CHIP RES.
R 7048 CHIP RES.
R 7049 CHIP RES.
RL7001 RELAY
S 7001 SLIDE SWITCH
TH7001 THERMISTOR
TH7002 THERMISTOR
SHIELD CASE
SHIELD PLATE
TERMINAL
TERMINAL
BINDING HEAD SCREW
BINDING HEAD SCREW
VALUE V/W TOL.
150k 1/16W 5%
22k 1/16W 5%
22 1/10W 5%
47k 1/16W 5%
5.6 5W 10%
10k 1/16W 5%
2.2k 1/16W 5%
2.2k 1/16W 5%
0 1/16W 5%
0 1/16W 5%
0 1/16W 5%
0 1/16W 5%
DC12V
MFR'S DESIG VXSTD P/N
RMC1/16 154JATP J24185154
RMC1/16 223JATP J24185223
RMC1/10T 220J J24205220
RMC1/16 473JATP J24185473
ERF-5AK5R6 J30376569
RMC1/16 103JATP J24185103
RMC1/16 222JATP J24185222
RMC1/16 222JATP J24185222
RMC1/16 000JATP J24185000
RMC1/16 000JATP J24185000
RMC1/16 000JATP J24185000
RMC1/16 000JATP J24185000
ACP131 DC12V M1190152
SSSS912N-2A-OR N6090094
157-203-55009TP G9090045
157-502-53002TP G9090049
RA0638000
PA R0124501
B4 AG M3 Q6000114
B4 AG M3 Q6000114
M3X10NI U20310002
M3X10NI U20310002
25W PA Unit
Parts List
VERS. LOT SIDE LAY ADR
1- A F4
1- A F4
1- A F4
1- A G1
1- A E5
1- A D3
1- A A4
1- A A3
1- A D3
1- A D3
1- A D3
1- A D3
1- A F5
1- A F4
1- A E5
1- A D2
1-
1-
1-
1-
1-
1-
K-7
