Vertex Standard VXR-9000EV Service Manual page 47

REF DESCRIPTION
R 3097 CHIP RES.
R 3098 CHIP RES.
R 3099 CHIP RES.
R 3100 CHIP RES.
R 3101 CHIP RES.
R 3102 CHIP RES.
R 3103 CHIP RES.
R 3104 CHIP RES.
R 3105 CHIP RES.
R 3106 CHIP RES.
R 3107 CHIP RES.
R 3109 CHIP RES.
R 3110 CHIP RES.
R 3111 CHIP RES.
R 3112 CHIP RES.
R 3113 CHIP RES.
R 3114 CHIP RES.
R 3115 CHIP RES.
R 3117 CHIP RES.
R 3118 CHIP RES.
R 3119 CHIP RES.
R 3120 CHIP RES.
R 3121 CHIP RES.
R 3122 CHIP RES.
R 3123 CHIP RES.
R 3124 CHIP RES.
R 3125 CHIP RES.
R 3127 CHIP RES.
R 3128 CHIP RES.
R 3129 CHIP RES.
R 3130 CHIP RES.
R 3131 CHIP RES.
R 3133 CHIP RES.
R 3135 CHIP RES.
R 3136 CHIP RES.
R 3137 CHIP RES.
R 3138 CHIP RES.
R 3139 CHIP RES.
R 3140 CHIP RES.
R 3141 CHIP RES.
R 3142 CHIP RES.
R 3143 CHIP RES.
R 3144 CHIP RES.
R 3145 CHIP RES.
R 3146 CHIP RES.
R 3147 CHIP RES.
R 3150 CHIP RES.
R 3151 CHIP RES.
R 3152 CHIP RES.
R 3153 CHIP RES.
R 3154 CHIP RES.
R 3155 CHIP RES.
R 3157 CHIP RES.
R 3158 CHIP RES.
R 3161 CHIP RES.
R 3162 CHIP RES.
R 3163 CHIP RES.
R 3164 CHIP RES.
R 3165 CHIP RES.
R 3166 CHIP RES.
R 3168 CHIP RES.
R 3169 CHIP RES.
R 3170 CHIP RES.
R 3171 CHIP RES.
R 3172 CHIP RES.
R 3173 CHIP RES.
R 3174 CHIP RES.
R 3175 CHIP RES.
R 3176 CHIP RES.
R 3178 CHIP RES.
R 3179 CHIP RES.
R 3180 CHIP RES.
R 3181 CHIP RES.
VALUE V/W TOL.
150k 1/16W 5%
100k 1/16W 5%
22k 1/16W 5%
270k 1/16W 5%
100k 1/16W 5%
100k 1/16W 5%
10k 1/16W 5%
8.2k 1/16W 5%
47k 1/16W 5%
6.8k 1/16W 5%
100k 1/16W 5%
5.6k 1/16W 5%
5.6k 1/16W 5%
100k 1/16W 5%
1k 1/16W 5%
120k 1/16W 5%
33k 1/16W 5%
100k 1/16W 5%
100k 1/16W 5%
100k 1/16W 5%
1k 1/16W 5%
1k 1/16W 5%
10k 1/16W 5%
100k 1/16W 5%
47k 1/16W 5%
4.7k 1/16W 5%
100 1/16W 5%
4.7k 1/16W 5%
10k 1/16W 5%
4.7k 1/16W 5%
10k 1/16W 5%
10k 1/16W 5%
47k 1/16W 5%
47k 1/16W 5%
10k 1/16W 5%
10k 1/16W 5%
10k 1/16W 5%
10k 1/16W 5%
4.7k 1/16W 5%
47k 1/16W 5%
4.7k 1/16W 5%
1.8k 1/16W 5%
27k 1/16W 5%
27k 1/16W 5%
27k 1/16W 5%
2.2k 1/16W 5%
47k 1/16W 5%
47k 1/16W 5%
4.7k 1/16W 5%
4.7k 1/16W 5%
47k 1/16W 5%
10k 1/16W 5%
68 1/16W 5%
1M 1/16W 5%
1M 1/16W 5%
47k 1/16W 5%
6.8k 1/16W 5%
4.7k 1/16W 5%
0 1/16W 5%
0 1/16W 5%
15k 1/16W 5%
10k 1/16W 5%
39k 1/16W 5%
100k 1/16W 5%
4.7k 1/16W 5%
47k 1/16W 5%
47k 1/16W 5%
47k 1/16W 5%
8.2k 1/16W 5%
10k 1/16W 5%
0 1/16W 5%
0 1/16W 5%
1.8k 1/16W 5%
MFR'S DESIG VXSTD P/N
RMC1/16 154JATP J24185154
RMC1/16 104JATP J24185104
RMC1/16 223JATP J24185223
RMC1/16 274JATP J24185274
RMC1/16 104JATP J24185104
RMC1/16 104JATP J24185104
RMC1/16 103JATP J24185103
RMC1/16 822JATP J24185822
RMC1/16 473JATP J24185473
RMC1/16 682JATP J24185682
RMC1/16 104JATP J24185104
RMC1/16 562JATP J24185562
RMC1/16 562JATP J24185562
RMC1/16 104JATP J24185104
RMC1/16 102JATP J24185102
RMC1/16 124JATP J24185124
RMC1/16 333JATP J24185333
RMC1/16 104JATP J24185104
RMC1/16 104JATP J24185104
RMC1/16 104JATP J24185104
RMC1/16 102JATP J24185102
RMC1/16 102JATP J24185102
RMC1/16 103JATP J24185103
RMC1/16 104JATP J24185104
RMC1/16 473JATP J24185473
RMC1/16 472JATP J24185472
RMC1/16 101JATP J24185101
RMC1/16 472JATP J24185472
RMC1/16 103JATP J24185103
RMC1/16 472JATP J24185472
RMC1/16 103JATP J24185103
RMC1/16 103JATP J24185103
RMC1/16 473JATP J24185473
RMC1/16 473JATP J24185473
RMC1/16 103JATP J24185103
RMC1/16 103JATP J24185103
RMC1/16 103JATP J24185103
RMC1/16 103JATP J24185103
RMC1/16 472JATP J24185472
RMC1/16 473JATP J24185473
RMC1/16 472JATP J24185472
RMC1/16 182JATP J24185182
RMC1/16 273JATP J24185273
RMC1/16 273JATP J24185273
RMC1/16 273JATP J24185273
RMC1/16 222JATP J24185222
RMC1/16 473JATP J24185473
RMC1/16 473JATP J24185473
RMC1/16 472JATP J24185472
RMC1/16 472JATP J24185472
RMC1/16 473JATP J24185473
RMC1/16 103JATP J24185103
RMC1/16 680JATP J24185680
RMC1/16 105JATP J24185105
RMC1/16 105JATP J24185105
RMC1/16 473JATP J24185473
RMC1/16 682JATP J24185682
RMC1/16 472JATP J24185472
RMC1/16 000JATP J24185000
RMC1/16 000JATP J24185000
RMC1/16 153JATP J24185153
RMC1/16 103JATP J24185103
RMC1/16 393JATP J24185393
RMC1/16 104JATP J24185104
RMC1/16 472JATP J24185472
RMC1/16 473JATP J24185473
RMC1/16 473JATP J24185473
RMC1/16 473JATP J24185473
RMC1/16 822JATP J24185822
RMC1/16 103JATP J24185103
RMC1/16 000JATP J24185000
RMC1/16 000JATP J24185000
RMC1/16 182JATP J24185182
CNTL Unit
Parts List
VERS. LOT SIDE LAY ADR
1- B f2
1- B f2
1- A D1
1- A D1
1- A D1
1- A D1
1- A D1
1- A D1
1- A D1
1- B f2
1- B e2
1- B c3
1- B e2
1- B c2
1- B e2
1- B e3
1- A D1
1- A D1
1- B c2
1- A D1
1- B c2
1- B c2
1- B f3
1- A D1
1- B c3
1- A D1
1- A E3
1- A B2
1- A B1
1- A B2
1- A D3
1- A D2
1- A B2
1- A C2
1- A C1
1- A B2
1- A B1
1- A C2
1- A D2
1- A C2
1- A C2
1- A C2
1- A C1
1- A B2
1- A B1
1- A D3
1- A C2
1- A C2
1- A B1
1- A B1
1- A B1
1- A C2
1- A B1
1- A B2
1- A B1
1- A C1
1- A C2
1- A B2
1- A C2
1- A C3
1- A B3
1- A B3
1- A B3
1- A C2
1- A D2
1- A C2
1- A C2
1- A C2
1- A C1
1- A C1
1- A C2
1- A C2
1- A C2
I-11
