IEI Technology NANO-CV-D25502/N26002 User Manual

Epic sbc with intel atom d2550/n2600 processor, ddr3, dual vga, lvds, dual pcie gbe, usb 2.0, dual pcie mini, sata 3gb/s, audio and rohs
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
NANO-CV-D25502/N26002 EPIC SBC
IEI Technology Corp.
MODEL:
NANO-CV-D25502/N26002
EPIC SBC with Intel® Atom™ D2550/N2600 Processor,
DDR3, Dual VGA, LVDS, Dual PCIe GbE, USB 2.0,
Dual PCIe Mini, SATA 3Gb/s, Audio and RoHS

User Manual

Page i
Rev. 1.00 – 27 August, 2012

Advertisement

Table of Contents
loading

Related Manuals for IEI Technology NANO-CV-D25502/N26002

Summary of Contents for IEI Technology NANO-CV-D25502/N26002

  • Page 1: User Manual

    NANO-CV-D25502/N26002 EPIC SBC IEI Technology Corp. MODEL: NANO-CV-D25502/N26002 EPIC SBC with Intel® Atom™ D2550/N2600 Processor, DDR3, Dual VGA, LVDS, Dual PCIe GbE, USB 2.0, Dual PCIe Mini, SATA 3Gb/s, Audio and RoHS User Manual Page i Rev. 1.00 – 27 August, 2012...
  • Page 2 NANO-CV-D25502/N26002 EPIC SBC Revision Date Version Changes 1.00 Initial release 27 August, 2012 Page ii...
  • Page 3 NANO-CV-D25502/N26002 EPIC SBC Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 4: Table Of Contents

    PTIONAL TEMS 3 CONNECTORS ......................12 3.1 P ..............13 ERIPHERAL NTERFACE ONNECTORS 3.1.1 NANO-CV-D25502/N26002 Layout..............13 3.1.2 Peripheral Interface Connectors ..............13 3.1.3 External Interface Panel Connectors............... 14 3.2 I ..............15 NTERNAL ERIPHERAL ONNECTORS 3.2.1 5 V SATA Power Connectors................15 3.2.2 Audio Connector ....................
  • Page 5 NANO-CV-D25502/N26002 EPIC SBC 3.2.11 Power Connector (9V~28V)................24 3.2.12 RS-232 Serial Port Connectors..............25 3.2.13 RS-422/485 Serial Port Connector ..............26 3.2.14 SATA Drive Connectors ................. 27 3.2.15 SO-DIMM Connector..................28 3.2.16 USB Connector ....................28 3.3 E ......... 29...
  • Page 6 NANO-CV-D25502/N26002 EPIC SBC 5 BIOS ..........................54 5.1 I ......................55 NTRODUCTION 5.1.1 Starting Setup....................55 5.1.2 Using Setup ...................... 55 5.1.3 Getting Help..................... 56 5.1.4 Unable to Reboot after Configuration Changes ..........56 5.1.5 BIOS Menu Bar....................56 5.2 M ........................
  • Page 7 NANO-CV-D25502/N26002 EPIC SBC A BIOS OPTIONS ......................100 B ONE KEY RECOVERY ................... 103 B.1 O ..............104 ECOVERY NTRODUCTION B.1.1 System Requirement..................105 B.1.2 Supported Operating System ................. 106 B.2 S ................ 107 ETUP ROCEDURE FOR INDOWS B.2.1 Hardware and BIOS Setup ................108 B.2.2 Create Partitions ...................
  • Page 8 NANO-CV-D25502/N26002 EPIC SBC D.3.1 Enable the DIO Input Function ..............151 D.3.2 Enable the DIO Output Function..............151 E WATCHDOG TIMER....................152 F HAZARDOUS MATERIALS DISCLOSURE............155 F.1 H IPB P AZARDOUS ATERIALS ISCLOSURE ABLE FOR RODUCTS ERTIFIED AS HS C 2002/95/EC W ........
  • Page 9 NANO-CV-D25502/N26002 EPIC SBC List of Figures Figure 1-1: NANO-CV-D25502/N26002 ..................2 Figure 1-2: Connectors ........................3 Figure 1-3: NANO-CV-D25502/N26002 Dimensions (mm)............4 Figure 1-4: External Interface Panel Dimensions (mm) ..............4 Figure 1-5: Data Flow Diagram......................5 Figure 3-1: Connectors and Jumpers..................13 Figure 3-2: 5 V SATA Power Connector Locations ..............15 Figure 3-3: Audio Connector Location ..................16...
  • Page 10 NANO-CV-D25502/N26002 EPIC SBC Figure 4-6: Power Cable to Motherboard Connection ..............41 Figure 4-7: Connect Power Cable to Power Supply..............42 Figure 4-8: Audio Kit Cable Connection..................43 Figure 4-9: LVDS Connector......................44 Figure 4-10: Backlight Inverter Connection................45 Figure 4-11: PCIe Mini Card Installation..................46 Figure 4-12: SATA Drive Cable Connection................47...
  • Page 11 NANO-CV-D25502/N26002 EPIC SBC Figure B-4: Command Prompt ....................110 Figure B-5: Partition Creation Commands................111 Figure B-6: Launching the Recovery Tool ................113 Figure B-7: Manual Recovery Environment for Windows ............. 113 Figure B-8: Building the Recovery Partition................114 Figure B-9: Press Any Key to Continue .................. 114 Figure B-10: Press F3 to Boot into Recovery Mode...............
  • Page 12 NANO-CV-D25502/N26002 EPIC SBC Figure B-39: System Backup Complete Window ..............131 Figure B-40: Restore Backup ....................132 Figure B-41: Restore System Backup Complete Window ............. 132 Figure B-42: Symantec Ghost Window ................... 133 Figure B-43: Disable Automatically Restart................140 Page xii...
  • Page 13 NANO-CV-D25502/N26002 EPIC SBC List of Tables Table 1-1: NANO-CV-D25502/N26002 Model Variations..............2 Table 1-2: NANO-CV-D25502/N26002 Specifications ..............7 Table 2-1: Packing List.........................11 Table 2-2: Optional Items......................11 Table 3-1: Peripheral Interface Connectors ................14 Table 3-2: Rear Panel Connectors ....................14 Table 3-3: 5 V SATA Power Connector Pinouts ................15 Table 3-4: Audio Connector Pinouts ..................16...
  • Page 14 NANO-CV-D25502/N26002 EPIC SBC Table 5-1: BIOS Navigation Keys ....................56 Page xiv...

  • Page 15: Figure 1-1: Nano-Cv-D25502/N26002

    NANO-CV-D25502/N26002 EPIC SBC BIOS Menus BIOS Menu 1: Main ........................57 BIOS Menu 2: Advanced ......................58 BIOS Menu 3: ACPI Settings .......................59 BIOS Menu 4: RTC Wake Settings ....................60 BIOS Menu 5: CPU Configuration ....................61 BIOS Menu 6: IDE Configuration....................62 BIOS Menu 7: USB Configuration ....................63 BIOS Menu 8: Super IO Configuration..................64...

  • Page 16: Introduction

    NANO-CV-D25502/N26002 EPIC SBC Chapter Introduction Page 1...

  • Page 17: Introduction

    The NANO-CV-D25502/N26002 EPIC motherboard is an Intel® Atom™ D2550/N2600 processor platform that supports one 1066 MHz or 800 MHz DDR3 SO-DIMM memory. The NANO-CV-D25502/N26002 supports dual VGA display output and comes with a LVDS connector supporting 24-bit or 18-bit LVDS screens. Maximum six USB ports, two SATA 3Gb/s connectors, two PCIe Mini card slots, four COM ports, and one audio connector provide flexible expansion options.

  • Page 18: Connectors

    Easy-assembly thermal design by heat sink enclosure Wide range power input (9V~28V) Full-size PCIe Mini card slot with mSATA support Dual GbE RoHS compliant 1.4 Connectors The connectors on the NANO-CV-D25502/N26002 are shown in the figure below. Figure 1-2: Connectors Page 3...

  • Page 19: Dimensions

    NANO-CV-D25502/N26002 EPIC SBC 1.5 Dimensions The main dimensions of the NANO-CV-D25502/N26002 are shown in the diagram below. Figure 1-3: NANO-CV-D25502/N26002 Dimensions (mm) Figure 1-4: External Interface Panel Dimensions (mm) Page 4...

  • Page 20: Data Flow

    NANO-CV-D25502/N26002 EPIC SBC 1.6 Data Flow F igure 1-5 shows the data flow between the system chipset, the CPU and other components installed on the motherboard. Figure 1-5: Data Flow Diagram Page 5...

  • Page 21: Technical Specifications

    NANO-CV-D25502/N26002 EPIC SBC 1.7 Technical Specifications The NANO-CV-D25502/N26002 technical specifications are listed below. Specification/Model NANO-CV-D25502/N26002 EPIC Form Factor 1.86 GHz Intel® Atom™ D2550 dual-core CPU 1.6 GHz Intel® Atom™ N2600 dual-core CPU System CPU 1.86 GHz Intel® Atom™ N2800 dual-core CPU (optional) System Chipset Intel®...

  • Page 22: Table 1-2: Nano-Cv-D25502/N26002 Specifications

    N2600/N2800: -20ºC ~ 70ºC with free air; -20ºC ~ 75ºC with force air D2550: -30ºC ~ 80ºC Storage Temperature N2600/N2800: -30ºC ~ 85ºC Humidity (Operating) 5% ~ 95% (non-condensing) Dimensions 115 mm x 165 mm Weight (GW/NW) 850 g/350 g Table 1-2: NANO-CV-D25502/N26002 Specifications Page 7...

  • Page 23: Packing List

    NANO-CV-D25502/N26002 EPIC SBC Chapter Packing List Page 8...

  • Page 24: Anti-Static Precautions

    Only handle the edges of the PCB: Don't touch the surface of the motherboard. Hold the motherboard by the edges when handling. 2.2 Unpacking Precautions When the NANO-CV-D25502/N26002 is unpacked, please do the following: Follow the antistatic guidelines above. Make sure the packing box is facing upwards when opening.

  • Page 25: Packing List

    If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the NANO-CV-D25502/N26002 was purchased from or contact an IEI sales representative directly by sending an email to ales@iei.com.tw.

  • Page 26: Optional Items

    NANO-CV-D25502/N26002 EPIC SBC Quantity Item and Part Number Image One Key Recovery CD Utility CD Quick Installation Guide Table 2-1: Packing List 2.4 Optional Items The following are optional components which may be separately purchased: Item and Part Number Image...

  • Page 27: Connectors

    NANO-CV-D25502/N26002 EPIC SBC Chapter Connectors Page 12...

  • Page 28: Peripheral Interface Connectors

    NANO-CV-D25502/N26002 EPIC SBC 3.1 Peripheral Interface Connectors This chapter details all the jumpers and connectors. 3.1.1 NANO-CV-D25502/N26002 Layout The figure below shows all the connectors and jumpers. Figure 3-1: Connectors and Jumpers 3.1.2 Peripheral Interface Connectors The table below lists all the connectors on the board.

  • Page 29: External Interface Panel Connectors

    NANO-CV-D25502/N26002 EPIC SBC Connector Type Label Backlight inverter connector 5-pin wafer INV1 Battery connector 2-pin wafer Digital Input/Output (DIO) connector 10-pin header DIO1 Fan connectors 3-pin wafer CPU_FAN1, SYS_FAN2 Front panel connector 10-pin header F_PANEL1 Keyboard and mouse connector 6-pin wafer...

  • Page 30: Internal Peripheral Connectors

    NANO-CV-D25502/N26002 EPIC SBC 3.2 Internal Peripheral Connectors The section describes all of the connectors on the NANO-CV-D25502/N26002. 3.2.1 5 V SATA Power Connectors CN Label: SATA_PWR1, SATA_PWR2 2-pin wafer CN Type: CN Location: See Figure 3-2 CN Pinouts: See Table 3-3 Use the 5 V SATA power connectors to connect to SATA device power connection.

  • Page 31: Backlight Inverter Connector

    3.2.3 Backlight Inverter Connector CN Label: INV1 CN Type: 5-pin wafer CN Location: See Figure 3-4 CN Pinouts: See Table 3-5 The backlight inverter connector provides the backlight on the LCD display connected to the NANO-CV-D25502/N26002 with +12V of power. Page 16...

  • Page 32: Battery Connector

    NANO-CV-D25502/N26002 EPIC SBC Figure 3-4: Backlight Inverter Connector Location Description LCD_BKLTCTL GROUND +12V GROUND BACKLIGHT ENABLE Table 3-5: Backlight Inverter Connector Pinouts 3.2.4 Battery Connector CAUTION: Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery.

  • Page 33: Digital Input/Output (Dio) Connector

    NANO-CV-D25502/N26002 EPIC SBC This is connected to the system battery. The battery provides power to the system clock to retain the time when power is turned off. Figure 3-5: Battery Connector Location Description Battery+ Table 3-6: Battery Connector Pinouts 3.2.5 Digital Input/Output (DIO) Connector...

  • Page 34: Fan Connectors

    NANO-CV-D25502/N26002 EPIC SBC Description Description Output 3 Output 2 Output 1 Output 0 Input 3 Input 2 Input 1 Input 0 Table 3-7: Digital I/O Connector Pinouts 3.2.6 Fan Connectors CN Label: CPU_FAN1, SYS_FAN1 CN Type: 3-pin wafer CN Location:...

  • Page 35: Front Panel Connector

    NANO-CV-D25502/N26002 EPIC SBC 3.2.7 Front Panel Connector CN Label: F_PANEL1 10-pin header CN Type: CN Location: See Figure 3-8 CN Pinouts: See Table 3-9 The front panel connector connects to the indicator LEDs and buttons on the computer's front panel.

  • Page 36: Lvds1 Connector

    NANO-CV-D25502/N26002 EPIC SBC The keyboard and mouse connector can be connected to a standard PS/2 cable or PS/2 Y-cable to add keyboard and mouse functionality to the system. Figure 3-9: Keyboard/Mouse Connector Location Description Mouse Data Mouse Clock Keyboard Data...

  • Page 37: Pcie Mini Card Slots

    NANO-CV-D25502/N26002 EPIC SBC Figure 3-10: LVDS1 Connector Location Description Description LVDS_DATA0 LVDS_DATA0# LVDS_DATA1 LVDS_DATA1# LVDS_DATA2 LVDS_DATA2# LVDS_CLK LVDS_CLK# LDDC_DATA LDDC_CLK VCC_LCD VCC_LCD VCC_LCD VCC_LCD Table 3-11: LVDS1 Connector Pinouts 3.2.10 PCIe Mini Card Slots CN Label: M_PCIE1, M_PCIE2 CN Type:...

  • Page 38: Figure 3-11: Pcie Mini Card Slot Locations

    NANO-CV-D25502/N26002 EPIC SBC NOTE: The M_PCIE1 slot supports mSATA devices. However, the SATA1 connector will be disabled when an mSATA device is installed to the M_PCIE1 slot. Figure 3-11: PCIe Mini Card Slot Locations Description Description PCIE_WAKE# VCC3 1.5V PCIE_CLK#...

  • Page 39: Power Connector (9V~28V)

    NANO-CV-D25502/N26002 EPIC SBC Description Description SMBCLK PCIE_TXN SMBDATA PCIE_TXP USBD- USBD+ VCC3 VCC3 1.5V M-SATA Detect VCC3 Table 3-12: PCIe Mini Card Slot Pinouts 3.2.11 Power Connector (9V~28V) CN Label: 4-pin connector CN Type: CN Location: See Figure 3-12 CN Pinouts:...

  • Page 40: Serial Port Connectors

    NANO-CV-D25502/N26002 EPIC SBC Description Description Table 3-13: Power Connector Pinouts 3.2.12 RS-232 Serial Port Connectors CN Label: COM1, COM2, COM3 10-pin header CN Type: CN Location: See Figure 3-13 CN Pinouts: See Table 3-14 Each of these connectors provides RS-232 connections.

  • Page 41: Rs-422/485 Serial Port Connector

    NANO-CV-D25502/N26002 EPIC SBC 3.2.13 RS-422/485 Serial Port Connector CN Label: COM4 4-pin wafer CN Type: CN Location: See Figure 3-14 CN Pinouts: See Table 3-15 NOTE: These pins are shared with those on the main serial port. Use either the pins on the main connector, or on this connector, but not both.

  • Page 42: Sata Drive Connectors

    NANO-CV-D25502/N26002 EPIC SBC 3.2.14 SATA Drive Connectors CN Label: SATA1, SATA2 CN Type: 7-pin SATA drive connector CN Location: See Figure 3-15 See Table 3-16 CN Pinouts: The SATA drive connectors can be connected to SATA drives and support up to 3Gb/s data transfer rate.

  • Page 43: So-Dimm Connector

    NANO-CV-D25502/N26002 EPIC SBC 3.2.15 SO-DIMM Connector CN Label: DIMM1 204-pin DDR3 SO-DIMM connector CN Type: CN Location: See Figure 3-16 The SO-DIMM connector is for installing memory on the system. Figure 3-16: SO-DIMM Connector Location 3.2.16 USB Connector CN Label:...

  • Page 44: External Peripheral Interface Connector Panel

    CN Type: RJ-45 connector CN Location: See Figure 3-18 CN Pinouts: See Table 3-18 The NANO-CV-D25502/N26002 is equipped with two built-in RJ-45 Ethernet controllers. Each controller can connect to the LAN through one RJ-45 LAN connector. Description Description MDI0+ MDI2+...

  • Page 45: Usb Connectors

    NANO-CV-D25502/N26002 EPIC SBC Description Description MDI1+ MDI3+ MDI1- MDI3- Table 3-18: LAN Pinouts Figure 3-19: RJ-45 Ethernet Connector Description Description on: linked off: 10 Mb/s blinking: data is being sent/received green: 100 Mb/s orange: 1000 Mb/s Table 3-19: RJ-45 Ethernet Connector LEDs 3.3.2 USB Connectors...

  • Page 46: Vga Connectors

    NANO-CV-D25502/N26002 EPIC SBC 3.3.3 VGA Connectors CN Label: VGA1, VGA2 15-pin Female CN Type: CN Location: See Figure 3-18 CN Pinouts: See Figure 3-20 and Table 3-21 Each VGA connector connects to a monitor that accepts a standard VGA input.

  • Page 47: Installation

    NANO-CV-D25502/N26002 EPIC SBC Chapter Installation Page 32...

  • Page 48: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the NANO-CV-D25502/N26002. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the NANO-CV-D25502/N26002 or any other electrical component is handled, the following anti-static precautions are strictly adhered to.
  • Page 49 This helps to prevent potential ESD damage. Turn all power to the NANO-CV-D25502/N26002 off: When working with the NANO-CV-D25502/N26002, make sure that it is disconnected from all power supplies and that no electricity is being fed into the system.

  • Page 50: So-Dimm Installation

    Figure 4-1. Figure 4-1: SO-DIMM Installation Step 1: Locate the SO-DIMM socket. Place the NANO-CV-D25502/N26002 on an anti-static pad with the solder side facing up. Step 2: Align the SO-DIMM with the socket. The SO-DIMM must be oriented in such a way that the notch in the middle of the SO-DIMM must be aligned with the plastic bridge in the socket.

  • Page 51: Jumper Settings

    NANO-CV-D25502/N26002 EPIC SBC Step 5: Secure the SO-DIMM. Release the arms on the SO-DIMM socket. They clip into place and secure the SO-DIMM in the socket.Step 0: 4.4 Jumper Settings NOTE: A jumper is a metal bridge used to close an electrical circuit.

  • Page 52: Clear Cmos Jumper

    NANO-CV-D25502/N26002 EPIC SBC Setting Description Short 1-2 Use ATX power (Default) Use AT power Table 4-2: AT/ATX Power Selection Jumper Settings Figure 4-2: AT/ATX Power Selection Jumper Location 4.4.2 Clear CMOS Jumper Jumper Label: 3-pin header Jumper Type: Jumper Settings:...

  • Page 53: Lvds1 Voltage Selection

    Figure 4-3: Clear CMOS Jumper Location 4.4.3 LVDS1 Voltage Selection WARNING: Permanent damage to the screen and NANO-CV-D25502/N26002 may occur if the wrong voltage is selected with this jumper. Please refer to the user guide that came with the monitor to select the correct voltage.

  • Page 54: Msata/Pcie Mini Selection

    NANO-CV-D25502/N26002 EPIC SBC Figure 4-4: LVDS1 Voltage Selection Jumper Location 4.4.4 mSATA/PCIe Mini Selection Jumper Label: MSATA_SW1 Jumper Type: 2-pin header Jumper Settings: See Table 4-5 Jumper Location: See Figure 4-5 The mSATA/PCIe Mini mode selection jumper specifies the M_PCIE1 connector as MSATA or PCIe Mini mode.

  • Page 55: Chassis Installation

    The NANO-CV-D25502/N26002 must be installed in a chassis with ventilation holes on the sides allowing airflow to travel through the heat sink surface. In a system with an individual power supply unit, the cooling fan of a power supply can also help generate airflow through the board surface.

  • Page 56: At/Atx Power Connection

    NANO-CV-D25502/N26002 EPIC SBC 4.6.1 AT/ATX Power Connection Follow the instructions below to connect the NANO-CV-D25502/N26002 to an AT or ATX power supply. WARNING: Disconnect the power supply power cord from its AC power source to prevent a sudden power surge to the NANO-CV-D25502/N26002.

  • Page 57: Audio Kit Installation

    Figure 4-7: Connect Power Cable to Power Supply 4.6.2 Audio Kit Installation The Audio Kit that came with the NANO-CV-D25502/N26002 connects to the 10-pin audio connector on the NANO-CV-D25502/N26002. The audio kit consists of three audio jacks. One audio jack, Mic In, connects to a microphone. The remaining two audio jacks, Line-In and Line-Out, connect to two speakers.

  • Page 58: Lvds Lcd Installation

    Connect the audio devices. Connect one speaker to the line-in audio jack, one speaker to the line-out audio jack and a microphone to the mic-in audio jack. 4.6.3 LVDS LCD Installation The NANO-CV-D25502/N26002 can be connected to a TFT LCD screen through the LVDS crimp connectors board.

  • Page 59: Figure 4-9: Lvds Connector

    NANO-CV-D25502/N26002 EPIC SBC WARNING: The diagram below is merely for illustration. The configuration and connection of the cables from the TFT LCD screen being installed may be different. Please refer to the installation manual that came with the TFT LCD screen.

  • Page 60: Figure 4-10: Backlight Inverter Connection

    NANO-CV-D25502/N26002 EPIC SBC Figure 4-10: Backlight Inverter Connection Page 45...

  • Page 61: Pcie Mini Card Installation

    NANO-CV-D25502/N26002 EPIC SBC 4.6.4 PCIe Mini Card Installation To install the PCIe Mini card, please refer to the diagram and instructions below. Figure 4-11: PCIe Mini Card Installation Step 1: Insert into the socket at and angle. Line up the notch on the card with the notch on the connector.

  • Page 62: Sata Drive Connection

    NANO-CV-D25502/N26002 EPIC SBC 4.6.5 SATA Drive Connection The NANO-CV-D25502/N26002 is shipped with a SATA drive cable. To connect the SATA drive to the connector, please follow the steps below. Step 1: Locate the SATA connector and the SATA power connector. The locations of the connectors are shown in Chapter 3.

  • Page 63: Single Rs-232 Cable

    NANO-CV-D25502/N26002 EPIC SBC 4.6.6 Single RS-232 Cable The single RS-232 cable consists of one serial port connector attached to a serial communications cable that is then attached to a D-sub 9 male connector. To install the single RS-232 cable, please follow the steps below.

  • Page 64: External Peripheral Interface Connection

    Chapter 3. Step 2: Align the connectors. Align the RJ-45 connector on the LAN cable with the RJ-45 connector on the NANO-CV-D25502/N26002. See Figure 4-14. Figure 4-14: LAN Connection Step 3: Insert the LAN cable RJ-45 connector. Once aligned, gently insert the LAN cable RJ-45 connector into the on-board RJ-45 connector.

  • Page 65: Usb Connection (Dual Connector)

    NANO-CV-D25502/N26002 EPIC SBC 4.7.2 USB Connection (Dual Connector) The external USB Series "A" receptacle connectors provide easier and quicker access to external USB devices. Follow the steps below to connect USB devices to the NANO-CV-D25502/N26002. Step 1: Locate the USB Series "A" receptacle connectors. The locations of the USB Series "A"...

  • Page 66: Vga Monitor Connection

    4.7.3 VGA Monitor Connection The NANO-CV-D25502/N26002 has two female DB-15 connectors on the external peripheral interface panel. The DB-15 connectors are connected to a CRT or VGA monitor. To connect a monitor to the NANO-CV-D25502/N26002, please follow the instructions below. Step 1: Locate the female DB-15 connector.

  • Page 67: Heat Sink Enclosure

    When the NANO-CV-D25502/N26002 is shipped it is secured to a heat sink with eight retention screws. If the NANO-CV-D25502/N26002 must be removed from the heat sink, the eight retention screws must be removed.

  • Page 68: Figure 4-17: Heat Sink Retention Screws

    NANO-CV-D25502/N26002 EPIC SBC Figure 4-17: Heat Sink Retention Screws Page 53...

  • Page 69: Bios

    NANO-CV-D25502/N26002 EPIC SBC Chapter BIOS Page 54...

  • Page 70: Introduction

    NANO-CV-D25502/N26002 EPIC SBC 5.1 Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. 5.1.1 Starting Setup The UEFI BIOS is activated when the computer is turned on. The setup program can be activated in one of two ways.

  • Page 71: Getting Help

    NANO-CV-D25502/N26002 EPIC SBC Function Esc key Main Menu – Quit and not save changes into CMOS Status Page Setup Menu and Option Page Setup Menu -- Exit current page and return to Main Menu General help, only for Status Page Setup Menu and Option...

  • Page 72: Main

    NANO-CV-D25502/N26002 EPIC SBC 5.2 Main The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information. Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.

  • Page 73: Advanced

    NANO-CV-D25502/N26002 EPIC SBC System Time [xx:xx:xx] Use the System Time option to set the system time. Manually enter the hours, minutes and seconds. 5.3 Advanced Use the Advanced menu (BIOS Menu 2) to configure the CPU and peripheral devices through the following sub-menus:...

  • Page 74: Rtc Wake Settings

    NANO-CV-D25502/N26002 EPIC SBC Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Advanced ACPI Settings Select the highest ACPI sleep state the system will enter when the ACPI Sleep State [S1 (CPU Stop Clock)] SUSPEND button is pressed. ---------------------- : Select Screen ↑...
  • Page 75 NANO-CV-D25502/N26002 EPIC SBC Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Advanced Wake system with Fixed Time [Disabled] Enable or disable System wake on alarm event. When enabled, System will wake on the date::hr::min::sec specified ---------------------- : Select Screen ↑...

  • Page 76: Cpu Configuration

    NANO-CV-D25502/N26002 EPIC SBC 5.3.3 CPU Configuration Use the CPU Configuration menu (BIOS Menu 5) to view detailed CPU specifications and configure the CPU. Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Advanced CPU Configuration Enabled for Windows XP...

  • Page 77: Ide Configuration

    NANO-CV-D25502/N26002 EPIC SBC Hyper-Threading [Enabled] Use the Hyper-Threading BIOS option to enable or disable the Intel Hyper-Threading Technology. Disabled Disables the Intel Hyper-Threading Technology. Enables the Intel Hyper-Threading Technology. Enabled EFAULT 5.3.4 IDE Configuration Use the IDE Configuration menu (BIOS Menu 6) to change and/or set the configuration of the SATA devices installed in the system.

  • Page 78: Usb Configuration

    NANO-CV-D25502/N26002 EPIC SBC 5.3.5 USB Configuration Use the USB Configuration menu (BIOS Menu 7) to read USB configuration information and configure the USB settings. Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Advanced USB Configuration Enables Legacy USB support.

  • Page 79: F81866 Super Io Configuration

    NANO-CV-D25502/N26002 EPIC SBC Enabled Legacy USB support enabled EFAULT Legacy USB support disabled if no USB devices are Auto connected 5.3.6 F81866 Super IO Configuration Use the F81866 Super IO Configuration menu (BIOS Menu 8) to set or change the configurations for the serial ports.

  • Page 80: Serial Port N Configuration

    NANO-CV-D25502/N26002 EPIC SBC 5.3.6.1 Serial Port n Configuration Use the Serial Port n Configuration menu (BIOS Menu 9) to configure the serial port n. Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Advanced Serial Port n Configuration Enable or Disable Serial...
  • Page 81 NANO-CV-D25502/N26002 EPIC SBC IO=2F8h; Serial Port I/O port address is 2F8h and the interrupt IRQ=3, 4 address is IRQ3, 4 Serial Port I/O port address is 3E8h and the interrupt IO=3E8h; address is IRQ3, 4 IRQ=3, 4 IO=2E8h; Serial Port I/O port address is 2E8h and the interrupt...
  • Page 82 NANO-CV-D25502/N26002 EPIC SBC 5.3.6.1.3 Serial Port 3 Configuration Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port. Disabled Disable the serial port Enabled Enable the serial port EFAULT Change Settings [Auto] Use the Change Settings option to change the serial port IO port address and interrupt address.
  • Page 83 NANO-CV-D25502/N26002 EPIC SBC 5.3.6.1.4 Serial Port 4 Configuration Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port. Disabled Disable the serial port Enable the serial port Enabled EFAULT Change Settings [Auto] Use the Change Settings option to change the serial port IO port address and interrupt address.

  • Page 84: F81866 H/W Monitor

    NANO-CV-D25502/N26002 EPIC SBC 5.3.7 F81866 H/W Monitor The F81866 H/W Monitor menu (BIOS Menu 10) contains the fan configuration submenus and displays operating temperature, fan speeds and system voltages. Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Advanced...

  • Page 85: Smart Fan Mode Configuration

    NANO-CV-D25502/N26002 EPIC SBC VSB3V VBAT 5.3.7.1 Smart Fan Mode Configuration Use the Smart Fan Mode Configuration submenu (BIOS Menu 11) to configure fan temperature and speed settings. Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Advanced Smart Fan Mode Configuration...

  • Page 86: Serial Port Console Redirection

    NANO-CV-D25502/N26002 EPIC SBC 5.3.8 Serial Port Console Redirection The Serial Port Console Redirection menu (BIOS Menu 12) allows the console redirection options to be configured. Console redirection allows users to maintain a system remotely by re-directing keyboard input and text output through the serial port.
  • Page 87 NANO-CV-D25502/N26002 EPIC SBC Bits per second [115200] Use the Bits per second option to specify the serial port transmission speed. The speed must match the other side. Long or noisy lines may require lower speeds. 9600 Sets the serial port transmission speed at 9600.

  • Page 88: Iei Feature

    NANO-CV-D25502/N26002 EPIC SBC Stop Bits [1] Use the Stop Bits option to specify the number of stop bits used to indicate the end of a serial data packet. Communication with slow devices may require more than 1 stop bit. Sets the number of stop bits at 1.

  • Page 89: Chipset

    NANO-CV-D25502/N26002 EPIC SBC 5.4 Chipset Use the Chipset menu (BIOS Menu 14) to access the Host Bridge and Southbridge configuration menus. WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction.

  • Page 90: Intel Igd Configuration

    NANO-CV-D25502/N26002 EPIC SBC Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Chipset > Intel IGD Configuration Config Intel IGD Settings ******* Memory Information ******* Memory Frequency 1067 MHz(DDR3) Total Memory 1024 MB DIMM#1 1024 MB --------------------- : Select Screen ↑...
  • Page 91 NANO-CV-D25502/N26002 EPIC SBC IGFX - Boot Type [VBIOS Default] Use the IGFX - Boot Type option to select the display device used by the system when it boots. Configuration options are listed below. VBIOS Default EFAULT CRT1 CRT2 LVDS1 LVDS1 Panel Type [800x600 LVDS] Use the LVDS1 Panel Type option to select the type of flat panel connected to the system.

  • Page 92: South Bridge Configuration

    NANO-CV-D25502/N26002 EPIC SBC 5.4.2 South Bridge Configuration Use the South Bridge Configuration menu (BIOS Menu 17) to configure the Southbridge chipset. Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Chipset Auto Power Button Status [Disabled] Select AC power state...

  • Page 93: Boot

    NANO-CV-D25502/N26002 EPIC SBC Set Spread Spectrum Function [Disabled] The Set Spread Spectrum Function option can help to improve CPU EMI issues. The spread spectrum mode is disabled Disabled EFAULT Enabled The spread spectrum mode is enabled 5.5 Boot Use the Boot menu (BIOS Menu 18) to configure system boot options.
  • Page 94 NANO-CV-D25502/N26002 EPIC SBC Does not enable the keyboard Number Lock automatically. To use the 10-keys on the keyboard, press the Number Lock key located on the upper left-hand corner of the 10-key pad. The Number Lock LED on the keyboard lights up when the Number Lock is engaged.

  • Page 95: Security

    NANO-CV-D25502/N26002 EPIC SBC 5.6 Security Use the Security menu (BIOS Menu 19) to set system and user passwords. Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Password Description Set Setup Administrator Password If ONLY the Administrator’s password is set,...
  • Page 96 NANO-CV-D25502/N26002 EPIC SBC Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Save Changes and Reset Reset the system after Discard Changes and Reset saving the changes. Restore Defaults Save as User Defaults...

  • Page 97: Software Drivers

    NANO-CV-D25502/N26002 EPIC SBC Chapter Software Drivers Page 82...

  • Page 98: Available Software Drivers

    NANO-CV-D25502/N26002 EPIC SBC 6.1 Available Software Drivers NOTE: The content of the CD may vary throughout the life cycle of the product and is subject to change without prior notice. Visit the IEI website or contact technical support for the latest updates.

  • Page 99: Figure 6-1: Start Up Screen

    NANO-CV-D25502/N26002 EPIC SBC Figure 6-1: Start Up Screen Step 3: Click NANO-CV-D25502/N26002. Step 4: The list of drivers in Figure 6-2 appears. Figure 6-2: Drivers Page 84...

  • Page 100: Chipset Driver Installation

    NANO-CV-D25502/N26002 EPIC SBC 6.3 Chipset Driver Installation To install the chipset driver, please do the following. Step 1: Access the driver list. (See Section 6.2) Step 2: Click “1-Chipset”. Step 3: Go to the 32-bit or 64-bit folder that corresponds to your OS version.

  • Page 101: Figure 6-4: Chipset Driver Welcome Screen

    NANO-CV-D25502/N26002 EPIC SBC Figure 6-4: Chipset Driver Welcome Screen Step 8: Click Next to continue. Step 9: The license agreement in Figure 6-5 appears. Step 10: Read the License Agreement. Step 11: Click Yes to continue. Page 86...

  • Page 102: Figure 6-5: Chipset Driver License Agreement

    NANO-CV-D25502/N26002 EPIC SBC Figure 6-5: Chipset Driver License Agreement Step 12: The Read Me file in Figure 6-6 appears. Step 13: Click Next to continue. Figure 6-6: Chipset Driver Read Me File Step 14: Setup Operations are performed as shown in Figure 6-7.

  • Page 103: Figure 6-7: Chipset Driver Setup Operations

    NANO-CV-D25502/N26002 EPIC SBC Figure 6-7: Chipset Driver Setup Operations Step 15: Once the Setup Operations are complete, click Next to continue. Step 16: The Finish screen appears. Step 17: Select “Yes, I want to restart the computer now” and click the Finish icon.

  • Page 104: Vga Driver Installation

    NANO-CV-D25502/N26002 EPIC SBC Figure 6-8: Chipset Driver Installation Finish Screen 6.4 VGA Driver Installation To install the VGA driver, please do the following. Step 1: Access the driver list. (See Section 6.2) Step 2: Click “2-Graphics”. Step 3: Open the 32-bit or 64-bit folder that corresponds to your OS version.

  • Page 105: Figure 6-9: Vga Driver Welcome Screen

    NANO-CV-D25502/N26002 EPIC SBC Figure 6-9: VGA Driver Welcome Screen Step 7: Click Next to continue. Step 8: The license agreement in Figure 6-10 appears. Step 9: Read the License Agreement. Step 10: Click Yes to continue. Page 90...

  • Page 106: Figure 6-10: Vga Driver License Agreement

    NANO-CV-D25502/N26002 EPIC SBC Figure 6-10: VGA Driver License Agreement Step 11: The Read Me file in Figure 6-11 appears. Step 12: Click Next to continue. Figure 6-11: VGA Driver Read Me File Page 91...

  • Page 107: Figure 6-12: Vga Driver Setup Operations

    NANO-CV-D25502/N26002 EPIC SBC Step 13: Setup Operations are performed as shown in Figure 6-12. Figure 6-12: VGA Driver Setup Operations Step 14: Once the Setup Operations are complete, click the Next icon to continue. Step 15: The Finish screen appears.

  • Page 108: Lan Driver Installation

    NANO-CV-D25502/N26002 EPIC SBC Figure 6-13: VGA Driver Installation Finish Screen 6.5 LAN Driver Installation To install the LAN driver, please do the following. Step 1: Access the driver list shown in Figure 6-2. (See Section 6.2) Step 2: Click “3-LAN”.

  • Page 109: Figure 6-14: Lan Driver Welcome Screen

    NANO-CV-D25502/N26002 EPIC SBC Figure 6-14: LAN Driver Welcome Screen Step 6: Click Next to continue. Step 7: Click Next to continue. Step 8: The Ready to Install screen in Figure 6-15 appears. Step 9: Click Install to proceed with the installation.

  • Page 110: Figure 6-15: Lan Driver Installation

    NANO-CV-D25502/N26002 EPIC SBC Figure 6-15: LAN Driver Installation Step 10: The program begins to install. Step 11: When the driver installation is complete, the screen in Figure 6-16 appears. Step 12: Click Finish to exit. Page 95...

  • Page 111: Audio Driver Installation

    NANO-CV-D25502/N26002 EPIC SBC Figure 6-16: LAN Driver Installation Complete 6.6 Audio Driver Installation To install the Audio driver, please do the following. Step 1: Access the driver list. (See Section 6.2) Step 2: Click “4-Audio”. Step 3: Open the Win7 folder.

  • Page 112: Figure 6-17: Audio Driver Installation File Extraction

    NANO-CV-D25502/N26002 EPIC SBC Figure 6-17: Audio Driver Installation File Extraction Step 6: The Welcome screen in Figure 6-18 appears. Figure 6-18: Audio Driver Welcome Screen Step 7: Click Next to continue. Step 8: The program begins to install. Page 97...

  • Page 113: Figure 6-19: Audio Driver Installation

    NANO-CV-D25502/N26002 EPIC SBC Step 9: The installation progress can be monitored in the progress bar shown in Figure 6-19. Figure 6-19: Audio Driver Installation Step 10: When the driver installation is complete, the screen in Figure 6-20 appears. Figure 6-20: Audio Driver Installation Complete...
  • Page 114 NANO-CV-D25502/N26002 EPIC SBC Step 11: Select “Yes, I want to restart my computer now” and click Finish. Step 12: The system reboots. Page 99...

  • Page 115: Abios Options

    NANO-CV-D25502/N26002 EPIC SBC Appendix BIOS Options Page 100...
  • Page 116 NANO-CV-D25502/N26002 EPIC SBC Below is a list of BIOS configuration options in the BIOS chapter. 　 System Overview .........................57 　 System Date [xx/xx/xx] ......................57 　 System Time [xx:xx:xx] .......................58 　 ACPI Sleep State [S1 (CPU Stop Clock)] ................59 　 Wake system with Fixed Time [Disabled]................60 　...
  • Page 117 NANO-CV-D25502/N26002 EPIC SBC 　 Set Spread Spectrum Function [Disabled]................78 　 Bootup NumLock State [On]....................78 　 Quiet Boot [Enabled] ......................79 　 Launch PXE OpROM [Disabled] ..................79 　 Option ROM Messages [Force BIOS].................79 　 UEFI Boot [Disabled] ......................79 　 Administrator Password .....................80 　...

  • Page 118: B One Key Recovery

    NANO-CV-D25502/N26002 EPIC SBC Appendix One Key Recovery Page 103...

  • Page 119: One Key Recovery Introduction

    NANO-CV-D25502/N26002 EPIC SBC B.1 One Key Recovery Introduction The IEI one key recovery is an easy-to-use front end for the Norton Ghost system backup and recovery tool. This tool provides quick and easy shortcuts for creating a backup and reverting to that backup or reverting to the factory default settings.

  • Page 120: System Requirement

    NANO-CV-D25502/N26002 EPIC SBC After completing the five initial setup procedures as described above, users can access the recovery tool by pressing <F3> while booting up the system. The detailed information of each function is described in Section B.5. NOTE: The initial setup procedures for Linux system are described in Section B .3.

  • Page 121: Supported Operating System

    NANO-CV-D25502/N26002 EPIC SBC partitions. Please take the following table as a reference when calculating the size of the partition. OS Image after Ghost Compression Ratio Windows® 7 7 GB 5 GB Windows® XPE 776 MB 560 MB Windows® CE 6.0...

  • Page 122: Setup Procedure For Windows

    NANO-CV-D25502/N26002 EPIC SBC Linux Fedora Core 12 (Constantine) Fedora Core 11 (Leonidas) Fedora Core 10 (Cambridge) Fedora Core 8 (Werewolf) Fedora Core 7 (Moonshine) RedHat RHEL-5.4 RedHat 9 (Ghirke) Ubuntu 8.10 (Intrepid) Ubuntu 7.10 (Gutsy) Ubuntu 6.10 (Edgy) Debian 5.0 (Lenny) Debian 4.0 (Etch)

  • Page 123: Hardware And Bios Setup

    NANO-CV-D25502/N26002 EPIC SBC The detailed descriptions are described in the following sections. NOTE: The setup procedures described below are for Microsoft Windows operating system users. For Linux, most of the setup procedures are the same except for several steps described in Section B .3.

  • Page 124: Figure B-2: Launching The Recovery Tool

    NANO-CV-D25502/N26002 EPIC SBC Step 2: Boot the system from recovery CD. When prompted, press any key to boot from the recovery CD. It will take a while to launch the recovery tool. Please be patient! Figure B-2: Launching the Recovery Tool Step 3: The recovery tool setup menu is shown as below.

  • Page 125: Figure B-4: Command Prompt

    NANO-CV-D25502/N26002 EPIC SBC Figure B-4: Command Prompt Step 5: The command prompt window appears. Type the following commands (marked in red) to create two partitions. One is for the OS installation; the other is for saving recovery files and images which will be an invisible partition.

  • Page 126: Figure B-5: Partition Creation Commands

    NANO-CV-D25502/N26002 EPIC SBC Figure B-5: Partition Creation Commands Page 111...

  • Page 127: Install Operating System, Drivers And Applications

    NANO-CV-D25502/N26002 EPIC SBC NOTE: Use the following commands to check if the partitions were created successfully. Step 6: Press any key to exit the recovery tool and automatically reboot the system. Please continue to the following procedure: Build the Recovery Partition.S t e p 0 :...

  • Page 128: Build-Up Recovery Partition

    NANO-CV-D25502/N26002 EPIC SBC B.2.4 Build-up Recovery Partition Step 1: Put the recover CD in the optical drive. Step 2: Start the system. Step 3: Boot the system from the recovery CD. When prompted, press any key to boot from the recovery CD. It will take a while to launch the recovery tool. Please...

  • Page 129: Figure B-8: Building The Recovery Partition

    NANO-CV-D25502/N26002 EPIC SBC Step 5: The Symantec Ghost window appears and starts configuring the system to build a recovery partition. In this process the partition created for recovery files in Section B .2.2 is hidden and the recovery tool is saved in this partition.

  • Page 130: Create Factory Default Image

    NANO-CV-D25502/N26002 EPIC SBC B.2.5 Create Factory Default Image NOTE: Before creating the factory default image, please configure the system to a factory default environment, including driver and application installations. To create a factory default image, please follow the steps below.

  • Page 131: Figure B-12: About Symantec Ghost Window

    NANO-CV-D25502/N26002 EPIC SBC Figure B-12: About Symantec Ghost Window Step 4: Use mouse to navigate to the option shown below ( F igure B-13). Figure B-13: Symantec Ghost Path Step 5: Select the local source drive (Drive 1) as shown in F igure B-14.

  • Page 132: Figure B-14: Select A Local Source Drive

    NANO-CV-D25502/N26002 EPIC SBC Figure B-14: Select a Local Source Drive Step 6: Select a source partition (Part 1) from basic drive as shown in F igure B-15. Then click OK. Figure B-15: Select a Source Partition from Basic Drive Step 7: Select 1.2: [Recovery] NTFS drive and enter a file name called...

  • Page 133: Figure B-16: File Name To Copy Image To

    NANO-CV-D25502/N26002 EPIC SBC Figure B-16: File Name to Copy Image to Step 8: When the Compress Image screen in F igure B-17 prompts, click High to make the image file smaller. Figure B-17: Compress Image Page 118...

  • Page 134: Figure B-18: Image Creation Confirmation

    NANO-CV-D25502/N26002 EPIC SBC Step 9: The Proceed with partition image creation window appears, click Yes to continue. Figure B-18: Image Creation Confirmation Step 10: The Symantec Ghost starts to create the factory default image ( F igure B-19). Figure B-19: Image Creation Complete...

  • Page 135: Auto Recovery Setup Procedure

    NANO-CV-D25502/N26002 EPIC SBC Step 12: The recovery tool main menu window is shown as below. Press any key to reboot the system. S t e p 0 : Figure B-21: Press Any Key to Continue B.3 Auto Recovery Setup Procedure...

  • Page 136: Figure B-22: Auto Recovery Utility

    NANO-CV-D25502/N26002 EPIC SBC Step 1: Follow the steps described in Section B.2.1 ~ Section B.2.3 to setup BIOS, create partitions and install operating system. Step 2: Install the auto recovery utility into the system by double clicking the Utility/AUTORECOVERY-SETUP.exe in the One Key Recovery CD. This utility MUST be installed in the system, otherwise, the system will automatically restore from the factory default image every ten (10) minutes.

  • Page 137: Figure B-24: Launching The Recovery Tool

    NANO-CV-D25502/N26002 EPIC SBC Step 4: Reboot the system from the recovery CD. When prompted, press any key to boot from the recovery CD. It will take a while to launch the recovery tool. Please be patient! Figure B-24: Launching the Recovery Tool Step 5: When the recovery tool setup menu appears, press <4>...

  • Page 138: Figure B-26: Building The Auto Recovery Partition

    NANO-CV-D25502/N26002 EPIC SBC Figure B-26: Building the Auto Recovery Partition Step 7: After completing the system configuration, the following message prompts to confirm whether to create a factory default image. Type Y to have the system create a factory default image automatically. Type N within 6 seconds to skip this process (The default option is YES).

  • Page 139: Figure B-28: Image Creation Complete

    NANO-CV-D25502/N26002 EPIC SBC Step 8: The Symantec Ghost starts to create the factory default image (Figure B-28). Figure B-28: Image Creation Complete Step 9: After completing the system configuration, press any key in the following window to restart the system.

  • Page 140: Setup Procedure For Linux

    NANO-CV-D25502/N26002 EPIC SBC BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit iEi Feature ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ Auto Recovery Function [Enabled] Recover from PXE [Disabled] Select Screen ↑ ↓ Select Item Enter Go to SubScreen General Help Save and Exit Exit v02.61 ©Copyright 1985-2006, American Megatrends, Inc.

  • Page 141: Figure B-31: Partitions For Linux

    NANO-CV-D25502/N26002 EPIC SBC Partition 1: / Partition 2: SWAP NOTE: Please reserve enough space for partition 3 for saving recovery images. Figure B-31: Partitions for Linux Step 3: Create a recovery partition. Insert the recovery CD into the optical disk drive.

  • Page 142: Figure B-32: System Configuration For Linux

    NANO-CV-D25502/N26002 EPIC SBC recovery partition. After completing the system configuration, press any key to reboot the system. Eject the recovery CD. Figure B-32: System Configuration for Linux Step 5: Access the recovery tool main menu by modifying the “menu.lst”. To first access the recovery tool main menu, the menu.lst must be modified.

  • Page 143: Recovery Tool Functions

    NANO-CV-D25502/N26002 EPIC SBC Step 7: The recovery tool menu appears. ( F igure B-34) Figure B-34: Recovery Tool Menu Step 8: Create a factory default image. Follow Step 2 Step 12 described in Section B .2.5 to create a factory default image.

  • Page 144: Figure B-35: Recovery Tool Main Menu

    NANO-CV-D25502/N26002 EPIC SBC Figure B-35: Recovery Tool Main Menu The recovery tool has several functions including: 1. Factory Restore: Restore the factory default image (iei.GHO) created in Section B .2.5. 2. Backup system: Create a system backup image (iei_user.GHO) which will be saved in the hidden partition.

  • Page 145: Factory Restore

    NANO-CV-D25502/N26002 EPIC SBC B.5.1 Factory Restore To restore the factory default image, please follow the steps below. Step 1: Type <1> and press <Enter> in the main menu. Step 2: The Symantec Ghost window appears and starts to restore the factory default. A factory default image called iei.GHO is created in the hidden Recovery partition.

  • Page 146: Backup System

    NANO-CV-D25502/N26002 EPIC SBC B.5.2 Backup System To backup the system, please follow the steps below. Step 1: Type <2> and press <Enter> in the main menu. Step 2: The Symantec Ghost window appears and starts to backup the system. A backup image called iei_user.GHO is created in the hidden Recovery partition.

  • Page 147: Restore Your Last Backup

    NANO-CV-D25502/N26002 EPIC SBC B.5.3 Restore Your Last Backup To restore the last system backup, please follow the steps below. Step 1: Type <3> and press <Enter> in the main menu. Step 2: The Symantec Ghost window appears and starts to restore the last backup image (iei_user.GHO).

  • Page 148: Manual

    NANO-CV-D25502/N26002 EPIC SBC B.5.4 Manual To restore the last system backup, please follow the steps below. Step 1: Type <4> and press <Enter> in the main menu. Step 2: The Symantec Ghost window appears. Use the Ghost program to backup or recover the system manually.

  • Page 149: Restore Systems From A Linux Server Through Lan

    NANO-CV-D25502/N26002 EPIC SBC B.6 Restore Systems from a Linux Server through LAN The One Key Recovery allows a client system to automatically restore to a factory default image saved in a Linux system (the server) through LAN connectivity after encountering a Blue Screen of Death (BSoD) or a hang for around 10 minutes.

  • Page 150: Configure Dhcp Server Settings

    NANO-CV-D25502/N26002 EPIC SBC B.6.1 Configure DHCP Server Settings Step 1: Install the DHCP #yum install dhcp (CentOS, commands marked in red) #apt-get install dhcp3-server (Debian, commands marked in blue) Step 2: Confirm the operating system default settings: dhcpd.conf. CentOS Use the following command to show the DHCP server sample location: #vi /etc/dhcpd.conf...

  • Page 151: Configure Tftp Settings

    NANO-CV-D25502/N26002 EPIC SBC filename “pxelinux.0”; B.6.2 Configure TFTP Settings Step 1: Install the tftp, httpd and syslinux. #yum install tftp-server httpd syslinux (CentOS) #apt-get install tftpd-hpa xinetd syslinux (Debian) Step 2: Enable the TFTP server by editing the “/etc/xinetd.d/tftp” file and make it use the remap file.

  • Page 152: Configure One Key Recovery Server Settings

    NANO-CV-D25502/N26002 EPIC SBC Debian Replace the TFTP settings from “inetd” to “xinetd” and annotate the “inetd” by adding “#”. #vi /etc/inetd.conf Modify: #tftp dgram udp wait root /usr/sbin..(as shown below) #vi /etc/xinetd.d/tftp B.6.3 Configure One Key Recovery Server Settings Step 1: Copy the Utility/RECOVERYR10.TAR.BZ2 package from the One Key...

  • Page 153: Start The Dhcp, Tftp And Http

    NANO-CV-D25502/N26002 EPIC SBC B.6.4 Start the DHCP, TFTP and HTTP Start the DHCP, TFTP and HTTP. For example: CentOS #service xinetd restart #service httpd restart #service dhcpd restart Debian #/etc/init.d/xinetd reload #/etc/init.d/xinetd restart #/etc/init.d/dhcp3-server restart B.6.5 Create Shared Directory Step 1: Install the samba.

  • Page 154: Setup A Client System For Auto Recovery

    NANO-CV-D25502/N26002 EPIC SBC Modify: [image] comment = One Key Recovery path = /share/image browseable = yes writable = yes public = yes create mask = 0644 directory mask = 0755 Step 4: Edit “/etc/samba/smb.conf” for your environment. For example: Step 5:...

  • Page 155: Figure B-43: Disable Automatically Restart

    NANO-CV-D25502/N26002 EPIC SBC Figure B-43: Disable Automatically Restart Step 2: Configure the following BIOS options of the client system. Advanced → iEi Feature → Auto Recovery Function → Enabled Advanced → iEi Feature → Recover from PXE → Enabled Boot → Launch PXE OpROM → Enabled...
  • Page 156 NANO-CV-D25502/N26002 EPIC SBC Step 6: Restart the client system from LAN. If the system encounters a Blue Screen of Death (BSoD) or a hang for around 10 minutes, it will automatically restore from the factory default image. The following screens will show when the system starts auto recovering.

  • Page 157: Other Information

    NANO-CV-D25502/N26002 EPIC SBC NOTE: A firewall or a SELinux is not in use in the whole setup process described above. If there is a firewall or a SELinux protecting the system, modify the configuration information to accommodate them. B.7 Other Information B.7.1 Using AHCI Mode or ALi M5283 / VIA VT6421A Controller...
  • Page 158 NANO-CV-D25502/N26002 EPIC SBC Step 5: When the following window appears, press <S> to select “Specify Additional Device”. Page 143...

  • Page 159: System Memory Requirement

    NANO-CV-D25502/N26002 EPIC SBC Step 6: In the following window, select a SATA controller mode used in the system. Then press <Enter>. The user can now start using the SATA HDD. Step 7: After pressing <Enter>, the system will get into the recovery tool setup menu.

  • Page 160: C Terminology

    NANO-CV-D25502/N26002 EPIC SBC Appendix Terminology Page 145...
  • Page 161 NANO-CV-D25502/N26002 EPIC SBC AC ’97 Audio Codec 97 (AC’97) refers to a codec standard developed by Intel® in 1997. ACPI Advanced Configuration and Power Interface (ACPI) is an OS-directed configuration, power management, and thermal management interface. AHCI Advanced Host Controller Interface (AHCI) is a SATA Host controller register-level interface.
  • Page 162 NANO-CV-D25502/N26002 EPIC SBC DIMM Dual Inline Memory Modules are a type of RAM that offer a 64-bit data bus and have separate electrical contacts on each side of the module. The digital inputs and digital outputs are general control signals that control the on/off circuit of external devices or TTL devices.
  • Page 163 NANO-CV-D25502/N26002 EPIC SBC LVDS Low-voltage differential signaling (LVDS) is a dual-wire, high-speed differential electrical signaling system commonly used to connect LCD displays to a computer. POST The Power-on Self Test (POST) is the pre-boot actions the system performs when the system is turned-on.

  • Page 164: D Digital I/O Interface

    NANO-CV-D25502/N26002 EPIC SBC Appendix Digital I/O Interface Page 149...

  • Page 165: Introduction

    NANO-CV-D25502/N26002 EPIC SBC D.1 Introduction The DIO connector on the NANO-CV-D25502/N26002 is interfaced to GPIO ports on the Super I/O chipset. The DIO has both 4-bit digital inputs and 4-bit digital outputs. The digital inputs and digital outputs are generally control signals that control the on/off circuit of external devices or TTL devices.

  • Page 166: Assembly Language Samples

    NANO-CV-D25502/N26002 EPIC SBC D.3 Assembly Language Samples D.3.1 Enable the DIO Input Function The BIOS interrupt call INT 15H controls the digital I/O. An assembly program to enable digital I/O input functions is listed below. Sets the digital port as input...

  • Page 167: E Watchdog Timer

    NANO-CV-D25502/N26002 EPIC SBC Appendix Watchdog Timer Page 152...
  • Page 168 NANO-CV-D25502/N26002 EPIC SBC NOTE: The following discussion applies to DOS environment. Contact IEI support or visit the IEI website for specific drivers for other operating systems. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash. This condition may have occurred by external EMIs or a software bug.
  • Page 169 NANO-CV-D25502/N26002 EPIC SBC NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. EXAMPLE PROGRAM: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30 ;time-out value is 48 seconds ;...

  • Page 170: F Hazardous Materials Disclosure

    NANO-CV-D25502/N26002 EPIC SBC Appendix Hazardous Materials Disclosure Page 155...

  • Page 171: Ipb Products Certified As Ercury

    NANO-CV-D25502/N26002 EPIC SBC F.1 Hazardous Materials Disclosure Table for IPB Products Certified as RoHS Compliant Under 2002/95/EC Without Mercury The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 172 NANO-CV-D25502/N26002 EPIC SBC Part Name Toxic or Hazardous Substances and Elements Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated Biphenyls Diphenyl (Pb) (Hg) (Cd) Chromium (CR(VI)) (PBB) Ethers (PBDE) Housing Display Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Power Supply...
  • Page 173 NANO-CV-D25502/N26002 EPIC SBC 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯 醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11363-2006 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11363-2006 标准规定的限量要求。...

Table of Contents
