NANO-CV-D25501/N26001 EPIC SBC
MODEL:
NANO-CV-D25501/N26001
EPIC SBC with Intel® Atom™ D2550/N2600 Processor,
DDR3, VGA, HDMI, Dual LVDS, Dual PCIe GbE, USB 3.0,
mSATA, SATA 3Gb/s, PC/104-Plus, Audio and RoHS
Rev. 1.04 – February 22, 2016

User Manual

Page i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NANO-CV-D25501 and is the answer not in the manual?

Questions and answers

Related Manuals for IEI Technology NANO-CV-D25501

Summary of Contents for IEI Technology NANO-CV-D25501

  • Page 1: User Manual

    NANO-CV-D25501/N26001 EPIC SBC MODEL: NANO-CV-D25501/N26001 EPIC SBC with Intel® Atom™ D2550/N2600 Processor, DDR3, VGA, HDMI, Dual LVDS, Dual PCIe GbE, USB 3.0, mSATA, SATA 3Gb/s, PC/104-Plus, Audio and RoHS User Manual Page i Rev. 1.04 – February 22, 2016...
  • Page 2 NANO-CV-D25501/N26001 EPIC SBC Revision Date Version Changes 1.04 Added LVDS1 to Figure 1-3 February 22, 2016 Modified Table 4-7 1.03 Updated Figure 1-5: Data Flow Diagram February 18, 2013 1.02 Updated Figure 3-11: LVDS1 Connector Location February 6, 2013 1.01 Updated the note for the Intel®...
  • Page 3 NANO-CV-D25501/N26001 EPIC SBC Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 4 NANO-CV-D25501/N26001 EPIC SBC Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product.

  • Page 5: Table Of Contents

    PTIONAL TEMS 3 CONNECTORS ......................14 3.1 P ..............15 ERIPHERAL NTERFACE ONNECTORS 3.1.1 NANO-CV-D25501/N26001 Layout..............15 3.1.2 Peripheral Interface Connectors ..............16 3.1.3 External Interface Panel Connectors............... 17 3.2 I ..............17 NTERNAL ERIPHERAL ONNECTORS 3.2.1 5 V SATA Power Connectors................17 3.2.2 Audio Connector ....................
  • Page 6 NANO-CV-D25501/N26001 EPIC SBC 3.2.11 LVDS2 Connector................... 26 3.2.12 microSD Card Slot ..................27 3.2.13 PC/104-Plus Slot.................... 28 3.2.14 PC/104-Plus Power Input Connector ............31 3.2.15 PCIe Mini Card Slot ..................32 3.2.16 Power Connector (9V~28V)................33 3.2.17 RS-232 Serial Port Connectors..............34 3.2.18 RS-422/485 Serial Port Connector ..............
  • Page 7 NANO-CV-D25501/N26001 EPIC SBC 4.6.2 Audio Kit Installation..................57 4.6.3 Keyboard/Mouse Connector ................58 4.6.4 LVDS LCD Installation ..................60 4.6.5 PCIe Mini Card Installation ................62 4.6.6 SATA Drive Connection ................... 63 4.6.7 Single RS-232 Cable ..................64 4.6.8 USB Cable (Dual Port without Bracket) ............65 4.7 E...
  • Page 8 NANO-CV-D25501/N26001 EPIC SBC 5.4.1 Host Bridge Configuration ................93 5.4.1.1 Intel IGD Configuration................94 5.4.2 South Bridge Configuration................96 5.5 B ........................98 5.6 S ....................... 100 ECURITY 5.7 S & E ......................100 6 SOFTWARE DRIVERS .................... 102 6.1 A ................
  • Page 9 NANO-CV-D25501/N26001 EPIC SBC List of Figures Figure 1-1: NANO-CV-D25501/N26001 ..................2 Figure 1-2: Connectors ........................4 Figure 1-3: NANO-CV-D25501/N26001 Dimensions (mm)............5 Figure 1-4: External Interface Panel Dimensions (mm) ..............5 Figure 1-5: Data Flow Diagram......................6 Figure 3-1: Connectors and Jumpers..................15 Figure 3-2: 5 V SATA Power Connector Locations ..............17 Figure 3-3: Audio Connector Location ..................18...
  • Page 10 NANO-CV-D25501/N26001 EPIC SBC Figure 3-26: VGA Connector .......................42 Figure 4-1: SO-DIMM Installation ....................47 Figure 4-2: AT/ATX Power Selection Jumper Location ............49 Figure 4-3: Clear CMOS Jumper Location .................50 Figure 4-4: LVDS1 Voltage Selection Jumper Location ............51 Figure 4-5: LVDS2 Voltage Selection Jumper Location ............52 Figure 4-6: LVDS2 Resolution Selection Jumper Location............53...
  • Page 11 NANO-CV-D25501/N26001 EPIC SBC Figure 6-7: Chipset Driver Setup Operations ................. 108 Figure 6-8: Chipset Driver Installation Finish Screen............109 Figure 6-9: VGA Driver Welcome Screen ................110 Figure 6-10: VGA Driver License Agreement................111 Figure 6-11: VGA Driver Read Me File ..................111 Figure 6-12: VGA Driver Setup Operations................
  • Page 12 NANO-CV-D25501/N26001 EPIC SBC List of Tables Table 1-1: NANO-CV-D25501/N26001 Model Variations..............2 Table 1-2: NANO-CV-D25501/N26001 Specifications ..............9 Table 2-1: Packing List.........................13 Table 2-2: Optional Items......................13 Table 3-1: Peripheral Interface Connectors ................16 Table 3-2: Rear Panel Connectors ....................17 Table 3-3: 5 V SATA Power Connector Pinouts ................18 Table 3-4: Audio Connector Pinouts ..................18...
  • Page 13 NANO-CV-D25501/N26001 EPIC SBC Table 3-27: HDMI Connector Pinouts ..................40 Table 3-28: USB 2.0 Port Pinouts....................41 Table 3-29: USB 3.0 Port Pinouts....................41 Table 3-30: VGA Connector Pinouts...................42 Table 4-1: Jumpers ........................48 Table 4-2: AT/ATX Power Selection Jumper Settings...............49 Table 4-3: Clear CMOS Jumper Settings..................49 Table 4-4: LVDS1 Voltage Selection Jumper Settings..............50...
  • Page 14 NANO-CV-D25501/N26001 EPIC SBC BIOS Menus BIOS Menu 1: Main ........................76 BIOS Menu 2: Advanced ......................77 BIOS Menu 3: ACPI Settings .......................78 BIOS Menu 4: RTC Wake Settings ....................79 BIOS Menu 5: CPU Configuration ....................80 BIOS Menu 6: IDE Configuration....................81 BIOS Menu 7: USB Configuration ....................82 BIOS Menu 8: Super IO Configuration..................83...

  • Page 15: Introduction

    NANO-CV-D25501/N26001 EPIC SBC Chapter Introduction Page 1...

  • Page 16: Introduction

    The NANO-CV-D25501/N26001 EPIC motherboard is an Intel® Atom™ D2550/N2600 processor platform that supports one 1066 MHz or 800 MHz DDR3 SO-DIMM memory. The NANO-CV-D25501/N26001 supports VGA/HDMI display output and comes with two LVDS connectors supporting 24-bit or 18-bit LVDS screens. Maximum six USB ports (two USB 3.0, four USB 2.0), two SATA 3Gb/s connectors, one PCIe Mini card slot, one...

  • Page 17: Features

    Supports PC/104-Plus (PC/104 and PCI-104 slots) Dual GbE Complete I/O with six USB (two USB 3.0, four USB 2.0), two SATA 3Gb/s, four COM and audio RoHS compliant 1.4 Connectors The connectors on the NANO-CV-D25501/N26001 are shown in the figure below. Page 3...

  • Page 18: Figure 1-2: Connectors

    NANO-CV-D25501/N26001 EPIC SBC Figure 1-2: Connectors Page 4...

  • Page 19: Dimensions

    NANO-CV-D25501/N26001 EPIC SBC 1.5 Dimensions The main dimensions of the NANO-CV-D25501/N26001 are shown in the diagram below. Figure 1-3: NANO-CV-D25501/N26001 Dimensions (mm) Figure 1-4: External Interface Panel Dimensions (mm) Page 5...

  • Page 20: Data Flow

    NANO-CV-D25501/N26001 EPIC SBC 1.6 Data Flow F igure 1-5 shows the data flow between the system chipset, the CPU and other components installed on the motherboard. Figure 1-5: Data Flow Diagram Page 6...

  • Page 21: Technical Specifications

    NANO-CV-D25501/N26001 EPIC SBC 1.7 Technical Specifications The NANO-CV-D25501/N26001 technical specifications are listed below. Specification/Model NANO-CV-D25501/N26001 EPIC Form Factor 1.86 GHz Intel® Atom™ D2550 dual-core CPU 1.6 GHz Intel® Atom™ N2600 dual-core CPU System CPU 1.86 GHz Intel® Atom™ N2800 dual-core CPU (optional) System Chipset Intel®...
  • Page 22 NANO-CV-D25501/N26001 EPIC SBC Specification/Model NANO-CV-D25501/N26001 One PCIe Mini card slot with mSATA support (SATA1 and mSATA share Expansion SATA signal) One PC/104-Plus slot (ISA bus and PCI bus) Realtek ALC662 HD Audio codec Audio One internal audio connector (10-pin box header)

  • Page 23: Table 1-2: Nano-Cv-D25501/N26001 Specifications

    NANO-CV-D25501/N26001 EPIC SBC Specification/Model NANO-CV-D25501/N26001 670 g/350 g Weight (GW/NW) Table 1-2: NANO-CV-D25501/N26001 Specifications Page 9...

  • Page 24: Packing List

    NANO-CV-D25501/N26001 EPIC SBC Chapter Packing List Page 10...

  • Page 25: Anti-Static Precautions

    Only handle the edges of the PCB: Don't touch the surface of the motherboard. Hold the motherboard by the edges when handling. 2.2 Unpacking Precautions When the NANO-CV-D25501/N26001 is unpacked, please do the following: Follow the antistatic guidelines above. Make sure the packing box is facing upwards when opening.

  • Page 26: Packing List

    If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the NANO-CV-D25501/N26001 was purchased from or contact an IEI sales representative directly by sending an email to ales@ieiworld.com.

  • Page 27: Optional Items

    NANO-CV-D25501/N26001 EPIC SBC Quantity Item and Part Number Image Mini jumper pack One Key Recovery CD Utility CD Quick Installation Guide Table 2-1: Packing List 2.4 Optional Items The following are optional components which may be separately purchased: Item and Part Number...

  • Page 28: Connectors

    NANO-CV-D25501/N26001 EPIC SBC Chapter Connectors Page 14...

  • Page 29: Peripheral Interface Connectors

    NANO-CV-D25501/N26001 EPIC SBC 3.1 Peripheral Interface Connectors This chapter details all the jumpers and connectors. 3.1.1 NANO-CV-D25501/N26001 Layout The figure below shows all the connectors and jumpers. Figure 3-1: Connectors and Jumpers Page 15...

  • Page 30: Peripheral Interface Connectors

    NANO-CV-D25501/N26001 EPIC SBC 3.1.2 Peripheral Interface Connectors The table below lists all the connectors on the board. Connector Type Label 5 V SATA power connectors 2-pin wafer SATA_PWR1, SATA_PWR2 Audio connector 10-pin header AUDIO1 Backlight inverter connectors 5-pin wafer INV1, INV2...

  • Page 31: External Interface Panel Connectors

    USB_CON1 VGA connector 15-pin female VGA1 Table 3-2: Rear Panel Connectors 3.2 Internal Peripheral Connectors The section describes all of the connectors on the NANO-CV-D25501/N26001. 3.2.1 5 V SATA Power Connectors CN Label: SATA_PWR1, SATA_PWR2 CN Type: 2-pin wafer CN Location:...

  • Page 32: Audio Connector

    NANO-CV-D25501/N26001 EPIC SBC Pin No. Description Ground Table 3-3: 5 V SATA Power Connector Pinouts 3.2.2 Audio Connector CN Label: AUDIO1 CN Type: 10-pin header CN Location: See Figure 3-3 CN Pinouts: See Table 3-4 The 10-pin audio connector is connected to external audio devices including speakers and microphones for the input and output of audio signals to and from the system.

  • Page 33: Backlight Inverter Connectors

    CN Type: CN Location: See Figure 3-4 CN Pinouts: See Table 3-5 The backlight inverter connectors provide the backlight on the LCD display connected to the NANO-CV-D25501/N26001 with +12V of power. Figure 3-4: Backlight Inverter Connector Locations Description LCD_BKLTCTL GROUND +12V...

  • Page 34: Battery Connector

    NANO-CV-D25501/N26001 EPIC SBC 3.2.4 Battery Connector CAUTION: Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery. Dispose of used batteries according to instructions and local regulations. CN Label: BAT1 CN Type:...

  • Page 35: Buzzer Connector

    NANO-CV-D25501/N26001 EPIC SBC 3.2.5 Buzzer Connector CN Label: 2-pin wafer CN Type: CN Location: See Figure 3-6 CN Pinouts: See Table 3-7 This is connected to the buzzer cable. Figure 3-6: Buzzer Connector Location Description +V5S Table 3-7: Buzzer Connector Pinouts 3.2.6 Digital Input/Output (DIO) Connector...

  • Page 36: Fan Connector

    NANO-CV-D25501/N26001 EPIC SBC Figure 3-7: Digital I/O Connector Location Description Description Output 3 Output 2 Output 1 Output 0 Input 3 Input 2 Input 1 Input 0 Table 3-8: Digital I/O Connector Pinouts 3.2.7 Fan Connector CN Label: CPU_FAN1 3-pin wafer...

  • Page 37: Front Panel Connector

    NANO-CV-D25501/N26001 EPIC SBC Figure 3-8: Fan Connector Location PIN NO. DESCRIPTION FANIO +12V (PWM) Ground Table 3-9: Fan Connector Pinouts 3.2.8 Front Panel Connector CN Label: F_PANEL1 10-pin header CN Type: CN Location: See Figure 3-9 CN Pinouts: See Table 3-10 The front panel connector connects to the indicator LEDs and buttons on the computer's front panel.

  • Page 38: Keyboard/Mouse Connector

    NANO-CV-D25501/N26001 EPIC SBC Figure 3-9: Front Panel Connector Location Function Description Function Description PWRLED Power LED PWRBTSW# PWRLED Power Button +V5S RESET+ HDD LED Reset Button HDD_LED- Table 3-10: Front Panel Connector Pinouts 3.2.9 Keyboard/Mouse Connector CN Label: KB_MS1 CN Type:...

  • Page 39: Lvds1 Connector

    NANO-CV-D25501/N26001 EPIC SBC Figure 3-10: Keyboard/Mouse Connector Location Description Mouse Data Mouse Clock Keyboard Data Keyboard Clock Table 3-11: Keyboard/Mouse Connector Pinouts 3.2.10 LVDS1 Connector CN Label: LVDS1 CN Type: 20-pin crimp CN Location: See Figure 3-11 CN Pinouts: See Table 3-12 The LVDS connector is for an LCD panel connected to the board.

  • Page 40: Lvds2 Connector

    NANO-CV-D25501/N26001 EPIC SBC Description Description LVDS_DATA0 LVDS_DATA0# LVDS_DATA1 LVDS_DATA1# LVDS_DATA2 LVDS_DATA2# LVDS_CLK LVDS_CLK# LDDC_DATA LDDC_CLK VCC_LCD VCC_LCD VCC_LCD VCC_LCD Table 3-12: LVDS1 Connector Pinouts 3.2.11 LVDS2 Connector CN Label: LVDS2 30-pin crimp CN Type: See Figure 3-12 CN Location: CN Pinouts: See Table 3-13 The LVDS connector is for an LCD panel connected to the board.

  • Page 41: Microsd Card Slot

    NANO-CV-D25501/N26001 EPIC SBC Description Description LVDS_DATA0 LVDS_DATA0# LVDS_DATA1 LVDS_DATA1# LVDS_DATA2 LVDS_DATA2# LVDS_CLK1 LVDS_CLK1# LVDS_DATA3 LVDS_DATA3# LVDS_DATA4 LVDS_DATA4# LVDS_DATA5 LVDS_DATA5# LVDS_DATA6 LVDS_DATA6# LVDS_CLK2 LVDS_CLK2# LVDS_DATA7 LVDS_DATA7# VCC_LCD VCC_LCD VCC_LCD VCC_LCD Table 3-13: LVDS2 Connector Pinouts 3.2.12 microSD Card Slot CN Label:...

  • Page 42: Pc/104-Plus Slot

    NANO-CV-D25501/N26001 EPIC SBC Description DAT2 DAT3 VSS1 DAT0 DAT1 Table 3-14: microSD Card Slot Connector Pinouts 3.2.13 PC/104-Plus Slot CN Label: PC104_PLUS1, CN8 104-pin ISA bus and 120-pin PCI bus CN Type: CN Location: See Figure 3-14 CN Pinouts: See Table 3-15 and Table 3-16 The PC/104-Plus slot is for installing a PC/104-Plus expansion module.

  • Page 43: Table 3-15: Pci Bus Pinouts

    NANO-CV-D25501/N26001 EPIC SBC Description Description Description Description RESERVED1 VIO1 CBE0- AD11 VIO2 AD10 M66EN AD14 AD13 AD12 CBE1- AD15 SERR- SBO- PERR- SDONE STOP- LOCK- TRDY- DEVSEL- FRAME- IRDY- AD16 CBE2- AD18 AD17 AD21 AD20 AD19 AD23 AD22 IDSEL0 IDSEL1-...
  • Page 44 NANO-CV-D25501/N26001 EPIC SBC Description Description Description Description -IOCHK RSTDRV -SBHE -MEMCS16 SA23 -IOCS16 IRQ9 SA22 IRQ10 SA21 IRQ11 DRQ2 SA20 IRQ12 SA19 IRQ15 -NOWS SA18 IRQ14 +12V SA17 -DACK0 IOCHRDY -MEMR DRQ0 -SMEMW -MEMW -DACK5 SA19 -SMEMR DRQ5 SA18 -IOW...

  • Page 45: Pc/104-Plus Power Input Connector

    NANO-CV-D25501/N26001 EPIC SBC Description Description Description Description Table 3-16: ISA Bus Pinouts 3.2.14 PC/104-Plus Power Input Connector CN Label: CN Type: 3-pin wafer CN Location: See Figure 3-15 CN Pinouts: See Table 3-17 The PC/104-Plus power input connector provides power to the PC/104-Plus expansion module installed on the PC/104-Plus slot.

  • Page 46: Pcie Mini Card Slot

    NANO-CV-D25501/N26001 EPIC SBC 3.2.15 PCIe Mini Card Slot CN Label: M_PCIE1 52-pin PCIe Mini card slot CN Type: CN Location: See Figure 3-16 CN Pinouts: See Table 3-18 The PCIe Mini card slot enables a PCIe Mini card expansion module to be connected to the board.

  • Page 47: Power Connector (9V~28V)

    NANO-CV-D25501/N26001 EPIC SBC Description Description PCIRST# PCIE_RXN VCC3 PCIE_RXP 1.5V SMBCLK PCIE_TXN SMBDATA PCIE_TXP USBD- USBD+ VCC3 VCC3 1.5V M-SATA Detect VCC3 Table 3-18: PCIe Mini Card Slot Pinouts 3.2.16 Power Connector (9V~28V) CN Label: CN Type: 4-pin connector CN Location:...

  • Page 48: Serial Port Connectors

    NANO-CV-D25501/N26001 EPIC SBC Figure 3-17: Power Connector Location Description Description Table 3-19: Power Connector Pinouts 3.2.17 RS-232 Serial Port Connectors CN Label: COM1, COM2, COM3 CN Type: 10-pin header See Figure 3-18 CN Location: CN Pinouts: See Table 3-20 Each of these connectors provides RS-232 connections.

  • Page 49: Rs-422/485 Serial Port Connector

    NANO-CV-D25501/N26001 EPIC SBC Description Description Table 3-20: RS-232 Serial Port Connector Pinouts 3.2.18 RS-422/485 Serial Port Connector CN Label: COM4 CN Type: 4-pin wafer CN Location: See Figure 3-19 CN Pinouts: See Table 3-21 NOTE: These pins are shared with those on the main serial port. Use either the pins on the main connector, or on this connector, but not both.

  • Page 50: Sata Drive Connectors

    NANO-CV-D25501/N26001 EPIC SBC Description Description RXD422- TXD422+/TXD485+ RXD422+ TXD422-/TXD485- Table 3-21: RS-422/485 Connector Pinouts Use the optional RS-422/485 cable to connect to a serial device. The pinouts of the DB-9 connector are listed below. RS-422 Pinouts RS-485 Pinouts Table 3-22: DB-9 RS-422/485 Pinouts 3.2.19 SATA Drive Connectors...

  • Page 51: So-Dimm Connector

    NANO-CV-D25501/N26001 EPIC SBC Figure 3-20: SATA Drive Connector Locations Description Table 3-23: SATA Drive Connector Pinouts 3.2.20 SO-DIMM Connector CN Label: DIMM1 CN Type: 204-pin DDR3 SO-DIMM connector CN Location: See Figure 3-21 The SO-DIMM connector is for installing memory on the system.

  • Page 52: Usb Connector

    NANO-CV-D25501/N26001 EPIC SBC Figure 3-21: SO-DIMM Connector Location 3.2.21 USB Connector CN Label: USB4 CN Type: 8-pin header CN Location: See Figure 3-22 CN Pinouts: See Table 3-24 The USB connector provides connectivity to two USB 1.1/2.0 ports. Figure 3-22: USB Connector Location...

  • Page 53: External Peripheral Interface Connector Panel

    RJ-45 connector CN Type: CN Location: See Figure 3-23 CN Pinouts: See Table 3-25 The NANO-CV-D25501/N26001 is equipped with two built-in RJ-45 Ethernet controllers. Each controller can connect to the LAN through one RJ-45 LAN connector. Description Description MDI0+ MDI2+...

  • Page 54: Hdmi Connector

    NANO-CV-D25501/N26001 EPIC SBC Description Description on: linked off: 10 Mb/s blinking: data is being sent/received green: 100 Mb/s orange: 1000 Mb/s Table 3-26: RJ-45 Ethernet Connector LEDs 3.3.2 HDMI Connector CN Label: HDMI1 CN Type: HDMI connector CN Location: See Figure 3-23...

  • Page 55: Usb 2.0 Connector

    Dual USB port CN Location: See Figure 3-23 CN Pinouts: See Table 3-29 The NANO-CV-D25501/N26001 has two external USB 3.0 ports. Each USB 3.0 port can be connected to a USB device. Description Description Table 3-29: USB 3.0 Port Pinouts...

  • Page 56: Vga Connector

    NANO-CV-D25501/N26001 EPIC SBC NOTE: If installing the Windows® 7 OS by using the USB 3.0 ports, loading the USB 3.0 driver during OS installation is necessary. Refer to Section 4.8 for detailed installation procedure. 3.3.5 VGA Connector CN Label: VGA1...
  • Page 57 NANO-CV-D25501/N26001 EPIC SBC NOTE: Due to Intel® GMA driver limitation, the monitor connected to the VGA connector may become extended desktop or not have signal to it after restarting from the graphics driver installation. To work out this limitation, press the Ctrl+Alt+F1 hotkey to switch the primary display to CRT mode.

  • Page 58: Installation

    NANO-CV-D25501/N26001 EPIC SBC Chapter Installation Page 44...

  • Page 59: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the NANO-CV-D25501/N26001. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the NANO-CV-D25501/N26001 or any other electrical component is handled, the following anti-static precautions are strictly adhered to.
  • Page 60 This helps to prevent potential ESD damage. Turn all power to the NANO-CV-D25501/N26001 off: When working with the NANO-CV-D25501/N26001, make sure that it is disconnected from all power supplies and that no electricity is being fed into the system.

  • Page 61: So-Dimm Installation

    Figure 4-1. Figure 4-1: SO-DIMM Installation Step 1: Locate the SO-DIMM socket. Place the NANO-CV-D25501/N26001 on an anti-static pad with the solder side facing up. Step 2: Align the SO-DIMM with the socket. The SO-DIMM must be oriented in such a way that the notch in the middle of the SO-DIMM must be aligned with the plastic bridge in the socket.

  • Page 62: Jumper Settings

    NANO-CV-D25501/N26001 EPIC SBC 4.4 Jumper Settings NOTE: A jumper is a metal bridge used to close an electrical circuit. It consists of two or three metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them. To...

  • Page 63: Clear Cmos Jumper

    NANO-CV-D25501/N26001 EPIC SBC The AT/ATX power selection jumper specifies the system power mode as AT or ATX. Setting Description Short 1-2 Use ATX power (Default) Use AT power Table 4-2: AT/ATX Power Selection Jumper Settings Figure 4-2: AT/ATX Power Selection Jumper Location 4.4.2 Clear CMOS Jumper...

  • Page 64: Lvds1 Voltage Selection

    Figure 4-3: Clear CMOS Jumper Location 4.4.3 LVDS1 Voltage Selection WARNING: Permanent damage to the screen and NANO-CV-D25501/N26001 may occur if the wrong voltage is selected with this jumper. Please refer to the user guide that came with the monitor to select the correct voltage.

  • Page 65: Lvds2 Voltage Selection

    Figure 4-4: LVDS1 Voltage Selection Jumper Location 4.4.4 LVDS2 Voltage Selection WARNING: Permanent damage to the screen and NANO-CV-D25501/N26001 may occur if the wrong voltage is selected with this jumper. Please refer to the user guide that came with the monitor to select the correct voltage.

  • Page 66: Lvds2 Resolution Selection

    NANO-CV-D25501/N26001 EPIC SBC Figure 4-5: LVDS2 Voltage Selection Jumper Location 4.4.5 LVDS2 Resolution Selection Jumper Label: Jumper Type: DIP switch Jumper Settings: See Table 4-6 Jumper Location: See Figure 4-6 Selects the resolution of the LCD panel connected to the LVDS2 connector.

  • Page 67: Msata/Pcie Mini Mode Selection

    NANO-CV-D25501/N26001 EPIC SBC 1100 1680 x 1050 @ 60Hz 24-bit Dual 1101 1600 x 1200 @ 60Hz 24-bit Dual 1110 1920 x 1080 @ 60Hz 24-bit Dual 1111 1920 x 1200 @ 60Hz 24-bit Dual Table 4-6: LVDS2 Resolution Selection Figure 4-6: LVDS2 Resolution Selection Jumper Location 4.4.6 mSATA/PCIe Mini Mode Selection...

  • Page 68: Pc/104-Plus Vio Voltage Selection

    NANO-CV-D25501/N26001 EPIC SBC Figure 4-7: mSATA/PCIe Mini Mode Selection Jumper Location 4.4.7 PC/104-Plus VIO Voltage Selection Jumper Label: Jumper Type: 3-pin header See Table 4-8 Jumper Settings: Jumper Location: See Figure 4-8 This jumper selects the PC/104-Plus VIO voltage to VCC or VCC3.

  • Page 69: Chassis Installation

    The NANO-CV-D25501/N26001 must be installed in a chassis with ventilation holes on the sides allowing airflow to travel through the heat sink surface. In a system with an individual power supply unit, the cooling fan of a power supply can also help generate airflow through the board surface.

  • Page 70: At/Atx Power Connection

    NANO-CV-D25501/N26001 EPIC SBC 4.6.1 AT/ATX Power Connection Follow the instructions below to connect the NANO-CV-D25501/N26001 to an AT or ATX power supply. WARNING: Disconnect the power supply power cord from its AC power source to prevent a sudden power surge to the NANO-CV-D25501/N26001.

  • Page 71: Audio Kit Installation

    Figure 4-10: Connect Power Cable to Power Supply 4.6.2 Audio Kit Installation The Audio Kit that came with the NANO-CV-D25501/N26001 connects to the 10-pin audio connector on the NANO-CV-D25501/N26001. The audio kit consists of three audio jacks. One audio jack, Mic In, connects to a microphone. The remaining two audio jacks, Line-In and Line-Out, connect to two speakers.

  • Page 72: Keyboard/Mouse Connector

    The NANO-CV-D25501/N26001 is shipped with a keyboard/mouse Y-cable connector. The keyboard/mouse Y-cable connector connects to a keyboard/mouse connector on the NANO-CV-D25501/N26001 and branches into two cables that are each connected to a PS/2 connector, one for a mouse and one for a keyboard. To connect the keyboard/mouse Y-cable connector please follow the steps below.

  • Page 73: Figure 4-12: Keyboard/Mouse Y-Cable Connection

    NANO-CV-D25501/N26001 EPIC SBC Step 3: Insert the cable connectors. Once the cable connector is properly aligned with the keyboard/mouse connector on the NANO-CV-D25501/N26001, connect the cable connector to the on-board connectors. See Figure 4-12. Figure 4-12: Keyboard/mouse Y-cable Connection Step 4: Attach PS/2 connectors to the chassis.

  • Page 74: Lvds Lcd Installation

    NANO-CV-D25501/N26001 EPIC SBC 4.6.4 LVDS LCD Installation The NANO-CV-D25501/N26001 can be connected to a TFT LCD screen through the LVDS crimp connectors board. connect NANO-CV-D25501/N26001, please follow the steps below. Step 1: Locate the connector. The location of the LVDS connector is shown in Chapter 3.

  • Page 75: Figure 4-13: Lvds Connector

    NANO-CV-D25501/N26001 EPIC SBC Figure 4-13: LVDS Connector Step 3: Locate the backlight inverter connector. The location of the backlight inverter connector is shown in Chapter 3. Step 4: Connect backlight connector. Connect the backlight connector to the driver TFT LCD PCB as shown in Figure 4-14. When inserting the cable connector, make sure the pins are properly aligned.

  • Page 76: Pcie Mini Card Installation

    NANO-CV-D25501/N26001 EPIC SBC Figure 4-14: Backlight Inverter Connection 4.6.5 PCIe Mini Card Installation To install the PCIe Mini card, please refer to the diagram and instructions below. Figure 4-15: PCIe Mini Card Installation Page 62...

  • Page 77: Sata Drive Connection

    Push down until the card clips into place. Push the other end of the card down until it clips into place on the plastic connector. 4.6.6 SATA Drive Connection The NANO-CV-D25501/N26001 is shipped with a SATA drive cable. To connect the SATA drive to the connector, please follow the steps below. Step 1: Locate the SATA connector and the SATA power connector.

  • Page 78: Single Rs-232 Cable

    NANO-CV-D25501/N26001 EPIC SBC Step 3: Connect the cable to the SATA disk. Connect the connector on the other end of the cable to the connector at the back of the SATA drive. See Figure 4-16. Step 4: To remove the SATA cable from the SATA connector, press the clip on the connector at the end of the cable.

  • Page 79: Usb Cable (Dual Port Without Bracket)

    4.6.8 USB Cable (Dual Port without Bracket) The NANO-CV-D25501/N26001 is shipped with a dual port USB 2.0 cable. To connect the USB cable connector, please follow the steps below. Step 1: Locate the connector.

  • Page 80: External Peripheral Interface Connection

    NANO-CV-D25501/N26001. 4.7.1 HDMI Display Device Connection The HDMI connector transmits a digital signal to compatible HDMI display devices such as a TV or computer screen. To connect the HDMI cable to the NANO-CV-D25501/N26001, follow the steps below. Step 1: Locate the HDMI connector. The location is shown in Chapter 3.

  • Page 81: Lan Connection

    Chapter 3. Step 2: Align the connectors. Align the RJ-45 connector on the LAN cable with the RJ-45 connector on the NANO-CV-D25501/N26001. See Figure 4-20. Figure 4-20: LAN Connection Step 3: Insert the LAN cable RJ-45 connector. Once aligned, gently insert the LAN cable RJ-45 connector into the on-board RJ-45 connector.

  • Page 82: Vga Monitor Connection

    4.7.4 VGA Monitor Connection The NANO-CV-D25501/N26001 has one female DB-15 connector on the external peripheral interface panel. The DB-15 connector is connected to a CRT or VGA monitor. To connect a monitor to the NANO-CV-D25501/N26001, please follow the instructions below. Step 1: Locate the female DB-15 connector.

  • Page 83: Installing Usb 3.0 Driver During Windows® 7 Os Installation

    OS installation is necessary. Follow the instructions below to complete the task. Step 1: Insert the USB flash drive containing the USB 3.0 driver into one of the USB 2.0 ports on the NANO-CV-D25501/N26001. Step 2: After clicking the Install now button during the OS installation (Figure 4-23), the Load Driver screen appears (Figure 4-24).

  • Page 84: Figure 4-23: Install Now

    NANO-CV-D25501/N26001 EPIC SBC Figure 4-23: Install Now Figure 4-24: Load Driver Step 3: Locate the USB 3.0 driver folder, select Driver, and then click OK (Figure 4-25). Page 70...

  • Page 85: Figure 4-25: Browse For Folder

    NANO-CV-D25501/N26001 EPIC SBC Figure 4-25: Browse for Folder Step 4: Make sure the ASMedia XHCI Controller driver is selected, and then click Next. Figure 4-26: Select the ASMedia XHCI Controller Driver Step 5: Click OK to continue (Figure 4-27). Page 71...

  • Page 86: Figure 4-27: Confirm The Driver File

    NANO-CV-D25501/N26001 EPIC SBC Figure 4-27: Confirm the Driver File Step 6: Make sure the Driver subfolder inside the USB 3.0 driver folder is selected, and then click OK (Figure 4-25). Step 7: Select the USB Root Hub driver and click Next.

  • Page 87: Bios

    NANO-CV-D25501/N26001 EPIC SBC Chapter BIOS Page 73...

  • Page 88: Introduction

    NANO-CV-D25501/N26001 EPIC SBC 5.1 Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. 5.1.1 Starting Setup The UEFI BIOS is activated when the computer is turned on. The setup program can be activated in one of two ways.

  • Page 89: Getting Help

    NANO-CV-D25501/N26001 EPIC SBC Function Esc key Main Menu – Quit and not save changes into CMOS Status Page Setup Menu and Option Page Setup Menu -- Exit current page and return to Main Menu General help, only for Status Page Setup Menu and Option...

  • Page 90: Main

    NANO-CV-D25501/N26001 EPIC SBC 5.2 Main The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information. Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.

  • Page 91: Advanced

    NANO-CV-D25501/N26001 EPIC SBC System Time [xx:xx:xx] Use the System Time option to set the system time. Manually enter the hours, minutes and seconds. 5.3 Advanced Use the Advanced menu (BIOS Menu 2) to configure the CPU and peripheral devices through the following sub-menus:...

  • Page 92: Rtc Wake Settings

    NANO-CV-D25501/N26001 EPIC SBC Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Advanced ACPI Settings Select the highest ACPI sleep state the system will enter when the ACPI Sleep State [S1 (CPU Stop Clock)] SUSPEND button is pressed. ---------------------- : Select Screen ↑...

  • Page 93: Bios Menu 4: Rtc Wake Settings

    NANO-CV-D25501/N26001 EPIC SBC Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Advanced Wake system with Fixed Time [Disabled] Enable or disable System wake on alarm event. When enabled, System will wake on the date::hr::min::sec specified ---------------------- : Select Screen ↑...

  • Page 94: Cpu Configuration

    NANO-CV-D25501/N26001 EPIC SBC 5.3.3 CPU Configuration Use the CPU Configuration menu (BIOS Menu 5) to view detailed CPU specifications and configure the CPU. Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Advanced CPU Configuration Enabled for Windows XP...

  • Page 95: Ide Configuration

    NANO-CV-D25501/N26001 EPIC SBC Hyper-Threading [Enabled] Use the Hyper-Threading BIOS option to enable or disable the Intel Hyper-Threading Technology. Disabled Disables the Intel Hyper-Threading Technology. Enables the Intel Hyper-Threading Technology. Enabled EFAULT 5.3.4 IDE Configuration Use the IDE Configuration menu (BIOS Menu 6) to change and/or set the configuration of the SATA devices installed in the system.

  • Page 96: Usb Configuration

    NANO-CV-D25501/N26001 EPIC SBC 5.3.5 USB Configuration Use the USB Configuration menu (BIOS Menu 7) to read USB configuration information and configure the USB settings. Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Advanced USB Configuration Enables Legacy USB support.

  • Page 97: F81866 Super Io Configuration

    NANO-CV-D25501/N26001 EPIC SBC Enabled Legacy USB support enabled EFAULT Legacy USB support disabled if no USB devices are Auto connected 5.3.6 F81866 Super IO Configuration Use the F81866 Super IO Configuration menu (BIOS Menu 8) to set or change the configurations for the serial ports.

  • Page 98: Serial Port N Configuration

    NANO-CV-D25501/N26001 EPIC SBC 5.3.6.1 Serial Port n Configuration Use the Serial Port n Configuration menu (BIOS Menu 9) to configure the serial port n. Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Advanced Serial Port n Configuration Enable or Disable Serial...
  • Page 99 NANO-CV-D25501/N26001 EPIC SBC IO=2F8h; Serial Port I/O port address is 2F8h and the interrupt IRQ=3, 4 address is IRQ3, 4 Serial Port I/O port address is 3E8h and the interrupt IO=3E8h; address is IRQ3, 4 IRQ=3, 4 IO=2E8h; Serial Port I/O port address is 2E8h and the interrupt...
  • Page 100 NANO-CV-D25501/N26001 EPIC SBC 5.3.6.1.3 Serial Port 3 Configuration Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port. Disabled Disable the serial port Enabled Enable the serial port EFAULT Change Settings [Auto] Use the Change Settings option to change the serial port IO port address and interrupt address.
  • Page 101 NANO-CV-D25501/N26001 EPIC SBC 5.3.6.1.4 Serial Port 4 Configuration Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port. Disabled Disable the serial port Enable the serial port Enabled EFAULT Change Settings [Auto] Use the Change Settings option to change the serial port IO port address and interrupt address.

  • Page 102: F81866 H/W Monitor

    NANO-CV-D25501/N26001 EPIC SBC 5.3.7 F81866 H/W Monitor The F81866 H/W Monitor menu (BIOS Menu 10) contains the fan configuration submenus and displays operating temperature, fan speeds and system voltages. Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Advanced...

  • Page 103: Smart Fan Mode Configuration

    NANO-CV-D25501/N26001 EPIC SBC 5.3.7.1 Smart Fan Mode Configuration Use the Smart Fan Mode Configuration submenu (BIOS Menu 11) to configure fan temperature and speed settings. Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Advanced Smart Fan Mode Configuration...

  • Page 104: Serial Port Console Redirection

    NANO-CV-D25501/N26001 EPIC SBC 5.3.8 Serial Port Console Redirection The Serial Port Console Redirection menu (BIOS Menu 12) allows the console redirection options to be configured. Console redirection allows users to maintain a system remotely by re-directing keyboard input and text output through the serial port.
  • Page 105 NANO-CV-D25501/N26001 EPIC SBC Bits per second [115200] Use the Bits per second option to specify the serial port transmission speed. The speed must match the other side. Long or noisy lines may require lower speeds. 9600 Sets the serial port transmission speed at 9600.

  • Page 106: Iei Feature

    NANO-CV-D25501/N26001 EPIC SBC Stop Bits [1] Use the Stop Bits option to specify the number of stop bits used to indicate the end of a serial data packet. Communication with slow devices may require more than 1 stop bit. Sets the number of stop bits at 1.

  • Page 107: Chipset

    NANO-CV-D25501/N26001 EPIC SBC 5.4 Chipset Use the Chipset menu (BIOS Menu 14) to access the Host Bridge and Southbridge configuration menus. WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction.

  • Page 108: Intel Igd Configuration

    NANO-CV-D25501/N26001 EPIC SBC Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Chipset > Intel IGD Configuration Config Intel IGD Settings ******* Memory Information ******* Memory Frequency 800 MHz(DDR3) Total Memory 1024 MB DIMM#1 1024 MB --------------------- : Select Screen ↑...
  • Page 109 NANO-CV-D25501/N26001 EPIC SBC Disabled Disables the LVDS1 connector. EFAULT Enables the LVDS1 connector. Enabled IGFX - Boot Type [VBIOS Default] Use the IGFX - Boot Type option to select the display device used by the system when it boots. Configuration options are listed below.

  • Page 110: South Bridge Configuration

    NANO-CV-D25501/N26001 EPIC SBC Fixed Graphics Memory Size [128MB] Use the Fixed Graphics Memory Size option to specify the maximum amount of memory that can be allocated as graphics memory. Configuration options are listed below. 128MB EFAULT 256MB 5.4.2 South Bridge Configuration Use the South Bridge Configuration menu (BIOS Menu 17) to configure the Southbridge chipset.
  • Page 111 NANO-CV-D25501/N26001 EPIC SBC Power Saving Function(ERP) [Disabled] Use the Power Saving Function(ERP) option to enable or disable the power saving function. Disabled Disables the power saving function. EFAULT Enables the power saving function. Enabled Azalia Controller [Enabled] Use the Azalia Controller option to enable or disable the High Definition Audio controller.

  • Page 112: Boot

    NANO-CV-D25501/N26001 EPIC SBC 5.5 Boot Use the Boot menu (BIOS Menu 18) to configure system boot options. Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Boot Configuration Select the keyboard...
  • Page 113 NANO-CV-D25501/N26001 EPIC SBC Quiet Boot [Enabled] Use the Quiet Boot BIOS option to select the screen display when the system boots. Normal POST messages displayed Disabled Enabled OEM Logo displayed instead of POST messages EFAULT Launch PXE OpROM [Disabled] Use the Launch PXE OpROM option to enable or disable boot option for legacy network devices.

  • Page 114: Security

    NANO-CV-D25501/N26001 EPIC SBC 5.6 Security Use the Security menu (BIOS Menu 19) to set system and user passwords. Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Password Description Set Setup Administrator Password If ONLY the Administrator’s password is set,...

  • Page 115: Bios Menu 20: Save & Exit

    NANO-CV-D25501/N26001 EPIC SBC Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Save Changes and Reset Reset the system after Discard Changes and Reset saving the changes. Restore Defaults Save as User Defaults...

  • Page 116: Software Drivers

    NANO-CV-D25501/N26001 EPIC SBC Chapter Software Drivers Page 102...

  • Page 117: Available Software Drivers

    NANO-CV-D25501/N26001 EPIC SBC 6.1 Available Software Drivers NOTE: The content of the CD may vary throughout the life cycle of the product and is subject to change without prior notice. Visit the IEI website or contact technical support for the latest updates.

  • Page 118: Figure 6-1: Start Up Screen

    NANO-CV-D25501/N26001 EPIC SBC Figure 6-1: Start Up Screen Step 3: Click NANO-CV-D25501/N26001. Step 4: The list of drivers in Figure 6-2 appears. Figure 6-2: Drivers Page 104...

  • Page 119: Chipset Driver Installation

    NANO-CV-D25501/N26001 EPIC SBC 6.3 Chipset Driver Installation To install the chipset driver, please do the following. Step 1: Access the driver list. (See Section 6.2) Step 2: Click “1-Chipset”. Step 3: Go to the 32-bit or 64-bit folder that corresponds to your OS version.

  • Page 120: Figure 6-4: Chipset Driver Welcome Screen

    NANO-CV-D25501/N26001 EPIC SBC Figure 6-4: Chipset Driver Welcome Screen Step 8: Click Next to continue. Step 9: The license agreement in Figure 6-5 appears. Step 10: Read the License Agreement. Step 11: Click Yes to continue. Page 106...

  • Page 121: Figure 6-5: Chipset Driver License Agreement

    NANO-CV-D25501/N26001 EPIC SBC Figure 6-5: Chipset Driver License Agreement Step 12: The Read Me file in Figure 6-6 appears. Step 13: Click Next to continue. Figure 6-6: Chipset Driver Read Me File Step 14: Setup Operations are performed as shown in Figure 6-7.

  • Page 122: Figure 6-7: Chipset Driver Setup Operations

    NANO-CV-D25501/N26001 EPIC SBC Figure 6-7: Chipset Driver Setup Operations Step 15: Once the Setup Operations are complete, click Next to continue. Step 16: The Finish screen appears. Step 17: Select “Yes, I want to restart the computer now” and click the Finish icon.

  • Page 123: Vga Driver Installation

    NANO-CV-D25501/N26001 EPIC SBC Figure 6-8: Chipset Driver Installation Finish Screen 6.4 VGA Driver Installation NOTE: Due to Intel® GMA driver limitation, the monitor connected to the VGA connector may become extended desktop or not have signal to it after restarting from the graphics driver installation. To work out this limitation, press the Ctrl+Alt+F1 hotkey to switch the primary display to CRT mode.

  • Page 124: Figure 6-9: Vga Driver Welcome Screen

    NANO-CV-D25501/N26001 EPIC SBC Step 5: The Welcome Screen in Figure 6-9 appears. Figure 6-9: VGA Driver Welcome Screen Step 6: Click Next to continue. Step 7: The license agreement in Figure 6-10 appears. Step 8: Read the License Agreement. Step 9: Click Yes to continue.

  • Page 125: Figure 6-10: Vga Driver License Agreement

    NANO-CV-D25501/N26001 EPIC SBC Figure 6-10: VGA Driver License Agreement Step 10: The Read Me file in Figure 6-11 appears. Step 11: Click Next to continue. Figure 6-11: VGA Driver Read Me File Step 12: Setup Operations are performed as shown in Figure 6-12.

  • Page 126: Figure 6-12: Vga Driver Setup Operations

    NANO-CV-D25501/N26001 EPIC SBC Figure 6-12: VGA Driver Setup Operations Step 13: Once the Setup Operations are complete, click the Next icon to continue. Step 14: The Finish screen appears. Step 15: Select “Yes, I want to restart the computer now” and click the Finish icon.

  • Page 127: Lan Driver Installation

    NANO-CV-D25501/N26001 EPIC SBC 6.5 LAN Driver Installation To install the LAN driver, please do the following. Step 1: Access the driver list shown in Figure 6-2. (See Section 6.2) Step 2: Click “3-LAN”. Step 3: Go to the Realtek > Install_Win7_7048_09162011 folder.

  • Page 128: Figure 6-15: Lan Driver Installation

    NANO-CV-D25501/N26001 EPIC SBC Figure 6-15: LAN Driver Installation Step 9: The program begins to install. Step 10: When the driver installation is complete, the screen in Figure 6-16 appears. Step 11: Click Finish to exit. Figure 6-16: LAN Driver Installation Complete...

  • Page 129: Audio Driver Installation

    NANO-CV-D25501/N26001 EPIC SBC 6.6 Audio Driver Installation To install the Audio driver, please do the following. Step 1: Access the driver list. (See Section 6.2) Step 2: Click “4-Audio”. Step 3: Open the Win7 folder. Step 4: Double click the Vista_Win7_R263 icon.

  • Page 130: Figure 6-18: Audio Driver Welcome Screen

    NANO-CV-D25501/N26001 EPIC SBC Figure 6-18: Audio Driver Welcome Screen Step 7: Click Next to continue. Step 8: The program begins to install. Step 9: The installation progress can be monitored in the progress bar shown in Figure 6-19. Figure 6-19: Audio Driver Installation...

  • Page 131: Usb 3.0 Driver Installation

    NANO-CV-D25501/N26001 EPIC SBC Step 10: When the driver installation is complete, the screen in Figure 6-20 appears. Figure 6-20: Audio Driver Installation Complete Step 11: Select “Yes, I want to restart my computer now” and click Finish. Step 12: The system reboots.

  • Page 132: Figure 6-21: Usb 3.0 Driver Welcome Screen

    NANO-CV-D25501/N26001 EPIC SBC Step 3: Locate the setup file and double click on it. Step 4: The Welcome Screen in Figure 6-21 appears. Step 5: Click Next to continue. Figure 6-21: USB 3.0 Driver Welcome Screen Step 6: The license agreement in Figure 6-22 appears.

  • Page 133: Figure 6-22: Usb 3.0 Driver License Agreement

    NANO-CV-D25501/N26001 EPIC SBC Figure 6-22: USB 3.0 Driver License Agreement Step 9: The installation progress can be monitored in the progress bar shown in Figure 6-23. Figure 6-23: USB 3.0 Driver Setup Operations Step 10: When the driver installation is complete, the screen in Figure 6-24 appears.

  • Page 134: Figure 6-24: Usb 3.0 Driver Installation Finish Screen

    NANO-CV-D25501/N26001 EPIC SBC Figure 6-24: USB 3.0 Driver Installation Finish Screen Page 120...

  • Page 135: A Regulatory Compliance

    NANO-CV-D25501/N26001 EPIC SBC Appendix Regulatory Compliance Page 121...
  • Page 136 NANO-CV-D25501/N26001 EPIC SBC DECLARATION OF CONFORMITY This equipment has been tested and found to comply with specifications for CE marking. If the user modifies and/or installs other devices in the equipment, the CE conformity declaration may no longer apply. FCC WARNING This equipment complies with Part 15 of the FCC Rules.

  • Page 137: Bbios Options

    NANO-CV-D25501/N26001 EPIC SBC Appendix BIOS Options Page 123...
  • Page 138 NANO-CV-D25501/N26001 EPIC SBC Below is a list of BIOS configuration options in the BIOS chapter. 　 System Overview .........................76 　 System Date [xx/xx/xx] ......................76 　 System Time [xx:xx:xx] .......................77 　 ACPI Sleep State [S1 (CPU Stop Clock)] ................78 　 Wake system with Fixed Time [Disabled]................79 　...
  • Page 139 NANO-CV-D25501/N26001 EPIC SBC 　 Power Saving Function(ERP) [Disabled]................97 　 Azalia Controller [Enabled] ....................97 　 Micro-SD [Enabled]......................97 　 Set Spread Spectrum Function [Disabled]................97 　 Bootup NumLock State [On]....................98 　 Quiet Boot [Enabled] ......................99 　 Launch PXE OpROM [Disabled] ..................99 　 Option ROM Messages [Force BIOS].................99 　...

  • Page 140: C Terminology

    NANO-CV-D25501/N26001 EPIC SBC Appendix Terminology Page 126...
  • Page 141 NANO-CV-D25501/N26001 EPIC SBC AC ’97 Audio Codec 97 (AC’97) refers to a codec standard developed by Intel® in 1997. ACPI Advanced Configuration and Power Interface (ACPI) is an OS-directed configuration, power management, and thermal management interface. AHCI Advanced Host Controller Interface (AHCI) is a SATA Host controller register-level interface.
  • Page 142 NANO-CV-D25501/N26001 EPIC SBC DIMM Dual Inline Memory Modules are a type of RAM that offer a 64-bit data bus and have separate electrical contacts on each side of the module. The digital inputs and digital outputs are general control signals that control the on/off circuit of external devices or TTL devices.
  • Page 143 NANO-CV-D25501/N26001 EPIC SBC LVDS Low-voltage differential signaling (LVDS) is a dual-wire, high-speed differential electrical signaling system commonly used to connect LCD displays to a computer. POST The Power-on Self Test (POST) is the pre-boot actions the system performs when the system is turned-on.

  • Page 144: D Digital I/O Interface

    NANO-CV-D25501/N26001 EPIC SBC Appendix Digital I/O Interface Page 130...

  • Page 145: Introduction

    NANO-CV-D25501/N26001 EPIC SBC D.1 Introduction The DIO connector on the NANO-CV-D25501/N26001 is interfaced to GPIO ports on the Super I/O chipset. The digital inputs and digital outputs are generally control signals that control the on/off circuit of external devices or TTL devices. Data can be read or written to the selected address to enable the DIO functions.

  • Page 146: Assembly Language Sample 1

    NANO-CV-D25501/N26001 EPIC SBC D.2 Assembly Language Sample 1 AX, 6F08H ;setting the digital port as input AL low byte = value AH – 6FH Sub-function: AL – 9 :Set the digital port as OUTPUT :Digital I/O input value D.3 Assembly Language Sample 2 AX, 6F09H ;setting the digital port as output...

  • Page 147: E Watchdog Timer

    NANO-CV-D25501/N26001 EPIC SBC Appendix Watchdog Timer Page 133...
  • Page 148 NANO-CV-D25501/N26001 EPIC SBC NOTE: The following discussion applies to DOS environment. Contact IEI support or visit the IEI website for specific drivers for other operating systems. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash. This condition may have occurred by external EMIs or a software bug.
  • Page 149 NANO-CV-D25501/N26001 EPIC SBC NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. EXAMPLE PROGRAM: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30 ;time-out value is 48 seconds ;...

  • Page 150: F Hazardous Materials Disclosure

    NANO-CV-D25501/N26001 EPIC SBC Appendix Hazardous Materials Disclosure Page 136...

  • Page 151: Hazardous Materials Disclosure Table For Ipb Products Certified As Rohs Compliant Under 2002/95/Ec Without Mercury

    NANO-CV-D25501/N26001 EPIC SBC F.1 Hazardous Materials Disclosure Table for IPB Products Certified as RoHS Compliant Under 2002/95/EC Without Mercury The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 152 NANO-CV-D25501/N26001 EPIC SBC Part Name Toxic or Hazardous Substances and Elements Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated Biphenyls Diphenyl (Pb) (Hg) (Cd) Chromium (CR(VI)) (PBB) Ethers (PBDE) Housing Display Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Power Supply...
  • Page 153 NANO-CV-D25501/N26001 EPIC SBC 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯 醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11363-2006 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11363-2006 标准规定的限量要求。...

This manual is also suitable for:

Nano-cv-n26001Nano-cv-d25501-r10

Table of Contents
