1 = High signal (input at 5 V)
A non-wired input is considered as High signal!
Figure 22: Digital Selection of Emissivity with FTC Inputs
The values in the table are controllable via the DataTemp Multidrop software only.
XR
Table Entry Emissivity
(Example)
0 1.100
1 0.500
2 0.600
3 0.700
4 0.800
5 0.970
6 1.000
7 0.950
Rev. B2 Feb 2017
FTC3 FTC2 FTC1
0 0 0
0 0 1
0 1 0
0 1 1
1 0 0
1 0 1
1 1 0
1 1 1
Operation
