Hilti SF 22A Manual

Hide thumbs Also See for SF 22A:

Advertisement

Quick Links

Download this manual
SF 22A
SFH 22A
English
Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04

Advertisement

loading

Related Manuals for Hilti SF 22A

Summary of Contents for Hilti SF 22A

  • Page 1 SF 22A SFH 22A English Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04...
  • Page 2 Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04...
  • Page 3 1 Information about the documentation 1.1 About this documentation • Read this documentation before initial operation or use. This is a prerequisite for safe, trouble-free handling and use of the product. • Observe the safety instructions and warnings in this documentation and on the product.
  • Page 4 Drilling with hammering action (hammer drilling) 1.4 Product information Hilti products are designed for professional use and may be operated, ser- viced and maintained only by trained, authorized personnel. This personnel must be informed of any particular hazards that may be encountered. The product and its ancillary equipment can present hazards if used incorrectly by untrained personnel or if used not in accordance with the intended use.
  • Page 5 ▶ Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes. ▶ Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.
  • Page 6 ▶ Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts. ▶ If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used.
  • Page 7 ▶ Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns. Service ▶ Have your power tool serviced by a qualified repair person using only identical replacement parts.
  • Page 8 ▶ Take breaks between working and do physical exercises to improve the blood circulation in your fingers. Exposure to vibration during long periods of work can lead to disorders of the blood vessels and nervous system in the fingers, hands and wrists. Electrical safety ▶...
  • Page 9 English Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04...
  • Page 10 English Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04...
  • Page 11 3 Description 3.1 Overview of the product English Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04...
  • Page 12 The “'SFH” model is also suitable for hammer drilling in masonry. ▶ Use only Hilti Li-ion batteries of the B22 series with this product. ▶ Use only the Hilti battery chargers of the C4/36 series for these batteries. 3.3 Li­ion battery display The charge status of the Li-ion battery and malfunctions of the power tool are indicated by the display on the Li­ion battery.
  • Page 13 • You can find other system products approved for use with your product at your local Hilti Center or online at: www.hilti.group. 4 Drill/driver SF 22-A SFH 22-A Rated voltage 21.6 V 21.6 V Weight in accordance with EPTA 2.52 kg 2.58 kg...
  • Page 14 SF 22-A SFH 22-A Sound (power) level (L 86 dB(A) 107 dB(A) Uncertainty for the sound power level 3 dB(A) 3 dB(A) Total vibration SF 22-A SFH 22-A Vibration emission value for screwdriv- < 2.5 m/s² < 2.5 m/s² ing (a Uncertainty for screwdriving (K) 1.5 m/s²...
  • Page 15 ▶ Push the battery into the tool from the rear until it engages with an audible click. 5.1.2 Removing the battery ▶ Remove the battery. 5.1.3 Fitting and adjusting the side handle ▶ Fit or adjust the side handle. English Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04...
  • Page 16 5.1.4 Fitting the accessory tool 1. Set the forward/reverse switch to the middle position or remove the battery from the power tool. 2. Check that the connection end of the accessory tool is clean. Clean the connection end if necessary. 3.
  • Page 17 5.2 Types of work Warning! Risk of damage! ▶ Operation of the direction of rotation and/or function selector switch while the tool is running may result in damage to the tool. ▶ Do not operate this switch while the tool is running. Observe the safety instructions and warnings in this documentation and on the product.

  • Page 18: Maintenance

    • Do not operate the cordless tool if signs of damage are found or if parts malfunction. Have the tool repaired by Hilti Service immediately. • After cleaning and maintenance, fit all guards or protective devices and check that they function correctly.
  • Page 19 ▶ Check the tool and batteries for damage before use after long periods of storage. 8 Troubleshooting If the trouble you are experiencing is not listed in this table or you are unable to remedy the problem by yourself, please contact Hilti Service. 8.1 Troubleshooting Trouble or fault Possible cause...
  • Page 20 Contact Hilti Service if the problem persists. The tool or battery The tool is overloaded ▶ Pay attention to the gets very hot.
  • Page 21 The materials must be correctly separated before they can be recycled. In many countries, your old tools, machines or appli- ances can be returned to Hilti for recycling. Ask Hilti Service or your Hilti representative for further information.
  • Page 22 English Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04...
  • Page 23 Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04...
  • Page 24 Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04...
  • Page 25 Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04...
  • Page 26 Hilti = registered trademark of Hilti Corp., Schaan 20170512 Printed: 30.05.2017 | Doc-Nr: PUB / 5152424 / 000 / 04...

This manual is also suitable for:

Sfh 22-a
