SF 2H­A
English
en
Français
fr
Español
es
Português
pt

Advertisement

loading
Need help?

Need help?

Do you have a question about the SF 2H-A and is the answer not in the manual?

Questions and answers

Related Manuals for Hilti SF 2H-A

Summary of Contents for Hilti SF 2H-A

  • Page 1 SF 2H­A English Français Español Português...
  • Page 5 SF 2H­A Original operating instructions ......1 Mode d'emploi original ....... 15 Manual de instrucciones original .
  • Page 6 ▶ Make a note of this data in the following table and always refer to it when making an enquiry to your Hilti representative or Hilti Service Center.
  • Page 7 Product information Type: Generation: Serial no.: 2 Safety 2.1 Warnings The purpose of warnings Warnings alert persons to hazards that occur when handling or using the product. Description of the key words used DANGER Draws attention to imminent danger that will lead to serious personal injury or fatality.
  • Page 8 Electrical safety ▶ Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock. ▶ Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators.
  • Page 9 ▶ If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards. Power tool use and care ▶ Do not force the power tool. Use the correct power tool for your application.
  • Page 10 Service ▶ Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. 2.2.2 Drill safety warnings ▶ Use auxiliary handle(s), if supplied with the tool. Loss of control can cause personal injury.
  • Page 11 or bystanders. Certain kinds of dust are classified as carcinogenic such as oak and beech dust, especially in conjunction with additives for wood conditioning (chromate, wood preservative). Material containing asbestos may be handled only by specialists. Use a dust removal system whenever possible.
  • Page 12 ▶ Do not use the battery as a power source for other unspecified appliances. ▶ Observe the national health and safety requirements. ▶ To reduce the risk of injury, use only genuine Hilti tools and accessories.
  • Page 13 To help ensure safe and reliable operation, use only genuine Hilti spare parts and consumables. Spare parts, consumables and accessories approved by us for use with the product can be found at your local Hilti Center or online at: www.hilti.com...
  • Page 14 4 Technical data 4.1 Hammer drill/driver Rated voltage 10.8 V Weight 2.6 lb (1.2 kg) Speed 1st gear 0 rpm … 400 rpm 2nd gear 0 rpm … 1,500 rpm Torque (soft joint) ≤ 9 ftlb (≤ 12 Nm) Torque range (15 settings) 0.4 ftlb …...
  • Page 15 CAUTION Risk of injury. If the battery is not fitted correctly it may drop out and fall. ▶ Check that the battery is securely seated in the tool so that it cannot drop out and fall, thereby presenting a hazard to other persons. ▶...
  • Page 16 ▶ Set the forward/reverse switch to the desired direction of rotation. 5.7 Switching on ▶ Press the control switch. ◁ Speed of rotation is regulated by the distance the control switch is pressed in. 5.8 Switching off ▶ Release the control switch. 5.9 Fitting the accessory tool 1.

  • Page 17: Troubleshooting

    ▶ To achieve maximum battery life, stop drawing power from the battery as soon as a significant drop in the performance of the power tool is noticed. ▶ Charge the batteries using the Hilti chargers approved for use with Li-ion batteries.
  • Page 18 ▶ Dispose of defective batteries right away. Keep them out of reach of children. Do not disassemble or incinerate the batteries. ▶ Batteries that have reached the end of their life must be disposed of in accordance with national regulations or returned to Hilti.
  • Page 19 The materials must be correctly separated before they can be recycled. In many countries, your old tools, machines or appli- ances can be returned to Hilti for recycling. Ask Hilti Service or your Hilti representative for further information.
  • Page 20 Hilti = registered trademark of Hilti Corp., Schaan Pos. 3 | 20150715...
