Digital Projection E-Vision Important Information Manual page 21

Digital Projection E-Vision Laser 4K Series
11
LENS adjustment
FOCUS IN / OUT:
press and hold this button,
SHIFT:
then use the Navigation arrow
buttons to move the lens.
ZOOM IN / OUT:
12 USER PRESET A, B, C, D
Load user presets.
13 ALT
Press and hold this button to
access alternative functions for all
buttons with a green label.
14 DVI / DisplayPort2 / numeric
input 3
There is no DVI input on this
projector.
Use with
ALT
DisplayPort 2 input.
15 HDMI 2 / HDMI 4 / numeric input 2
Select the HDMI 1 input.
Use with
ALT
4 input.
HDMI 1 / HDMI 3 / numeric input 1
16
Select the HDMI 1 input.
Use with
ALT
3 input.
TEST / SWAP / numeric input 0
17
Show a test pattern. Press again to
show the next test pattern:
...Off, White, Black, Red, Green,
Blue, Cyan, Yellow, Magenta,
Off...
FREEZE and RE-SYNC are not
available when the projector uses
input HDMI 3 or 4.
3D is only available on the HDMI 3
and 4 inputs.
This projector does not use the
following options on the remote:
DVI, VGA, COMP 1 and COMP 2.
Rev A June 2017
adjust focus.
adjust zoom.
to switch to the
to switch to the HDMI
to switch to the HDMI
EXIT
FREEZE
FOCUS
IN
11
OUT
USER PRESET
A B
12
HDMI1 HDMI2
1 2
HDMI3 HDMI4 DisplayPort2
DisplayPort1 HD-T
4 5
R G
VGA COMP1
7 8
3D EYE
OK
Important Information
INFO
RE-SYNC
LENS
ZOOM
IN
SHIFT
OUT
C D
DVI ALT
3
ALT
SDI ADDR
6
B ALL
COMP2 TEST
9 0
PIP SWAP
13
14
15
16
17
