CT1X IP Phone User Manual
Soft buttons
LCD Screen
Navigation button
1~9,*#
Programmable
Key
Menu
Mute button
Headset button
MWI
Login button
Indicator Status
1. Login indicator
LED Status
Red /Flash
Red
OFF
2. Mute indicator
ATCOM TECHNOLOGY CO., LIMITE
Press to select an feature shown in the soft button features
Display screen for the phone: It shows the date, time, phone
number, incoming caller's ID(if available),line/call status,
extension numbers and the soft button features.
1. Move cursor up and down when pressed in menu reviewing.
2. Adjust output volume when pressed in talking state
3. Adjust ringer volume when pressed in idle state.
For entering numbers, letters or characters
Function key can be defined as BLF, Speed dial key, CFWD, Hold,
Xfer, ConF, DND, Redial, Voicemail.
Enter Keypad menu settings
Mute/un-mute mic-phone in talking state
Pick up phone to make outgoing calls or answer incoming calls.
Message waiting indicator/ Ringing indicator
1. Press to enter login interface to input SIP account username
and password to register to sip server.
2. Press in login-ed state to input SIP account password to logout.
Frequency
500ms on/500ms off
-
-
www.atcom.cn
Description
LAN Disconnected
SIP Unregistered
SIP Registered
