Chaperone Bed
Exit System
1 Select desired zone.
2 Press Arm.
3 To disengage press
Disarm.
4 To change alarm tone,
press the speaker icon
located on the touch
screen.
Bed Exit
1
2 3
2 3
Arm Disarm
2131-029-001 InTouch Ops Guide Rev A.indd 21 2131-029-001 InTouch Ops Guide Rev A.indd 21
Zone 1 Zone 2
In largest zone, Medium zone allows
patient can move for limited move-
freely on bed, but ment. Alarms when
alarms when patient patient approaches
moves 50 percent of siderail or moves
4
body weight out of toward the foot end.
designated area.
Patient Bed
Info Controls
Zone 3
Smallest zone per-
mits very minimal
movement. Alarms
when patient moves
out of tightly restrict-
ed zone.
Support
Bed Exit Options
Surfaces
5/6/2009 4:30:52 PM 5/6/2009 4:30:52 PM
iBed
