Town & Country Fireplaces TC36ARCH Installation And Operating Instructions Manual

Hide thumbs Also See for TC36ARCH:
Table of Contents

Advertisement

Quick Links

Download this manual
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
WARNING:
If the information in these
instructions is not followed exactly, a re or
explosion may result causing property damage,
personal injury or death.
FOR YOUR SAFETY
Installation and service must be performed
by a quali ed installer, service agency or the
gas supplier.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Immediately call your gas supplier from
a neighbour's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier call
the re department.
Do not store or use gasoline or other ammable
vapors and liquids in the vicinity of this or any
other appliance.
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA only)
or mobile home, where not prohibited by local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless a
certi ed kit is used.
This appliance is suitable for installation in a
bedroom or bed sitting room.
011214-48
SERIAL #
TC36 & TC36ARCH
INSTALLATION
AND OPERATING
INSTRUCTIONS
MODEL: TC36 & TC36AR
SERIES D
MODULAR DIRECT VENT
FIREPLACE
TC36_D & TC36_DAR
5056.427D

Advertisement

Table of Contents
loading

Related Manuals for Town & Country Fireplaces TC36ARCH

Summary of Contents for Town & Country Fireplaces TC36ARCH

  • Page 1 SERIAL # gas supplier. WHAT TO DO IF YOU SMELL GAS • Do not try to light any appliance. • Do not touch any electrical switch. TC36 & TC36ARCH • Do not use any phone in your building. • Immediately call your gas supplier from INSTALLATION a neighbour’s phone. Follow the gas AND OPERATING supplier’s instructions.

  • Page 2: Table Of Contents

    Table of Contents Table of Contents ............ 2 Wall Termination Venting Chart ......23 Caution ..............3 Roof Termination Venting Chart ......24 Safety ..............3 Vent Terminal Clearance ........27 Important Note for the Vent Terminal Minimum Clearances ..... 27 Commonwealth of Massachusetts ......

  • Page 3: Caution

    Caution FOR YOUR SAFETY - Do not install or operate your Town & Country replace without rst reading and understanding this manual. Any installation or operational deviation from the following instructions voids the Town & Country Fireplaces Warranty and may prove hazardous.

  • Page 4: Important Note For The Commonwealth Of Massachusetts

    Important Note for the Commonwealth of Massachusetts: From Massachusetts Rules and Regulations 248 CMR 5.08: For all side wall horizontally vented gas fuelled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above nished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satis ed.

  • Page 5: Fireplace Dimensions

    Fireplace Dimensions TC 36D Fireplace Dimensions Fig. #1 3 5/8" 47 3/8" 26 1/16" 47 3/4" 36 1/8" 32 1/2" 32 1/2" 24 5/8" 38 1/2" 26 7/16" 38 1/2" TC 36D Arch Fireplace Dimensions Fig. #2 47 3/8" 3 5/8" 26 1/16"...

  • Page 6: Minimum Clearances To Combustible Material

    Minimum Clearances to Combustible Material Fig. #3 NON-COMBUSTIBLE ZONE. COMBUSTIBLE FRAMING AND STEEL FRAMING DO NOT INSTALL ANY COMBUSTIBLE MATERIAL, FINISH WALL ABOVE STANDOFFS ELECTRICAL WIRING OR GAS PLUMBING IN THIS STANDOFFS AREA. MAY USE COMBUSTIBLE FACING MATERIAL IN THIS AREA MANTEL CLEARANCE CHART NON-COMBUSTIBLE...

  • Page 7: Installation Requirements

    Installation Requirements Fig. #5 The Town & Country Fireplace installation and venting must conform to the current CAN/CGA-B149 installation code (in Canada) or the current National Fuel Gas Code, ANSI Z223.1 (in the USA), and approved per local codes. Only quali ed (licensed or trained) personnel should install this product.

  • Page 8: Top Standoffs

    Top Standoffs The top standoffs are shipped loose inside Fig. #9 TOP STANDOFFS the replace and must be installed on top of the replace as shown in Fig #9. Do this once the replace is on site and in position. Locating The Fireplace In planning the installation for the replace, it is necessary to determine where the unit is to be installed, location of vent system and where gas supply piping may be plumbed.

  • Page 9: Framing And Finishing

    Framing and Finishing Note: The replace should be in place Chase Insulation: position. Secure the steel frame to the framing When installing this and venting installed before framing in brackets on each side of the unit. Ensure that replace against a non-insulated exterior wall or building an enclosure around the unit.
  • Page 10 TC 36D Minimum Combustible Framing Dimensions Fig.#12 MINIMUM COMBUSTIBLE FRAMING DIMENSIONS 61 1/16" 20 7/8" 29 1/2" 50 1/4" 12 3/8" RANGE RANGE 26 5/8" 24 7/8" 61 1/16" 48 1/8" 28 1/16" 26 5/8" 50 1/4" 86 5/16" RANGE FRAMING 1/32"...
  • Page 11 Fig. #14 Fig. #14a NON-COMBUSTIBLE BOARD DETAIL IF FINISHING THE WALL ABOVE THE UNIT WITH PAINT, THE FRAMING KIT SHIPPED WITH THE UNIT SHOULD BE DISCARDED. U S E F U L L S H E E T S O F CA L C I U M NON-COMBUSTIBLE SILICATE BOARD OR EQUIVALENT BOARD...

  • Page 12: Tc36 Steel Stud Framing Kit (+ Arched)

    TC36 Steel Stud Framing Kits (+ Arched) Fig. #16 side of frame with screw holes at side of frame Attachment points Attachment points NOTE: After frame is assembled, make sure to have the side of the frame without the screw holes facing toward the inside of the room.
  • Page 13 Regular Frame Arch Frame 1. Top Frame Assembly Fig. #17 Fig. #17a • Lay out the inner (2) and outer (3) vertical side studs, and vertical center studs (4) on a large at surface. • Using the screws provided, attach the upper header stud (5) and the stud plate (6) to the vertical center studs (4) (Fig #17 &...

  • Page 14: Adjustable Lintel

    Adjustable Lintel The adjustable lintel assembly has Fig. #20 two orientations for desired nishing. A anged edge and a hemmed edge. The lintel comes factory installed with the ange edge out. If the desired edge is different from the factory setting, use the following steps to change the Lintel edge.

  • Page 15: Hearth Extension

    Hearth Extension Fig. #22 WINDOW FRAME 1" 1/4" SUB- HEARTH FLOOR EXTENSION WINDOW TRACK Caution: While a hearth extension is not required and combustible ooring materials may be brought directly up to the replace, many materials (such as wood ooring) may not tolerate the radiant heat from this replace, resulting in discoloration, shrinking and cracking.

  • Page 16: Electrical

    Electrical FIREBOX ACCESS PANEL The gas control system is located on the right hand side of the rebox behind an access Fig. #24 panel and the decorative rebox panel (if installed). The replace is operated via a wall control and a hand held remote control unit. The wall control is connected to the replace by a 40 ft.

  • Page 17: Wall Switch Remote Control

    Wall Switch and Remote Control Fig. #28 Fig. #29 Fig. #27 TO FIREPLACE Insert a straightened paper clip into Linking the remote control unit to the the “PROGRAM” slot on the wall Press the ON/OFF button of the wall switch. switch.

  • Page 18: Home Automation

    Home Automation The home automation feature supplied with this replace is capable Fig. #31 of controlling the ame and light on/off function with the use of a dry contact relay common to home automation systems. Furthermore, the ame and light level may be modulated from high to low using the 0 - 10 volt analog output available on most home automation systems.

  • Page 19: Gas Supply

    Gas Supply Caution: The gas line should be installed by a quali ed service person in accordance with all building codes. This section is intended as a guide for quali ed technicians installing this appliance. Consult local and / or national building codes before proceeding. •...

  • Page 20: Venting

    Venting Before installing venting for this unit, the installer should read these instructions to insure that the proper vent con guration has been selected. Use only Town and Country Termination kits #: TCVT.WTA - Wall Termination Kit TCVT.RTA - Roof Termination Kit Vent system components approved for use with the Town and Country Fireplace are shown in Fig.
  • Page 21 Fig. #34 Fig. #35 TRIM TO LENGTH WALL THIMBLE AND VENT MUST NOT PROTRUDE BEYOND SIDING Wall thimble: Where a vent pipe passes through a combustible wall, a wall thimble/shield must be used to retain insulation and maintain proper clearances. The wall thimble may be cut to length for various wall thicknesses up to 12"...

  • Page 22: Wall Vent Terminal

    Vent pipe: Install vent pipe through the wall thimble and attach to ue outlet collar on top of the replace. Secure all joints with screws and seal with approved "High Temp." self-adhesive aluminum tape provided. Adjust the replace position so that the vent pipe does not protrude beyond the outer wall.

  • Page 23: Wall Termination Venting Chart

    Wall Termination Venting Chart Fig. #38 Pipe length Minimum rise Pipe length Maximum run Max. 68 1/2” 1-24” 20 1/2" 1-12" 72 3/4” 1-12” 1-18" 75 3/4" 1-48" 1-12" 78 3/4” 1-24" 1-12” 11' 2" 2-48" 1-24" 3-48" 1-24" 84 3/4” 1-24”...

  • Page 24: Roof Termination Venting Chart

    Roof Termination Venting Chart Fig. #39 Pipe length Minimum rise Pipe length Maximum run Maximum 68 1/2” 1-24” 29" 1-12" 72 3/4” 1-12” 1-18" 75 1/4" 1-48" 1-12" 78 3/4” 1-24" 1-12” 11' 1 1/2" 2-48" 1-24" 3-48" 1-24" 84 3/4” 1-24"...
  • Page 25 Ceiling Opening: Fig. #40 Determine the exact position of the replace so that the vent pipe is centered (if possible) between two building framing members. Lay out the vent system path, minimizing the number of elbows and length of vent. Consult your local building codes prior to 14 1/2"...

  • Page 26: Roof Vent Terminal

    Roof Vent Terminal: 1. Place the roof ashing over the vent pipe, secure and seal it to the roof using the methods and materials appropriate for the type of roof on the building. Shingle roof example shown (Fig #42). Place the storm collar down over the vent pipe until it is level. Tighten storm collar for a snug t.

  • Page 27: Vent Terminal Clearance

    Vent Terminal Clearance Minimum clearances to the vent terminal must be maintained as Fig. #43 VENT TERMINAL MINIMUM CLEARANCES shown in gure #43 & 43a. Measure clearances to the nearest edge of TO ADJACENT STRUCTURES termination hood. NOTE: Vent terminal must not be recessed NOTE: LOCAL CODES OR REGULATIONS MAY REQUIRE DIFFERENT CLEARANCES.

  • Page 28: Vent Pipe Sealant

    Vent Pipe Sealant Fig. #45 APPROVED “HIGH TEMP.” SELF-ADHESIVE TAPE VENT PIPE All outer joints of the vent pipe must be sealed with the approved "High Temperature" self- adhesive aluminium tape provided. Wrap the tape completely around the joint and press rmly in place.

  • Page 29: Vent Restrictor Adjustment

    Vent Restrictor Adjustment The vent restrictor is located on the underside of the rebox top. The unit leaves the fac- Fig. #47 tory with the vent restrictor open. The restrictor is built into the appliance for secondary air WALL AND ROOF ow adjustment.

  • Page 30: Wall Shield/ Ceiling Firestop Thimble

    Wall Termination Kit Wall Shield/ TCVT.WTA Ceiling Firestop Fig. #48 Thimble WALL TERMINAL 16 1/2" TCVT.9360 Fig. #49 16 1/2" WALLSHIELD/CEILING FIRESTOP THIMBLE TCVT.THIMA 9 5/8" WALL SHIELD / CEILING FIRESTOP TCVT.THIMA - OPTIONAL Roof Termination Kit TCVT.RTA Fig. #50 16 1/2"...

  • Page 31: Vent Pipe Dimensions

    Vent Pipe Dimensions Fig. #51 11" 12" PIPE ..10 1/4" 18" PIPE ..16 1/4" 24" PIPE ..22 1/4" 48" PIPE ..46 1/4" 10 15/16" 9 1/2" TCVT.811X12ADJ 11 1/8" TCVT.811X _ _ 13 13/16" 12 9/16" 8 5/16"...

  • Page 32: Vent Offset Chart

    Vent Offset Chart Fig. #52 12" PIPE 18 5/8" 18" 18" PIPE 22 7/8" 22 3/8" 10 7/8" 24" PIPE 27 1/8" 26 1/2" 48" PIPE 44 1/16" 43 1/2" 1 1/4” 11 3/8" ADDING AN ADJUSTABLE SECTION TO PIPE WILL INCREASE OFFSET BY 2 1/8"...

  • Page 33: Firebox Panels Installation

    BLACK PORCELAIN ..............TCPN.757031.C(TC36) Fig. #53a ...................TCPN.75702.C(TC36 ARCH) COFFEE BEAN BROWN PORCELAIN ........TCPN.757031CB.C(TC36) ..................TCPN.75702CB.C(TC36 ARCH) MILAN ..................TCPN.36MILC2(TC36) ..................TCPN.36ARMILC2 (TC36ARCH) ..........................TCT TITANIUM ...................TCPN.757031.TI (TC36) ..................TCPN.75702.TI (TC36 ARCH) ............................ADJUSTABLE “V” BRACKET COPPER ..................TCPN.757031.CU (TC36) ..................TCPN.75702.CU (TC36 ARCH)

  • Page 34: Finishing Touch Trim Kit Instructions

    Fig. #54 Apply gas connection before installing panels. 4. Install the Right Side Panel by inserting the bottom of the panel in rst and then angling it up into position. It may be necessary to push the rebox shield up REAR UPPER PANEL to allow panel to move freely into place.

  • Page 35: Lighting Instructions

    Lighting Instructions FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: - Immediately call your gas supplier from a neighbour's phone. Follow If you do not follow these instructions exactly, a the gas supplier's instructions. fire or explosion may result causing property damage, - If you cannot reach your gas supplier, call the fire department.

  • Page 36: First Fire

    First Fire When lit for the first time, the fireplace will emit a slight odor for a couple of hours. This is due to the curing of paints, sealants and lubricants used in the manufacturing process. This condition is temporary. Open doors and windows to ventilate area. Odors caused by the curing process may cause discomfort to some individuals.
  • Page 37 Key Lock Transmission Low battery alarm Thermostat OFF/ Room ON/SMART Temperature CPI mode Set Point Aux ON Temperature/Level/State Flame ON Split Flow Dimmer ON Comfort fan Fig. 57: Transmitter LCD display. Note: Some functions may not be available. Attention! - Turn “off” the main gas supply of the appliance during installation or maintenance of the receiver device.
  • Page 38 Operating procedure Initializing the System for the first time Install the 3 AAA type batteries in the Transmitter battery bay, located on the base of the Transmitter (fig.54). Power on the wall switch/receiver. To activate the receiver address programming, see " Linking the remote control unit to the wall switch" section on page 17 of this manual. Fig.
  • Page 39 Remote-Flame Control The proflame has six (6) flame levels. With the system on, and the flame level at the maximum in the appliance, pressing the Down Arrow Key once will reduce the flame height by one step until the flame is turned off. The Up Arrow Key will increase the flame height each time it is pressed.
  • Page 40 Continuous Pilot/Intermittent Pilot (CPI/IPI) selection With the system in "OFF" position press the Mode Key (fig. 56) to index to the IPI mode icon (fig. 66 & 67). Pressing the Up Arrow Key will activate the Continuous Pilot Ignition mode (CPI). Pressing the Down Arrow Key will return to IPI.

  • Page 41: Maintenance

    Maintenance CAUTION: Turn off gas and electrical power supply (if applicable) and allow ample time for unit to APPENDIX cool before servicing appliance. It is recommended that the replace and its venting should be inspected at least once a year by a quali ed service person. Glass Panel: Warning: Do not operate...

  • Page 42: Tc36.D Replacement Parts

    TC36.D Replacement Parts (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. TC36 BODY ASSM........TC36.D PANEL SETS PARK AVE. BEIGE HERRINGBONE ....TCPN.36PAC2 MT.VERNON RED BRICK 2 ......TCPN.36VRC2 GLASS ASSM...........GLAS.2087ASSY MANHATTAN STACKED BRICK .....TCPN.36MNC2 BLACK PORCELAIN ........TCPN.757031C FRAMING KIT ..........TC36.BFRKITA CB BROWN PORCELAIN .......TCPN.757031CBC...

  • Page 43: Tc36.Dar Replacement Parts

    TC36.DAR Replacement Parts (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. PANEL SETS TC36 ARCH BODY ASSM....TC36.DAR PARK AVE. HERRINGBONE 2 ......TCPN.36ARPAC2 MT.VERNON RED BRICK 2 ........TCPN.36ARVRC2 GLASS ASSM........GLAS.2088ASSY MANHATTAN STACKED BRICK 2 ......TCPN.36ARMNC2 BLACK PORCELAIN ..........TCPN.75702.C FRAMING KIT........TC36.BAR2FRKITA CB BROWN PORCELAIN ........TCPN.75702CB.C...

  • Page 44: Replacement Parts - Valve Control System

    Replacement Parts – Valve Control System (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM ..DESCRIPTION ..........PART NO. ITEM ..DESCRIPTION ..........PART NO. #1 ..CONTROL ASSEMBLY KIT ....TCRP..1CA #4 ..TEST FITTING ......... 5019.104 #2 ..BULKHEAD ASSEMBLY KIT ....TCRP.8133 #5..

  • Page 45: Wiring Diagram

    Wiring Diagram Fig. #74 TC36_D 011214-48...

  • Page 46: Rating Label Location

    Rating Label Location NOTE: The Rating Label is located on a plate found in a slot between the left hand side lintel and the left hand side window frame. This plate is attached to the lintel with a cable. VENTED GAS FIREPLACE - NOT FOR USE WITH SOLID FUEL FOYER AU GAZ À...
  • Page 47 TC36_D 011214-48...
  • Page 48 © 2014 Copyright Paci c Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. For technical support, please contact your retailer. Web site: www.townandcountry replaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
