Installation
June 2017
c. Insert the wire pigtail into the desired conduit opening on the terminal box. Tighten the quick connector in the
conduit opening.
d. The instrument is not polarity sensitive. Connect the blue wire to the negative LOOP terminal in the terminal
box. Connect the brown wire to the positive LOOP terminal. Isolate the green/yellow wire inside of the
DVC6200p, and ensure that the shield is totally isolated at the instrument end.
Note
The green/yellow wire is isolated inside the DVC6200p to help prevent ground loop issues.
e. Replace the terminal box cap on the terminal box. To secure the terminal box cap engage the lock screw.
3. Connect the field wiring connector to the installed quick connector.

Communication Connections

A PROFIBUS PA secondary master interfaces with the DVC6200p digital valve controller from any wiring termination
point in the segment.
12
