Fisher FIELDVUE DVC6200p Instruction Manual page 66

Parts
June 2017
Figure 7‐2. FIELDVUE DVC6200p Digital Valve Controller Housing Assembly (continued)
APPLY LUBRICANT, SEALANT, OR THREAD LOCK
APPLY LUBRICANT ON ALL O-RINGS UNLESS OTHERWISE SPECIFIED
GG06847 sheet 2 of 3
Figure 7‐3. Gauge Configuration
DOUBLE‐ACTING
FOR PIPE PLUG OPTION REPLACE 47 WITH 66
FOR TIRE VALVE OPTION REPLACE 47 WITH 67
APPLY LUBRICANT, SEALANT, OR THREAD LOCK
APPLY LUBRICANT ON ALL O-RINGS UNLESS OTHERWISE SPECIFIED
GG06847 sheet 3 of 3
64
SECTION A-A
DIRECT‐ACTING
SECTION C-C
SCALE 2 : 1
SECTION E-E
SCALE 2 : 1
SST ONLY
SECTION F-F
SCALE 2 : 1
Instruction Manual
D103563X012
REVERSE‐ACTING
