- Page 1 M-Series HMI 10.4”/12” P-cap touchscreen, with ® Intel Celeron Bay Trail-M N2930 1.83 GHz Multifunctional Design R10IBWS-MHP1 Model No.: R12IBWS-MHM2 User Manual Version 1.0 Manual Part Number: 9152111I100Q...
-
Page 2: Copyright Notice
Preface Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer. Trademark Acknowledgement Brand and product names are trademarks or registered trademarks of their respective owners. - Page 3 You may need the following information ready before you call: Product serial number Software (OS, version, application software, etc.) Description of complete problem The exact wording of any error messages In addition, free technical support is available from our engineers every business day. We are always ready to give advice on application requirements or specific information on the installation and operation of any of our products.
-
Page 4: Safety Information
ALTERNATING CURRENT / MISE À LE TERRE! The Protective Conductor Terminal (Earth Ground) symbol indicates the potential risk of serious electrical shock due to improper grounding. Le symbole de Mise à Terre indique le risqué potential de choc électrique grave à la terre incorrecte. - Page 5 and must be easily accessible. Keep this equipment away from humidity. Put this equipment on a reliable surface during installation. Dropping it or letting it fall could cause damage. The openings on the enclosure are for air convection and to protect the equipment from overheating.
- Page 6 WARNING! / AVERTISSEMENT! Only use the connection cords that come with the product. When in doubt, please contact the manufacturer. Utiliser seulement les cordons d’alimentation fournis avec le produit. Si vous doutez de leur provenance, contactez le manufacturier. WARNING!/ AVERTISSEMENT! Always ground yourself against electrostatic damage to the device.
-
Page 7: Important Information
Important Information Countries/ Area Symbol This equipment complies with essential requirements of: European Union Electromagnetic Compatibility Directive(2014/30/EU) Low Voltage Directive (2014/35/EU) Restrictions of the use of certain hazardous substances (RoHS) Directive (2011/65/EU) FCC Part 15 Subpart B Regulations Class B Federal Communications Commission Radio Frequency Interface Statement This device complies with part 15 FCC rules. -
Page 8: Ec Declaration Of Conformity
EC Declaration of Conformity [English] The object of the declaration described above [A] is in conformity with the requirement of the following EU legislations [B] and harmonized standards [C]. Product also complies with the Council directions [D]. [German] Das oben beschriebene Objekt [A] entspricht den Anforderungen der nachfolgend aufgeführten EU-Vorgben [B] und den harmonisierten Normen [C]. -
Page 9: Table Of Contents
Contents Preface ............................ii 1 Introduction ..........................13 1.1 Product Features ........................ 13 1.2 Hardware Specifications ....................14 1.3 Software Support ....................... 15 1.4 Packing List ......................... 15 1.5 Appearance ........................16 1.6 Dimensions ......................... 17 10.4” Dimensions ......................17 12.1”... - Page 10 7.1 Software Developer Support ..................... 72 7.1.1 Watchdog SDK ......................72 7.2 Problem Report Form ......................73 8 Certificates ..........................75 8.1 FCC Declaration of Conformity ..................75 8.1.1 R10IBWS-MHP1 ....................... 75 8.1.2 R12IBWS-MHM2 ...................... 76 8.2 EC Declaration of Conformity .................... 77 User Manual...
- Page 11 8.2.1 R10IBWS-MHP1 ....................... 77 8.2.2 R12IBWS-MHM2 ...................... 78 User Manual...
- Page 12 M-Series HMI Introduction Introduction This chapter gives you product overview, describes features and hardware specification. You will find all accessories that come with the HMI device in the packing list. Mechanical dimensions and drawings included in this chapter. User Manual...
-
Page 13: Introduction
M-Series HMI Introduction 1 Introduction M-Series HMI is designed to provide versatile and cost-effective solution for your industrial needs. P-cap multi-touch screen equipped with industrial motherboard offers various input/ output connectors. Intel ® Celeron ® Bay Trail-M N2930 1.83GHz processor onboard with fanless cooling system assures steady performance and silent functioning. -
Page 14: Hardware Specifications
M-Series HMI Introduction 1.2 Hardware Specifications Model Name R10IBWS-MHP1 R12IBWS-MHM2 Display: Size 10.4” 12.1” Active Display Area 245.76(H) x 184.32(V) 211.2(H) x 158.4(V) Pixel Pitch 0.264(H) x 0.264(V) 0.240(H) x 0.240(V) Display Colors 262k / 16.2M Resolution 800 x 600... -
Page 15: Software Support
M-Series HMI Introduction Power Specifications: Power Input 9-36V isolation DC-in Power Adapter 110-240 AC to 12V DC out 80W *optional 1.3 Software Support Drivers: Chipset Driver Graphics Driver Intel Sideband Fabric Device (Intel MBI) Driver (Windows 8) Intel Trusted Engine Interface (Intel TXE) Driver Audio Driver USB 3.0 Driver (Windows 7) SDK:... -
Page 16: Appearance
M-Series HMI Introduction 1.5 Appearance *COM3 is an optional connector User Manual... -
Page 17: Dimensions
M-Series HMI Introduction 1.6 Dimensions 10.4” Dimensions User Manual... -
Page 18: Dimensions
M-Series HMI Introduction 12.1” Dimensions User Manual... -
Page 19: Getting Started
M-Series HMI Getting Started Getting Started This chapter tells you important information on power supply, adapter and precautions tips. Pay attention to power considerations. User Manual... -
Page 20: Getting Started
M-Series HMI Getting Started 2 Getting Started This chapter provides information on how to connect the HMI device to the source of power, connector pinouts and the guideline to turn on/off the HMI device. 2.1 Powering On 2.1.1 AC Adapter Components 1. -
Page 21: Power Considerations
M-Series HMI Getting Started ALTERNATING CURRENT / MISE À LE TERRE! This product must be grounded. Use only a grounded AC outlet. Install the additional PE ground wire if the local installation regulations require it. *If you do not use a grounded outlet while using the device, you may notice an electrical tingling sensation when the palms of your hands touch the device. -
Page 22: Connecting The Power
M-Series HMI Getting Started 2.1.3 Connecting the Power Connecting to AC Power Source 1. Plug one end of the terminal block cable firmly to the DC IN Jack. 2. Plug the other end of the terminal block to the AC adapter. 3. -
Page 23: Connector Pinouts
M-Series HMI Getting Started 2. Plug the terminal block plug firmly to the DC IN Jack. 3. Connect the other end of the DC power cable (wires with lug terminals that are labeled + and – to the terminals of the 9~36V DC Power Source. Ensure that the power connections maintain the proper polarity. -
Page 24: Hdmi Connector
M-Series HMI Getting Started 2.2.4 HDMI Connector Pin № Name Pin № Name TMDS_DATA2+ TMDS_DATA2- TMDS_DATA1+ TMDS_DATA1- TMDS_DATA0+ TMDS_DATA0- TMDS_CLOCK+ TMDS_CLOCK- DDC_CLOCK DDC_DATA Hot Plug Detect 2.2.5 LAN (RJ45) Connector Pin № Name Pin № Name TX1+ TX1- TX2+ TX2- TX3+ TX3- TX4+... - Page 25 M-Series HMI Getting Started Note: A pair of needle nose pliers may be helpful when working with jumpers. If you have any doubts about the best hardware configuration for your application, contact your local distributor or sales representative before you make any changes. Generally, you simply need a standard cable to make most connections.
-
Page 26: Adjusting The Lcd Display Brightness
M-Series HMI Getting Started 2.5 Adjusting the LCD Display Brightness Tap Start > Control Panel > Hardware and Sound > Power Options. Drag the brightness bar to adjust the brightness level according to your preference. 2.6 Turning Off You can Turn OFF the HMI device with the Windows power settings. To shut down the device: 1. - Page 27 M-Series HMI Operating the Device Operating the Device This chapter provides detailed information on how to operate the device. If you have been using touch-screen Panel PCs before, the interface may look familiar. Sections include system settings parameters. User Manual...
-
Page 28: Operating The Hmi Device
M-Series HMI Driver Installation 3 Operating the HMI Device In this chapter you will find instructions on how to use multi-touch on the Windows- based HMI device. 3.1 Multi-Touch The touchpad supports the core gestures for Windows. Gesture Windows Usage Gesture Action Action Tap/... -
Page 29: Operating System
M-Series HMI Driver Installation Press and Right-click Press, wait for blue- Hold ring animation to complete, then release Flicks Default: Pan Up/ Make quick drag Down/ Back, and gestures in the Forward described direction * Reference from Microsoft® 3.2 Operating System M-series HMI support several versions of Windows OS: Windows 10 IoT Enterprise, Windows Embedded 8 Standard, and Windows Embedded Standard 7 –... - Page 30 M-Series HMI Driver Installation Driver Installation This chapter describes how to install all necessary drivers. User Manual...
-
Page 31: Driver Installation
M-Series HMI Driver Installation 4 Driver Installation This chapter provides guideline to driver installations. 4.1 Installing Chipset Driver Step 1 Insert the CD that comes with the motherboard. Open the file document “Chipset Driver” and click “infinst_auto.exe” to install driver. User Manual... - Page 32 M-Series HMI Driver Installation Step 2 Click Next to continue. Step 3 Click Yes to agree the license terms. User Manual...
- Page 33 M-Series HMI Driver Installation Step 4 Click Next to install the driver. Step 5 Software setup progress window will appear, click Next to continue. Step 6 Click “Yes, I want to restart this computer now” to finish the installation. User Manual...
-
Page 34: Installing Graphics Driver
M-Series HMI Driver Installation 4.2 Installing Graphics Driver Step 1 Insert the CD that comes with the motherboard. Open the file document “Graphics Driver” and click Setup to execute the setup. Step 2 Setup Welcome Window will appear, click Next to continue the process. Step 3 Carefully read the license terms and click Yes to agree. -
Page 35: Installing Intel Sideband Fabric Device (Intel Mbi) Driver (Windows 8)
M-Series HMI Driver Installation 4.3 Installing Intel Sideband Fabric Device (Intel MBI) Driver (Windows 8) Step 1 Insert the CD that comes with the motherboard. Open the file document “MBI” and click “Setup.exe” to install the driver. Step 2 Welcome to the setup program window will appear, click Next to start the installation. -
Page 36: Installing Intel Trusted Engine Interface (Intel Txe) Driver
M-Series HMI Driver Installation 4.4 Installing Intel Trusted Engine Interface (Intel TXE) Driver Step 1 Insert the CD that comes with the motherboard. Open the file document “TXE” and click “Setup TXE.exe” to install the driver. Step 2 Welcome to the setup program window will appear, click Next to start the installation. -
Page 37: Installing Intel Network Connections
M-Series HMI Driver Installation 4.5 Installing Intel Network Connections User must confirm the type of operating system is being used before installing Intel Network Connections. Follow the steps below to complete the installation. Step 1 Click “PROWin64.exe” Step 2 Click Yes to start the installation. Step 3 Welcome window will appear, click Next to install the driver. -
Page 38: Installing Audio Driver
M-Series HMI Driver Installation 4.6 Installing Audio Driver The ALC886 series are high-performance 7.1+2 channel high definition audio codecs that provide ten DAC channels for simultaneous support of 7.1 sound playback, plus 2 channels of independent stereo sound output (multiple streaming) through the front panel stereo outputs. -
Page 39: Installing Usb 3.0 Driver (Windows 7)
M-Series HMI Driver Installation 4.7 Installing USB 3.0 Driver (Windows 7) NOTE: If your operation system is Windows Embedded 8.1 Industry or Windows Embedded 8 Standard, you should skip the USB 3.0 driver installation. This HMI features Intel Celeron Trail-M N2930 CPU with the Intel® USB 3.0 extensible Host Controller. - Page 40 M-Series HMI BIOS Setup BIOS Setup BIOS Setup Utility is a program for configuration basic Input / Output system settings of the HMI for optimum use. This chapter provides information on how to use BIOS setup, its functions and menu. User Manual...
-
Page 41: Bios Setup
M-Series HMI BIOS Setup 5 BIOS Setup 5.1 When and How to Use BIOS Setup To enter the BIOS setup, you need to connect an external USB keyboard, press <Del> key when the prompt appears on the screen during start up. The prompt screen shows only few seconds, you need to press <Del>... -
Page 42: Main Menu
M-Series HMI BIOS Setup Cursor ↑ Moves to the previous item Cursor ↓ Goes to the next item Cursor ← Moves to the previous item Cursor → Goes to the next item NOTE: You can press the F1, F2, F3, F4, –/+, and Esc keys by connecting a USB keyboard to your device. -
Page 43: Advanced Menu
M-Series HMI BIOS Setup BIOS Description Setting Option Effect Setting System Displays the system Adjustment of the Set the language in Language language. [English] is language other language. The set up by default. language in this device is English. System This is current date Date and time Set the date in the... - Page 44 M-Series HMI BIOS Setup BIOS Setting Description Setting Option Effect ACPI Settings Configures ACPI settings Enter Opens submenu F81866 Super IO Configures IO settings Enter Opens Configuration submenu Hardware Monitor Configures Hardware Monitor Enter Opens settings submenu S5 RTC Wake Settings Configures RTC Wake Enter Opens...
- Page 45 M-Series HMI BIOS Setup USB Configuration Configures USB Settings Enter Opens submenu Platform Trust Configures Platform Trust Enter Opens Technology Technology parameters submenu Security Configuration Configures Security Enter Opens parameters submenu For items marked ► press <Enter> for more options. 5.2.2.1 ACPI Settings Advanced Configuration and Power Interface (ACPI) settings allow to control how the power switch operates.
- Page 46 M-Series HMI BIOS Setup 5.2.2.2 F81866 Super IO Configuration You can use the screen to select options for Super IO Configuration, and change the value of the option selected. A description of the selected item appears on the right side of the screen.
- Page 47 M-Series HMI BIOS Setup GPI0 Port Configuration You can use the screen to change GPI0 Port setting. Use these items to set parameters related to PIN3-PIN14 Control. 5.2.2.3 Hardware Monitor You can check PC Health Status parameters such as system temperature, fan speed etc. User Manual...
- Page 48 M-Series HMI BIOS Setup 5.2.2.4 S5 RTC Wake Settings Wake system from S5 enables or disables system wake on alarm event. It allows you to wake up the system in a certain time. Wake System from S5 with fixed time setting Select Fixed Time to set the system to wake on the specified time.
- Page 49 M-Series HMI BIOS Setup Wake system from S5 after dynamic time setting Select Dynamic Time to set the system to wake on the current time + increase minute (s). User Manual...
- Page 50 M-Series HMI BIOS Setup 5.2.2.5 CPU Configuration BIOS Setting Description Setting Effect Option Socket CPU This item contains socket Enter Open sub-menu Information specific CPU information. CPU Thermal Thermal control Enter Open sub-menu Configuration Limit CPUID Limits CPIID Maximum Disabled/E Enable/Disable Maximum nabled...
- Page 51 M-Series HMI BIOS Setup 5.2.2.6 PPM Configuration BIOS Setting Description Setting Effect Option CPU C State Shows CPU C State Report Enabled/ Enable or Disable CPU Report Disabled C state report to OS Max CPU C- Allows to enter power- C1E, C3, Enable or Disable CPU State...
- Page 52 M-Series HMI BIOS Setup 5.2.2.7 Thermal Configuration This menu allows controlling thermal settings of the computer. Refer to the descriptions on the top right side of the screen for detailed information about each setting. BIOS Description Setting Option Effect Setting Critical Trip Specifies the 90C, 87C, 85C, 79C,...
- Page 53 M-Series HMI BIOS Setup 5.2.2.8 IDE Configuration BIOS Setting Description Setting Effect Option Serial- ATA Responsible for Enabled/ Enable or disable this (SATA) supporting chipset Disabled function drives with SATA interface. SATA Speed Allows forcing the speed Gen1 The maximum speed will be Support limit SATA II ports limited to 150 MB/s...
- Page 54 M-Series HMI BIOS Setup [RAID] Allows combining hard drives in RAID-arrays in order to improve the reliability of data storage, or to increase the speed. Serial- ATA The option turns on or Enabled/ Turn on (Enabled) or turn off Port 0 off Port 0 of SATA Disabled (Disabled) Port 0...
- Page 55 M-Series HMI BIOS Setup BIOS Setting Description Setting Effect Option Windows 8.X Allows user to choose the Enter Use Windows 8.X proper OS. Windows 7 Allows user to choose the Enter Use Windows 7 proper OS. IMPORTANT: The device will be shipped with OS according to your order. BIOS OS Selection menu varies accordingly.
- Page 56 M-Series HMI BIOS Setup be used. GetaA20 Activate GetaA20 Upon Enable or disable this Active Request function Option Receiving ROM Messages Force BIOS Set ROM messages Settings parameters Messages Network Specifies which Network option UEFI Only UEFI option ROM is booted ROMs are booted Legacy Storage...
- Page 57 M-Series HMI BIOS Setup BIOS Setting Description Setting Effect Option Legacy USB User can enable or disable Disable Will keep USB devices Support USB port. available only for EFI applications. Enable Enable all the USB devices USB 3.0 User can enable or disable Enable Enable USB 3.0 is enable Support...
- Page 58 M-Series HMI BIOS Setup 5.2.2.12 Platform Trust Technology BIOS Setting Description Setting Option Effect fTPM Trusted Platform Module Enabled/Disabled Enables or parameters disables this function User Manual...
- Page 59 M-Series HMI BIOS Setup 5.2.2.13 Security Configuration BIOS Setting Description Setting Effect Option Trusted Execution Technology Enabled/D Enables or disables this parameters isabled function TXE HMRFPO TXE HMRFPO parameters Enabled/D Enables or disables this isabled function TXE Firmware TXE Firmware Update Enabled/D Enables or disables this Update...
-
Page 60: Chipset Menu
M-Series HMI BIOS Setup 5.2.3 Chipset Menu For items marked with ►, please press <Enter> for more options. BIOS Description Setting Effect Setting Option High Allow to set up High Precious Timer Enabled/ Enables/Disable Precious settings Disabled s this function Timer Restore AC This function allows to set up... -
Page 61: Security Menu
M-Series HMI BIOS Setup 5.2.4 Security Menu In the Security menu, users can set administrator password, user password, and HDD security configuration. BIOS Setting Description Setting Effect Option Administrator Displays whether or not an Enter Enter Password administrator password has been password set. -
Page 62: Boot Configuration
M-Series HMI BIOS Setup 5.2.5 Boot Configuration The Boot menu sets the sequence of the devices to be searched for the operating system. The bootable devices will be automatically detected during POST and shown here, allowing you to set the sequence that the BIOS uses to look for a boot device from which to load the operating system. - Page 63 M-Series HMI BIOS Setup BIOS Setting Description Setting Effect Option Setup Prompt Allows user to configure the Enter Set the prompt Timeout number of seconds to stay in BIOS timeout setup prompt screen. Boot NumLock Enables or disables NumLock Remains On State feature on the numeric keypad of the keyboard after the POST...
-
Page 64: Save & Exit
M-Series HMI BIOS Setup 5.2.6 Save & Exit The Exit menu displays a way how to exit BIOS Setup utility. After finishing your settings, you must save and exit for changes to be applied. BIOS Setting Description Setting Effect Option Save This saves the changes to the Enter... -
Page 65: Using Recovery Wizard To Restore Computer
M-Series HMI BIOS Setup Save Save changes done so far to any Enter Saves the changes Changes of the setup options. <YES> Enter <NO> Return to the BIOS Setup Main Menu Discard Discard changes done so far to Enter Saves the changes Changes any of the setup options. - Page 66 M-Series HMI BIOS Setup A warning message about data loss will show up. Make sure the data is backed up before recovery, and click Yes to continue. Wait the recovery process to complete. During the recovery process, a command prompt will show up to indicate the percent of recovery process complete. The system will restart automatically after recovery completed.
- Page 67 M-Series HMI Mounting Solutions Mounting Solutions This chapter provides step-by-step mounting guide for all available mounting options. User Manual...
-
Page 68: Mounting Solutions
M-Series HMI Mounting Solutions 6 Mounting Solutions This chapter provides mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages. CAUTION/ ATTENTION Follow mounting instructions and use recommended mounting hardware to avoid the risk of injury. Suivez les instructions de montage et d'utilisation recommandé... -
Page 69: Mounting Guide
M-Series HMI Mounting Solutions • Keep the wires separated according to the interface. Wires that share similar electrical characteristics must be bundled together. • Do not bundle input wiring with output wiring. Keep them separate. When necessary, it is strongly advised that you label wiring to all devices in the system. -
Page 70: Flush Mount / Panel Mount
M-Series HMI Mounting Solutions 6.3.2 Flush Mount / Panel Mount Cut-out dimension ( W x D in mm) 10.4” 12.1” 262 x 199 297 x 236 Screw hole diameter M3 x 4 mm Mounting Steps: Prepare a fixture for the specific dimensions of the device Cut a hole on a sub frame or panel according to the cutout dimensions Turn off the device and disconnect the power source and other peripherals Install the device properly onto the cutout area of the sub frame or panel with... - Page 71 M-Series HMI Technical Support Documents Technical Support Documents This chapter includes Technical Support Documents. User Manual...
-
Page 72: Technical Support Documents
7.1 Software Developer Support Download SDK from Winmate Download Center or Winmate Partner Portal. 7.1.1 Watchdog SDK To find the Watchdog Sample code, please refer to the IB32 driver CD SDK or contact us. -
Page 73: Problem Report Form
M-Series HMI Technical Support Documents 7.2 Problem Report Form M-Series HMI (Multifunctional design) Customer name: Company: Tel.: Fax: E-mail: Date: Product Serial Number: _____________________________________________________ Problem Description: Please describe the problem as clearly as possible. Detailed description of the occurred problem will allow us to find the best solution to solve the problem as soon as possible. - Page 74 M-Series HMI Certificates Certificates This chapter includes FCC and EC Declarations of Conformity. User Manual...
-
Page 75: Certificates
M-Series HMI Certificates 8 Certificates This chapter includes FCC and EC Declarations of Conformity. 8.1 FCC Declaration of Conformity 8.1.1 R10IBWS-MHP1 User Manual... -
Page 76: R12Ibws-Mhm2
M-Series HMI Certificates 8.1.2 R12IBWS-MHM2 User Manual... -
Page 77: Ec Declaration Of Conformity
M-Series HMI Certificates 8.2 EC Declaration of Conformity 8.2.1 R10IBWS-MHP1 Refer to Preface for letters abbreviations in English and other languages. User Manual... - Page 78 M-Series HMI Certificates 8.2.2 R12IBWS-MHM2 Refer to Preface for letters abbreviations in English and other languages. User Manual...
- Page 79 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung City, Taipei 241, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw Official website: http://www.winmate.com.tw...
