UNFOLDING YOUR C-TECH TROLLEY

1. Remove each wheel by pressing the quick release button
2. Flip the wheels over as shown (fig. 1)
3. Slide the wheels back on to the axle as far as they will go
4. Release the button and pull the wheel back slightly to lock in to place
5. Pull lever (fig. 2), lift and unfold centre frame section - this will lock into place once unfolded
6. Release clip (fig. 3) and unfold upper frame section to desired height, re-secure clip
7
fig. 1
fig. 2
fig. 3
