M1 Lite Push Trolley
Instruction Manual
REGISTERONLINE
www.motocaddy.com/warranty

Advertisement

Table of Contents
loading

Related Manuals for Motocaddy M1 Lite

Summary of Contents for Motocaddy M1 Lite

  • Page 1 M1 Lite Push Trolley Instruction Manual REGISTERONLINE www.motocaddy.com/warranty...
  • Page 2 Locating your Serial Number The serial number for the M1 Lite Push Cart is located on the underside of the trolley frame underneath the rear cool bag strap. This number is required when registering your warranty online and should be kept handy for future use.

  • Page 3: Unfolding Your Trolley

    Unfolding your Trolley Unfolding your Trolley Push carry handle back (fig. 1) Press release button #1 and push front wheel away from trolley until it is fully extended and trolley is flat Push handle down to lock wheel in place (fig. 2) Pull CLIP 2 outwards to release (fig.

  • Page 4: Folding Your Trolley

    Folding your Trolley Folding your Trolley Fold back upper bag supports Pull CLIP 4 up to release locking system (fig. 1) Fold the frame in half and push handle towards front wheel Fold wishbone towards front wheel Push rear wheels in towards the trolley (fig. 2) Pull CLIP 2 outwards to release (fig.

  • Page 5: Using The Lower Bag Supports

    Using the Lower Bag Supports Using the Lower Bag Supports This Motocaddy trolley is fitted with the new EASILOCK™ bag attachment system. If you are using an EASILOCK™ compatible cart bag please follow these simple instructions: Fig 1 Remove the two pre-fitted lower bag straps by depressing the rear button and sliding (fig 1)

  • Page 6: Using The Upper Bag Supports / Adjusting The Bag Supports

    Using the Upper Bag Supports / Adjusting the Bag Supports Using the Upper Bag Supports The upper bag support straps can be secured using the same steps as the non-EASILOCK instructions overleaf: Stretch the elasticated strap around the bag Fig 1 Loop the rounded bar underneath the hook (fig.

  • Page 7: Using The Parking Brake

    Using the Parking Brake Using the Parking Brake The brake on your Motocaddy M1 Lite trolley is designed to be used as a parking brake (like a hand brake of a car or foot brake on a pram). When applying the brake you should make sure that the trolley has completely stopped moving first.
  • Page 8 +44 (0)1279 712 370 e: info@motocaddy.com w: www.motocaddy.com We are dedicated to protecting the environment and encourage the recycling of Motocaddy products through a free collection and disposal service. To find out more or to locate your nearest Motocaddy recycling point, please contact us through our website.
