- Page 1 INSTRUCTION MANUAL REGISTERONLINE www.motocaddy.com/warranty...
-
Page 2: Table Of Contents
Using the upper bag supports / Adjusting the bag supports Equipment overview Handle overview Power & Battery level / Operating the C-TECH Intelligent Speed Control / Electronic Park Assist Adjustable Distance Control (ADC) Setting/Resetting the clock / Using the USB charging port... -
Page 3: Locating Your Serial Number
LOCATING YOUR SERIAL NUMBER The serial number for your C-TECH trolley is located on the underside of the lower frame. This number is required when registering your warranty online and should be kept handy for future use. The same number should also be on the box received with your trolley. Please ensure that you keep hold of the packaging in case you need to return your trolley for any reason. -
Page 4: Safe Use Of Your Trolley
Do not operate the trolley whilst under the influence of drugs or excessive amounts of alcohol • Please take care when using the umbrella holder in windy conditions. The lightweight nature of the C-TECH electric trolley means that it may experience reduced stability. Please ensure that you hold the handle when an umbrella is deployed in an open position •... -
Page 5: Battery Care And Advice
Please ensure that only batteries supplied by Motocaddy are charged with Motocaddy chargers. Cyclic battery chargers are designed specifically in accordance with the battery manufacturer’s requirements. The charger MUST NOT be used to charge any other battery and is designed for use with Motocaddy C-TECH Lithium batteries only. The charger should only be connected to an earthed socket outlet and should only be opened and maintained by authorised personnel. -
Page 6: Charging Your Lithium Battery / Caring For Your Lithium Battery
CHARGING YOUR LITHIUM BATTERY The Lithium battery must always be removed from your trolley prior to charging: 1. Plug the charger into your mains supply - the red LED will light up to indicate power 2. Connect the charging cable to the socket on the side of the battery - an amber LED on the charger will indicate that the battery is charging 3. -
Page 7: Hibernation Of Lithium Batteries / Battery Management System
BMS may switch-off the battery. A full battery charge will rectify this problem. Motocaddy golf trolleys are designed to work with the BMS system installed in the Lithium batteries and the voltage meter is also synchronised to work in conjunction with the battery. If for any reason the voltage on the battery reaches that below the low battery warning on the trolley, then the BMS may disable the battery to protect it. -
Page 8: Unfolding Your C-Tech Trolley
UNFOLDING YOUR C-TECH TROLLEY fig. 1 1. Remove each wheel by pressing the quick release button 2. Flip the wheels over as shown (fig. 1) 3. Slide the wheels back on to the axle as far as they will go 4. -
Page 9: Folding Your C-Tech Trolley
FOLDING YOUR C-TECH TROLLEY fig. 1 1. Release clip, lower upper frame section and re-secure clip (fig. 1) 2. Pull lever and fold frame section down flat - this will lock into place once folded (fig. 2) 3. Remove each wheel by pressing the quick release button 4. -
Page 10: Using The Lower Bag Supports
USING THE LOWER BAG SUPPORTS This trolley is fitted with the exclusive Motocaddy EASILOCK™ bag attachment system. If you are using an EASILOCK™ compatible golf bag please follow these simple instructions: 1. Remove the two pre-fitted lower bag straps, these can be pulled off as shown (fig. 1) 2. -
Page 11: Using The Upper Bag Supports / Adjusting The Bag Supports
USING THE UPPER BAG SUPPORTS Use the following instructions to secure the upper bag supports: 1. Stretch the elasticated straps around the bag 2. Loop the rounded bar underneath the hook (fig. 1) ADJUSTING THE BAG SUPPORTS The bag support straps are manufactured from elasticated material to allow your golf bag to be held tightly in place. The strap should be adjusted to be reasonably tight around the golf bag: 1. -
Page 12: Equipment Overview
EQUIPMENT OVERVIEW 1. Upper bag support 2. Lower bag support 3. Release clip 4. Pull lever 5. EASILOCK™ housing 6. Snap-fit Lithium battery 7. Battery release lever 8. Lower strap hooks 9. Upper strap hooks 10. Front wheel 11. Rear wheels 12. -
Page 13: Handle Overview
HANDLE OVERVIEW Battery meter Clock / Speed indicator / ADC Speed meter Brake indicator Pause/Resume button Speed dial... -
Page 14: Power & Battery Level / Operating The C-Tech
The trolley will smoothly accelerate to the desired speed. (fig. 3) To stop the trolley, simply press the Pause/Resume button again and “STOP” will be shown. The C-TECH has a “Glide Stop” feature that will decelerate the trolley smoothly. fig. 3... -
Page 15: Intelligent Speed Control / Electronic Park Assist
INTELLIGENT SPEED CONTROL (ISC) The C-TECH features an Intelligent Speed Control that helps set the trolley speed as close to your walking pace as possible by automatically varying its pace to match the terrain. When going downhill it is important that you keep the trolley under power and trust it! On steeper declines, the C-TECH speed will initially increase, however the ISC will then slow the trolley down and if required initiate the electronic brake. -
Page 16: Adjustable Distance Control (Adc)
ADJUSTABLE DISTANCE CONTROL (ADC) The C-TECH features an easy-to-use Adjustable Distance Control which allows you to send the trolley ahead of you between 15 - 45 meters. 1. Whilst stationary, press and hold the Pause/Resume button and rotate the Speed Dial clockwise - “Adc”... -
Page 17: Setting/Resetting The Clock / Using The Usb Charging Port
5. Press the Pause/Resume button again to set USING THE USB CHARGING PORT The C-TECH features a USB Charging Port designed to power GPS devices during your round. Simply remove the covering cap and plug a USB cable into the charging port located on the fig. -
Page 18: Caring For Your Trolley
Makes sure the rear wheels are clean before inverting for transportation/storage • Keep battery and loom connection terminals clean and clear of debris Your C-TECH trolley is designed to require very little maintenance; we do however recommend giving your trolley regular checks to ensure: •... -
Page 19: Declaration Of Conformity
Model: S1/S1 PRO/S3 PRO/M1 PRO/M3 PRO S1 PRO DHC/S3 PRO DHC/M1 PRO DHC S7 REMOTE/C-TECH Thursday, January 01, 2017... - Page 20 +44 (0)1279 712 370 e: info@motocaddy.com w: www.motocaddy.com We are dedicated to protecting the environment and encourage the recycling of Motocaddy products through a free collection and disposal service. To find out more or to locate your nearest Motocaddy recycling point, please contact us through our website.
