LANCOM 9100 VPN
Chapter 2: Installation
¾
COM
¾
COM Connector for the serial configuration cable.
µ
ETH 1 to 4 Ethernet sockets ( 10/100/1000Base-Tx) for connection to the LAN. 10 Mbit,
100 Mbit or 1000 Mbit connections are supported. The available transfer rate
is detected automatically (autosensing).
Each Ethernet socket has two LEDs (green and yellow).
Green
Green
Green
Yellow
Yellow
¸
ISDN ISDN-S
Green
blinking
On (perma-
nently)
On (perma-
nently)
On (perma-
nently)
blinking
Off
On (perma-
nently)
¹
USB connector (USB host)
USB
18
µ
ETH1 ETH2 ETH3 ETH4
Off No networking device attached
On (perma- Connection to network device operational, not data traffic
nently)
Flickering Data traffic
Off 1000 Mbps
On (perma- 10/100 Mbps
nently)
connector. Each ISDN/S
0
Orange
blinking
blinking
Flashing
On (perma-
nently)
Off
Off
Off
¸ ¹
ISDN USB
socket has two LEDs (green and orange):
0
Hardware error
D channel connected, B channel not connected
ISDN protocol negotiation (B channel)
B channel connected
Layer-1 being established
Layer-1 deactivated
TEI or Layer-2 activation available
