Standby Displays the standby status:
Off
Red
Green
¶
VPN Status of a VPN connection.
Off
Green
Green
Green
Green
º
LCD display The LC display has two lines of 16 characters each to display the following
information in rotation:
The LANCOM 9100 VPN is equipped with the following interfaces on the front
panel:
On (perma-
nently)
On (perma-
nently)
Blinking
Flashing
Inverse flashing
On (perma-
nently)
Device name
Firmware version
Device temperature
Date and time
CPU load
Memory load
Number of VPN tunnels
Data transfer in reception direction
Data transfer in transmission direction
No VRRP aktive
or
VRRP active an one virtual router defined in the device is in
the Master state.
All virtual routers defined in the device are deactivated.
A virtual router is deactivated in the following situations:
the link is broken,
the virtual router is already in backup state and the backup
connection is broken,
the main connections fails and no backup priority is defi-
ned for the virtual router.
All virtual routers defined in the device are in Standby state.
No VPN tunnel established
Connection establishment
First connection
Other connections
VPN tunnels are established
